Append
Insert
Delete
Scroll -100
Scroll +100
Source
CH
Points
Max
Min
• Load List Sweep Data dialog box
This dialog box provides the following fields for loading a list sweep data from a
file stored on a USB memory. Highlight a file and press OK to load the data and
close the dialog box.
(data graph)
(file list)
Path
Points
Max
Keysight B2961A/B2962A User's Guide, Edition 3
When the pointer is in the MOVE status, the pointer can be
moved in the crosswise direction. And pressing the knob
changes the status to EDIT.
When the right cell is in the EDIT status, the output value
can be entered to the cell.
When the left cell is in the EDIT status, the following assist
keys are available for creating and scrolling the list. Then
the pointer can be moved in the lengthwise direction. And
pressing the knob changes the status to MOVE.
Adds a line below. The same output value
is entered to the right cell.
Adds a line above. The same output value
is entered to the right cell.
Deletes the line.
Moves the pointer to the maximum 100
points above.
Moves the pointer to the maximum 100
points below.
Source function (VOLTS or AMPS)
Channel number 1 or 2, only on 2-channel models
Number of data points
Maximum value
Minimum value
Displays the shape of the list sweep data selected by the file
list
List of the list sweep data file
Folder into which the list sweep data file is saved
Number of data points
Maximum value
Front Panel Reference
Display and Assist Keys
4-15
