User Defined
Waveform Setup
Front Panel Reference
Display and Assist Keys
Min
The following data can be loaded as the list sweep data.
• Comma separated value format, file extension csv
• Carriage return or line feed separated value format, file extension txt
• Space separated value format in a line, file extension prn
When the field pointer is in the EDIT (green) status on the ARB USER defined
waveform Start/Stop/Points field, the following assist keys are available for setting
the user defined waveform output.
Edit Opens the User Defined Waveform dialog box used to set the
user defined waveform.
Load Opens the Load User Defined Waveform dialog box used to
load a waveform data from a USB memory connected to the
front panel USB-A connector.
• User Defined Waveform dialog box
This dialog box provides the following fields for setting the user defined
waveform output. After the list is completed, press OK to apply the data and
close the dialog box.
(data graph)
(data list)
Append
Insert
4-16
Minimum value
Displays the shape of the waveform output
Lists the data index in the left cell, the output value in the
center cell, and the trigger output ON/OFF in the right cell.
When the pointer is in the MOVE status, the pointer can be
moved in the crosswise direction. And pressing the knob
changes the status to EDIT.
When the center cell is in the EDIT status, the output value
can be entered to the cell.
When the left cell is in the EDIT status, the following assist
keys are available for creating and scrolling the list. Then
the pointer can be moved in the lengthwise direction. And
pressing the knob changes the status to MOVE.
Adds a line below. The same output value
is entered to the center cell.
Adds a line above. The same output value
is entered to the center cell.
