Trace Statistical Result dialog box

This dialog box provides the following GUI for displaying the trace statistical result.
The result data is displayed in the Mean, Std. Dev., Min., and Max. fields.
Ch Only on 2-channel models. Channel 1 (Ch 1) or 2 (Ch 2)
This field specifies the channel of the data to display.
Feed Always SENSE
Element Type of data to display, AMPS, VOLTS, or OHMS
AMPS: Current measurement data
VOLTS: Voltage measurement data
OHMS: Resistance data given by Resistance=Vmeas/Imeas
In the above formula, Vmeas is the voltage measurement data,
and Imeas is the current measurement data.
For details on using resistance compensation, see
Compensation" on page
Length Data length
Mean Mean value
Std. Dev. Standard deviation
Min. Minimum value
Max. Maximum value
Keysight B2961A/B2962A User's Guide, Edition 3
Front Panel Reference
6-18.
Result key group
"Resistance
4-39
