Config Displays the DIO Configuration dialog box used to set the
configuration of the Digital I/O interface. See
Configuration dialog box" on page
R/W Displays the DIO Read/Write dialog box used to read or write a
value set to the Digital I/O interface. See
dialog box" on page

Data Output Format

Pressing the Format softkey displays the following softkeys for setting the format
and elements of the output data.
Measure Displays the Format (Measure) dialog box used to set the
elements of the measurement data output. See
(Measure) dialog box" on page
Math Displays the Format (Math) dialog box used to set the elements
of the math result data output. See
on page
Trace Displays the Format (Trace) dialog box used to set the elements
of the trace data output. See
page
Data Type Displays the following softkeys for specifying the data output
format. The present setting is indicated by an asterisk on the
softkey label.
ASCII
REAL32
REAL64
Data Swap Displays the following softkeys for enabling or disabling the
byte swap for the IEEE-754 precision format data output. The
present setting is indicated by an asterisk on the softkey label.
OFF
ON
If Data Swap=ON, the byte order is reversed. Byte 1 to byte 4 are sent in the order of
byte 4 to byte 1 for the IEEE-754 single precision format, and byte 1 to byte 8 are
sent in the order of byte 8 to byte 1 for the IEEE-754 double precision format.
Keysight B2961A/B2962A User's Guide, Edition 3
4-46.
4-44.
4-44.
ASCII format
IEEE-754 single precision format, 4-byte
IEEE-754 double precision format, 8-byte
Disables the byte swap. Normal byte order.
Enables the byte swap. Reverse byte order.
Front Panel Reference
I/O key group
"DIO
4-45.
"DIO Read/Write
"Format
4-44.
"Format (Math) dialog box"
"Format (Trace) dialog box" on
4-43
