To Use Trace Buffer

This section describes how to set the trace buffer and how to display the statistical
data. For details on this function, see
To use the trace buffer, set the trace buffer and source output and measurement
conditions, and then press the Trigger key.
•

"To Set Trace Buffer"

• "To Display Statistical Data"
To Set Trace Buffer
For details on the setup parameters, see
4-34.
1. Press the Function > Trace function keys.
The Trace Buffer Setup dialog box opens.
2. In the Ch field, set the channel to which the setting change is applied.
3. In the Feed Data field, set SENSE (for collecting the measurement result data) or
MATH (for collecting the calculation result data).
4. In the Buffer Control field, set NEXT (for enabling the write operation to the
trace buffer) or NEVER (for disabling it).
5. In the Buffer Size field, set the size of the trace buffer (1 to 100000).
6. To apply the settings, press Apply.
To apply the settings and close the dialog box, press OK.
To cancel the setting change, press the Cancel/Local key.
To specify the measurement result data (SENSE) to be collected, use
(Measure) dialog box" on page
To specify the calculation result data (MATH) to be collected, use
dialog box" on page 4-44.
To change the statistical data to be saved in the trace buffer, use
dialog box" on page 4-44.
