Front Panel Reference
Display key group

Display Preference dialog box

This dialog box is used to set the following parameters. The settings are saved to the
non-volatile memory.
• V/I Limit for Each Polarity
Selects the Limit setup operation.
ON Individual setup ON
Limit+ and Limit- fields are available. Positive and negative limits
can be set individually.
OFF Individual setup OFF
Limit field is available. ±(Limit value) is set to the limit.
• Immediate V/I Update by Knob
Selects the channel operation when the Source value or the Limit value is
changed by using the digit pointer and the rotary knob.
ON Real time update ON
Turning the rotary knob changes the display value and updates the
channel output in real time.
OFF Real time update OFF
Turning the rotary knob just changes the display value. The value is
applied to the channel output by pressing the rotary knob.
• Restore Trigger Mode on Local
Stores the trigger mode setting on entering GP-IB remote state, ON or OFF.
ON Saves the trigger mode setting in the non-volatile memory on
entering GPIB remote state and restores the saved trigger mode
setting when returning to GPIB local mode.
OFF Disables this function.
