Table 4-4 Ranging Mode used for Sweep Source Operation
BEST In the linear sweep mode, the sweep source channel automatically uses
the minimum range which covers the whole sweep output.
In the log sweep mode, the sweep source channel automatically uses
the range which provides the best resolution for each sweep step
output.
AUTO The sweep source channel automatically changes and sets the range
which provides the best resolution to apply the source output for each
sweep step.
FIXED The sweep source channel sets the range specified by the range
parameter Source Ranging: FIXED. See
page 4-18.

Output R (Emulation) dialog box

This dialog box provides the following parameters to set up the emulation table for
programmable output resistance setting.
Ch
#
Voltage (V)
Current (A)
Mode

Wait Control dialog box

This dialog box provides the following parameters for setting the source and
measurement wait time.
The source wait time is defined as the time the source channel cannot change the
output after the start of a DC output or the trailing edge of a pulse.
The measurement wait time is defined as the time the measurement channel cannot
start measurement after the start of a DC output or the trailing edge of a pulse.
Keysight B2961A/B2962A User's Guide, Edition 3
Description
Only on 2-channel models. Channel 1 (Ch 1) or 2 (Ch 2)
This field specifies the channel set by this dialog box.
List index.
Voltage value.
Current value.
Source mode: VOLTS or AMPS.
Front Panel Reference
Config key group
"Optional Parameters" on
4-31
