Table 1-3
Task
To enable/disable source output
To select source output mode
To set source output value
To set limit value
To set function OFF, sweep output
(linear single, linear double, log single,
log double, or list), or arbitrary
waveform output (exponent, ramp,
square, sinusoid, trapezoid, triangle, or
user defined)
To set constant source ranging mode
To set programmable output resistance
To set list sweep source
To set sweep source ranging mode
To set sweep direction
To set source output value after sweep
To set pulse source
To set source wait time
To set output filter
To use external low noise filter
To set programmable output resistance
using emulation table
To select output-off status
To enable/disable automatic output ON
To enable/disable automatic output OFF
Source Setup
Ch 1
Mode, Ch1 Mode, or Ch2 Mode assist key
Source, Ch1 Source, or Ch2 Source assist key
Limit, Ch1 Limit, or Ch2 Limit assist key
Hide Options/Pulse/Trigger assist key on Single view
Show Options assist key on Single view
Show Options assist key on Single view
Edit assist key in the EDIT status for the LIST sweep
Start/Stop/Points field
Config > Source > Sweep function keys
Config > Source > Sweep function keys
Config > Source > Sweep function keys
Show Pulse assist key on Single view
Config > Common > Wait function keys
Config > Source > Filter function keys
Config > Source > Ext. Filter function keys
Config > Source > Output R function keys
Config > Source > Connection function keys
Config > Source > Connection function keys
Config > Source > Connection function keys
Keysight B2961A/B2962A User's Guide, Edition 3
Relevant front panel key
switch or Ch 2
On/Off On/Off
Getting Started
Operation Summary
switch
1-13
