Math Expression

B2961A/B2962A provides a math function for performing calculations using the
measurement result data. The calculation result can be displayed and used for the
trace statistics.
For the predefined math expressions, see
To define a math expression, see Keysight B2961A/B2962A SCPI Command
Reference. Math expressions can be defined by using the :CALC:MATH commands.
For resources effective for the expression, see
To use the math function, see
To display the calculation result, see
Result dialog box" on page

Predefined Math Expressions

The following math expressions have already been defined in B2961A/B2962A.
The predefined math expressions are not cleared by the power off and on operations.
• Power (POWER)
• Offset Compensated Ohms (OFFCOMPOHM)
• Varistor Alpha (VARALPHA)
• Voltage Coefficient (VOLTCOEF)
In the following formula, [c] specifies the channel (1 or 2) used for the
measurement.
Calculates power using the following formula.
POWER = VOLT[c] * CURR[c]
Calculates offset compensated ohms (resistance) using the following formula.
OFFCOMPOHM = (VOLT[c][1]-VOLT[c][0]) / (CURR[c][1]-CURR[c][0])
where, VOLT[c][0] and CURR[c][0] are the data measured with a current output
level, and VOLT[c][1] and CURR[c][1] are the data measured with a different
current output level or zero output.
Keysight B2961A/B2962A User's Guide, Edition 3
"Predefined Math
"Resources Used in the
"Math Expression dialog box" on page
"Graph View" on page 4-22
4-38.
Function Details
Math Expression
Expressions".
Expressions".
4-33.
and "Measure
6-19
