Figure 6-2
Stop value
Start value
Previous value
Function Details
Pulse Output
Pulse Output and Measurement Timing, Sweep Output Example
Voltage or current
Trigger
Source delay (1)
Measure delay (2)
Pulse delay (3)
Source wait (4)
Measure wait (5)
Pulse width (6)
To set the delay time, see
To set the pulse delay time and the pulse width, see
4-19.
To set the wait time, see
For more information about the trigger setup, see

To Set Pulse Output

The following points must be noted when setting the pulse output.
• Pulse base value is set by the Source value on the Single or Dual view.
• Pulse peak value is set by the Single view.
Set the Peak value of
output.
Or set the Start, Stop, and Points values of
for the pulsed sweep output.
6-8
Trigger
(1)
(2)
(3)
(4)
(6)
"Trigger Parameters" on page
"Wait Control dialog box" on page
"Pulse Parameters" on page 4-19
"Function Parameters" on page 4-13
Keysight B2961A/B2962A User's Guide, Edition 3
Trigger
(1)
(2)
(3)
(4)
(5)
(5)
(6)
: Measurement
4-20.
"Pulse Parameters" on page
4-31.
"Trigger key group" on page
for the pulsed bias
Time
4-35.
