Page 1 AT-SBx908 GEN2 Switch Advanced Layer 3+ Modular Switch AlliedWare Plus™ v5.4.8-0 AT-SBx908 GEN2 Chassis AT-XEM2-12XT Ethernet Line Card AT-XEM2-12XS Ethernet Line Card AT-XEM2-4QS Ethernet Line Card AT-XEM2-1CQ Ethernet Line Card AT-FAN08 Fan Module AT-SBxPWRSYS2 AC Power Supply AT-SBxPWRSYS1-80 DC Power Supply Installation Guide for Virtual Chassis Stacking 613-002595 Rev.
Page 2 Allied Telesis, Inc. has been advised of, known, or should have known, the...
Page 3 Electrical Safety and Emissions Standards This product meets the following standards. U.S. Federal Communications Commission Radiated Energy Note: This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC Rules.
Page 4 Translated Safety Statements Important: Safety statements that have the  symbol are translated into multiple languages in the Translated Safety Statements document at www.alliedtelesis.com/support.
Page 5: Table Of Contents
Contents Preface ....................................13 Document Conventions ...............................14 Contacting Allied Telesis ..............................15 Chapter 1: Overview ................................ 17 Overview....................................18 AT-SBx908 GEN2 Chassis ............................18 Ethernet Line Cards ..............................18 Management Software and Interfaces .........................18 Management Methods..............................19 Management Panel ..............................19 Power Supplies ................................19 AT-SBx908 GEN2 Chassis..............................20 Ethernet Line Cards................................21...
Page 6 Contents Installing the Chassis Grounding Wire..........................84 Installing AT-SBxPWRSYS2 AC Power Supplies....................... 87 Installing AT-SBxPWRSYS1-80 DC Power Supplies ......................91 Installing Ethernet Line Cards............................. 95 Installing Blank Line Card Slot Covers..........................99 Installing the Blank Power Supply Slot Cover........................101 Installing the Power Cord Retaining Clips.........................
Page 7 Figures Figure 1: Front Panel of the AT-SBx908 GEN2 Chassis ......................20 Figure 2: Rear Panel of the AT-SBx908 GEN2 Chassis.......................20 Figure 3: AT-SBx908 GEN2 Ethernet Line Cards ........................21 Figure 4: Management Panel ...............................27 Figure 5: Switch ID LED ...............................30 Figure 6: AT-SBxPWRSYS2 and AT-SBxPWRSYS1-80 Power Supplies ................32 Figure 7: AT-FAN08 Module..............................34 Figure 8: PORT Parameter in the Command Line Interface....................35 Figure 9: Example Trunks for Stacks of Two, Three, or Four Switches ................42...
Page 8 Figures Figure 50: Removing the Ethernet Line Card from the Anti-static Bag .................96 Figure 51: Sliding the Ethernet Line Card into the Slot......................97 Figure 52: Seating an Ethernet Line Card in the Chassis.....................98 Figure 53: Tightening the Two Captive Screws on the Ethernet Line Card ................98 Figure 54: Installing a Blank Slot Cover..........................99 Figure 55: Tightening the Captive Screws on a Blank Slot Cover ..................100 Figure 56: Lifting the Locking Handle on the Blank Power Supply Slot Cover ..............101...
Page 9 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 110: Disconnecting the AC Power Cord from the Chassis ..................179 Figure 111: Lifting the Locking Handle on the AT-SBxPWRSYS2 AC Power Supply ............179 Figure 112: Removing the AT-SBxPWRSYS2 AC Power Supply ..................180 Figure 113: Loosening the Screw on the Locking Handle ....................181 Figure 114: Opening the Plastic Window over the Terminal Block..................182 Figure 115: Removing the Negative Lead Wire........................183...
Page 10 Figures...
Page 11 Tables Table 1: Twisted Pair Ports on the AT-XEM2-12XT Line Card ....................22 Table 2: Link and Activity LEDs on the AT-XEM2-12XT Line Card ..................22 Table 3: Link and Activity LEDs on the AT-XEM2-12XS Line Card ..................24 Table 4: Link and Activity Status LEDs for the AT-XEM2-4QS Line Card ................25 Table 5: Link and Activity Status LED for the AT-XEM2-1CQ Line Card ................26 Table 6: Twisted Pair Cable for the NET MGMT Port on the Management Panel ..............28 Table 7: NET MGMT Port LED ............................29...
Page 12 Tables...
Page 13: Preface
(VCStack) feature. For instructions on how to install the switch as a stand- alone device, refer to the AT-SBx908 GEN2 Installation Guide for Stand- alone Switches. This preface contains the following sections:  “Document Conventions” on page 14  “Contacting Allied Telesis” on page 15...
Page 14: Document Conventions
Preface Document Conventions This document uses the following conventions: Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury.
Page 15: Contacting Allied Telesis
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for the following services on this page: ...
Page 16 Preface...
Page 17 Chapter 1 Overview The chapter contains the following sections:  “Overview” on page 18  “AT-SBx908 GEN2 Chassis” on page 20  “Ethernet Line Cards” on page 21  “AT-XEM2-12XT Line Card” on page 22  “AT-XEM2-12XS Line Card” on page 24 ...
Page 18: Chapter 1: Overview
AT-XEM2-1CQ Card features one transceiver slot for a 100Gbps QSFP28 transceiver. Ethernet line cards are ordered separately. Refer to the product data sheet on the Allied Telesis web site for a list of approved transceivers. Management Here are the management software and interfaces: Software and ...
Page 19: Management Methods
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Management You can manage the switch as follows: Methods  Command line interface accessed locally through the Console port or remotely using Telnet or Secure Shell.  Web browser interface accessed remotely using HTTP. ...
Page 20: At-Sbx908 Gen2 Chassis
Chapter 1: Overview AT-SBx908 GEN2 Chassis The front panel of the AT-SBx908 GEN2 Chassis is shown in Figure 1. Management Panel Power Supply Slot (PSU A) Power Supply Slot (PSU B) Eight Slots for Ethernet Line Cards with Blank Cover Figure 1.
Page 21: Ethernet Line Cards
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Ethernet Line Cards The AT-SBx908 GEN2 Ethernet line cards are shown in Figure 3. AT-XEM2-12XS Line Card AT-XEM2-12XT Line with 12 slots for 1Gbps Card with 12 1Gbps or SFP or 10Gbps SFP+ 10Gbps ports with RJ- transceivers, or 10Gbps 45 connectors.
Page 22: At-Xem2-12Xt Line Card
Chapter 1: Overview AT-XEM2-12XT Line Card The AT-XEM2-12XT Card has 12 twisted pair ports with standard 8-pin RJ-45 ports. The specifications of the ports are listed in Table 1. Table 1. Twisted Pair Ports on the AT-XEM2-12XT Line Card Specification Description Port Speed The ports support 1Gbps or 10Gbps.
Page 23 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 2. Link and Activity LEDs on the AT-XEM2-12XT Line Card State Description Possible causes of this state are listed here: - The port has not established a link with another network device. - The LEDs are turned off.
Page 24: At-Xem2-12Xs Line Card
SFP or SFP+ transceivers must be purchased separately. For a list of supported transceivers, refer to the AT-SBx908 GEN2 Series data sheet on the Allied Telesis web site. The slots have link and activity LEDs. The states of the LEDs are described in Table 3.
Page 25: At-Xem2-4Qs Line Card
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking AT-XEM2-4QS Line Card The AT-XEM2-4QS Line Card has four QSFP+ transceiver slots that support the following types of 40Gbps transceivers:  AT-QSFPSR4 transceiver - Has a maximum operating distance of 150m (492 ft). Requires 12-strand OM4 fiber optic cable. ...
Page 26: At-Xem2-1Cq Line Card
Chapter 1: Overview AT-XEM2-1CQ Line Card The AT-XEM2-1CQ Line Card has one transceiver slot and supports the following 100Gbps transceivers:  AT-QSFP28SR4 transceiver - Has a maximum operating distance of 70m (230 ft) or 100m (328 ft) with 12-strand OM3 or OM4 fiber optic cable, respectively.
Page 27: Management Panel
The management panel is not field-replaceable. USB Port You can use the USB port with a flash drive to perform the following management functions:  Provide a centralized network backup location for Allied Telesis Management Framework.  Store backup copies of configuration files. ...
Page 28: Net Mgmt Ethernet Management Port
Chapter 1: Overview NET MGMT The switch uses the NET MGMT port as a separate routed eth0 interface. The interface is not part of the switching matrix of the Ethernet line cards, Ethernet but the switch can route traffic in or out of the port from the line cards. Management Here are the guidelines: Port...
Page 29: Console (Rs-232) Port
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking The Network Management (NET MGMT) port has one Status LED, described in Table 7. Table 7. NET MGMT Port LED State Description Solid Green The port has established a 1000 Mbps link with a network device.
Page 30: Eco-Friendly Button
Chapter 1: Overview The chassis is booting up. The chassis has encountered a fault condition. The chassis is operating as a stand-alone switch, with the ID number 1. The chassis is a member of a VCStack and has an ID number in the range of 1 to 4. The dot in the lower right corner flashes when the switch accesses USB memory.
Page 31 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Caution The Ethernet line cards do not forward network traffic for about three minutes while they initialize the AlliedWare Plus operating system and configure their parameter settings. Some network traffic may be lost.
Page 32: Power Supplies
Chapter 1: Overview Power Supplies The power supply units for the chassis are the AT-SBxPWRSYS2 AC and AT-SBxPWRSYS1-80 DC Power Supplies. Refer to Figure 6. AT-SBxPWRSYS2 AC Power Supply AT-SBxPWRSYS1-80 DC Power Supply Figure 6. AT-SBxPWRSYS2 and AT-SBxPWRSYS1-80 Power Supplies Here are the power supply guidelines: ...
Page 33 The power supplies are installed in the PSU A and PSU B slots in the front panel of the chassis. If you are installing only one power supply, Allied Telesis recommends installing it in PSU A slot because that slot does not come with a blank slot cover.
Page 34: At-Fan08 Units
Chapter 1: Overview AT-FAN08 Units The cooling unit for the chassis is the AT-FAN08 Fan module. Refer to Figure 7. Figure 7. AT-FAN08 Module The chassis comes with two pre-installed fan modules in FAN A and FAN B slots on the rear panel. The air flow is from the front to the back of the chassis, with the fans drawing air out of the device.
Page 35: Specifying Ports In The Command Line Interface
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Specifying Ports in the Command Line Interface The individual ports on the switches in a stack are specified in the command line interface with the PORT parameter. The format of the parameter is shown in Figure 8. .n.n port1 Stack ID Number...
Page 36 Chapter 1: Overview For instructions on the command line interface and the PORT parameter, refer to the Software Reference for AT-SBx908 GEN2 Switch, AlliedWare Plus Operating System.
Page 37: Software And Hardware Releases
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Software and Hardware Releases Software and hardware releases for the AlliedWare Plus operating software and AT-SBx908 GEN2 Switch are listed in Table 9. Table 9. Software and Hardware Releases Software Version Hardware v5.4.7A-1 AT-SBx908 GEN2 Chassis AT-XEM2-12XT Line Card...
Page 38 Chapter 1: Overview...
Page 39: Chapter 2: Virtual Chassis Stacking
Chapter 2 Virtual Chassis Stacking The sections in this chapter are listed here:  “Overview” on page 40  “Stacking Guidelines” on page 41  “Master and Member Switches” on page 55  “Switch ID Numbers” on page 57  “Optional Feature Licenses”...
Page 40: Overview
Chapter 2: Virtual Chassis Stacking Overview The Virtual Chassis Stacking (VCStack) feature lets you build a virtual stack of up to four SBx908 GEN2 Series switches. The feature allows the switches to function as a single networking unit, with the following benefits: ...
Page 41: Stacking Guidelines
 If you are using fiber optic transceivers for the trunk, the transceivers must be from Allied Telesis. Transceivers from other network equipment providers might not operate properly as part of a trunk link. For a list of supported transceivers, refer to the Allied Telesis web site.
Page 42: Figure 9: Example Trunks For Stacks Of Two, Three, Or Four Switches
Chapter 2: Virtual Chassis Stacking Stack with Two Chassis Stack with Three Chassis Stack with Four Chassis Figure 9. Example Trunks for Stacks of Two, Three, or Four Switches  The trunk configuration is referred to as a ring because the last switch in the stack is connected to the first switch, creating a loop.
Page 43: Figure 10: Stack Of Three Switches With A Linear Trunk
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  You can omit the link from the last to first switches to create a linear trunk. An example of a stack with three switches in a linear trunk is shown in Figure 10. This trunk topology is not recommended.
Page 44: Figure 11: Example Of A Trunk With Multiple Links Between Switches
Chapter 2: Virtual Chassis Stacking  You can increase the bandwidth and resiliency of trunks by increasing the number of physical links between switches. The example in Figure 11 uses ports on AT-XEM2-12XS Line Cards to build a stack of three switches, with a trunk of three links from switch-to-switch.
Page 45: Figure 12: Example Of A Stack Trunk Of Ports On Multiple Line Cards
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  You can further improve the resiliency of trunks by distributing the ports onto multiple cards in a switch. This makes it possible for trunks to continue functioning, though at reduced bandwidths, even if line cards with trunk ports fail.
Page 46: Figure 13: Invalid Trunk With Too Many Stacking Ports
Chapter 2: Virtual Chassis Stacking  Table 10 lists the maximum number of trunk ports that a switch can support at one time. The number varies by line card. For example, a switch can have a maximum of eight trunk ports when a trunk is build with ports on AT-XEM2-12XS Line Cards.
Page 47: Figure 14: Stack With Three Chassis
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  Provided that all other rules are followed, trunk ports can be chosen from any line card in a switch. Furthermore, as stated earlier, they can all be on the same line card or different cards in a switch, so long as the cards are all the same model.
Page 48: Figure 15: Invalid Trunk Because Switches Have Different Numbers Of Trunk Links
Chapter 2: Virtual Chassis Stacking  Figure 15 is an example of an invalid trunk because the units do not have the same number of trunk links. There are two links between chassis 1 and 2 and chassis 2 and 3, but only one link between chassis 1 and 3.
Page 49: Figure 16: Invalid Trunk With Different Ethernet Line Card Models
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  A trunk cannot have ports from different line card models. The trunk for the three switches in Figure 16 is invalid because it has ports from AT-XEM2-4QS and AT-XEM2-12XT Line Cards. Chassis 1 Chassis 2 Chassis 3...
Page 50: Figure 17: Invalid Trunk Using Both Direct Connect And Fiber Optic Cables On At-Xem2-12Xt Line Cards
Chapter 2: Virtual Chassis Stacking  The AT-XEM2-12XS Line Card supports 10Gbps AT-SP10TW direct connect twinax cables in addition to fiber optic transceivers. You can use direct connect cables for trunk links when switches are physically close together, such as in the same equipment rack or adjacent racks.
Page 51: Figure 18: Invalid Trunk Using Both Direct Connect And Fiber Optic Cables On At-Xem2-4Qs Line Cards
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  The AT-XEM2-4QS Line Card also supports direct connect cables, called AT-QSFPICU and AT-QSFP3CU cables. As with the AT- XEM2-12XT Line Card, you can build stack trunks using AT-XEM2- 4QS Line Cards with either direct connect cables or fiber optic transceivers, but not both.
Page 52: Figure 19: Example Of A Stack Trunk With At-Xem2-1Cq Line Cards
Chapter 2: Virtual Chassis Stacking  You can use AT-XEM2-1CQ Line Cards for a stack trunk. But since the card has only one 100Gbps transceiver slot, each switch has to have two cards. Figure 19 is an example of a stack trunk of four switches with the line card.
Page 53: Figure 20: Invalid Trunk Because A Chassis Is Connected To Three Other Chassis
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  In stacks of four chassis, no switch can have trunk links to more than two other chassis. The trunk example in Figure 20 is invalid because chassis 1 has trunk links to all three of the other switches. Chassis 1 Chassis 4 Chassis 2...
Page 54: Figure 21: Invalid Trunk Because Of Intermediary Network Devices
Chapter 2: Virtual Chassis Stacking  Trunk links must be direct connections between ports on line cards. A trunk cannot have any intermediary network devices, such as media converters, routers, or Ethernet switches. Figure 21 is an example of an invalid trunk because it has intermediary network devices, in this case media converters.
Page 55: Master And Member Switches
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Master and Member Switches A stack has a master switch. The main functions of a master switch are listed here:  Coordinate and monitor stack operations.  Verify that the switches are using the same version of management software.
Page 56 Chapter 2: Virtual Chassis Stacking After the stack is established and operating, you may, if you choose, change the priority settings on the individual units and so control which switch will be the master switch after subsequent power cycles and resets.
Page 57: Switch Id Numbers
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Switch ID Numbers Each switch must be assigned an ID number. The range is 1 to 4. The default is 1. The ID numbers are displayed on the ID LEDs on the front panels of the units.
Page 58: Optional Feature Licenses
Additional features and capabilities might be included with the operating system, but they can only be used after they are unlocked with optional feature licenses from Allied Telesis. Contact your authorized reseller or distributor for a list of optional features licenses for this product.
Page 59: Planning The Stack
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Planning the Stack Here are factors to consider when planning a stack:  How many SBx908 GEN2 Chassis will be in the stack? The maximum is four chassis.  How many trunk links will there be between switches? The maximum numbers of permitted links vary by Ethernet line card and are listed in Table 10 on page 46.
Page 60 Chapter 2: Virtual Chassis Stacking...
Page 61: Chapter 3: Beginning The Installation
Chapter 3 Beginning the Installation The chapter contains the following sections:  “Hardware Installation Overview” on page 62  “Reviewing Safety Precautions” on page 64  “Choosing a Site for the Chassis” on page 69  “Unpacking the Chassis” on page 70 ...
Page 62: Hardware Installation Overview
Chapter 3: Beginning the Installation Hardware Installation Overview Table 11 lists the general steps to installing the switch hardware. Table 11. Hardware Installation Procedures Step Description Procedure Review safety precautions. “Reviewing Safety Precautions” on page 64 Choose locations for the “Choosing a Site for the switches.
Page 63 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 11. Hardware Installation Procedures (Continued) Step Description Procedure Install the hardware. “Installing the Blank Power (continued) Supply Slot Cover” on page 101 “Installing the Power Cord Retaining Clips” on page 103...
Page 64: Reviewing Safety Precautions
Chapter 3: Beginning the Installation Reviewing Safety Precautions Please review the following safety precautions before beginning the installation procedure. Note Safety statements that have the  symbol are translated into multiple languages in the Translated Safety Statements document at www.alliedtelesis.com/support. Warning Class 1 Laser product.
Page 65 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Warning Power cord is used as a disconnection device. To de-energize equipment, disconnect the power cord.  E3 Warning Class I Equipment. This equipment must be earthed. The power plug must be connected to a properly wired earth ground socket outlet.
Page 66  E25 Warning The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28 Note Use dedicated power circuits or power conditioners to supply reliable electrical power to the device.
Page 67 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Note If installed in a closed or multi-unit rack assembly, the operating ambient temperature of the rack environment may be greater than the room ambient temperature. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).
Page 68 Chapter 3: Beginning the Installation Warning The temperature of an operational SFP or SFP+ transceiver may exceed 70° C (158° F). Exercise caution when removing or handling transceivers with unprotected hands.  E43 Warning The grounding lug on the rear panel of the chassis is for supplemental grounding.
Page 69: Choosing A Site For The Chassis
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Choosing a Site for the Chassis Observe these site requirements.  The AT-SBx908 Gen2 Chassis should be installed in a standard 19-inch equipment rack. It should not be installed on a table, desk, or wall.
Page 70: Unpacking The Chassis
Chapter 3: Beginning the Installation Unpacking the Chassis Figure 23 shows the contents of the shipping box. Figure 23. AT-SBx908 Gen2 Switch Shipping Box The items in the box are listed here:  A - Protective bag  B - AT-SBx908 Gen2 Switch ...
Page 71: Figure 24: Lifting The Switch From The Shipping Box
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Warning The switch is heavy. Ask for assistance lifting the device out of the shipping box. You might injure yourself or damage the device if you lift it without assistance. Figure 24. Lifting the Switch from the Shipping Box 2.
Page 72: Figure 26: Pre-Installed Items On The Front And Side Panels
Chapter 3: Beginning the Installation 3. Visually inspect the front panel of the switch for the pre-installed components shown in Figure 26. 1. Two equipment rack 3. One blank panel in power 2. Seven line card slot brackets supply slot B covers 4.
Page 73: Figure 27: Pre-Installed Items On The Rear Panel
Figure 27. Pre-installed Items on the Rear Panel Note You should retain the original packaging material in the event you need to return the unit to Allied Telesis. Note The product does not come with power supplies. Power supplies must be ordered separately.
Page 74: Figure 28: Accessory Kit
RJ-45 (8P8C) and DB-9 (D- sub 9-pin) connectors. Two power cord retaining clips Figure 28. Accessory Kit If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. 6. After unpacking the switch, do one of the following: ...
Page 75: Unpacking At-Sbxpwrsys2 Ac Power Supplies
The tie wrap included with the power supply is not used with the AT- SBx908 Gen2 chassis. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. After unpacking the chassis and power supplies, go to Chapter 4,...
Page 76: Unpacking At-Sbxpwrsys1-80 Dc Power Supplies
Figure 30. Items in the Shipping Box for the AT-SBxPWRSYS1-80 DC Power Supply If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. After unpacking the chassis and power supplies, go to Chapter 4,...
Page 77: Chapter 4: Installing The Chassis
Chapter 4 Installing the Chassis The procedures in this chapter explain how to install the chassis in a standard 19-inch equipment rack. The procedures are listed here:  “Tools and Material” on page 78  “Adjusting the Equipment Rack Brackets” on page 79 ...
Page 78: Tools And Material
Chapter 4: Installing the Chassis Tools and Material You need to provide the following tools and material to install the chassis:  #2 Phillips-head screwdriver  Eight screws for a standard 19-inch equipment rack  10 AWG stranded grounding wire ...
Page 79: Adjusting The Equipment Rack Brackets
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Adjusting the Equipment Rack Brackets The chassis comes with two pre-installed equipment rack brackets. The default positions of the brackets align the front of the chassis with the front of the equipment rack. You can re-position the brackets on the sides of the chassis to have the device extend in front of the rack.
Page 80: Figure 32: Chassis Orientations In The Equipment Rack (Continued)
Chapter 4: Installing the Chassis Figure 32. Chassis Orientations in the Equipment Rack (Continued)
Page 81: Figure 33: Chassis Orientations In The Equipment Rack (Continued)
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 33. Chassis Orientations in the Equipment Rack (Continued) To change the positions of the brackets, use a #2 Phillips-head screwdriver to remove them from their default positions and secure them to the new locations. An example is shown in Figure 34 on page 82.
Page 82: Figure 34: Example Of Adjusting The Equipment Rack Brackets
Chapter 4: Installing the Chassis Figure 34. Example of Adjusting the Equipment Rack Brackets...
Page 83: Installing The Chassis In An Equipment Rack
“Choosing a Site for the Chassis” on page 69 before installing the chassis. Caution The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28 To install the chassis, perform the following procedure: 1.
Page 84: Installing The Chassis Grounding Wire
Chapter 4: Installing the Chassis Installing the Chassis Grounding Wire This procedure explains how to connect a grounding wire to the chassis. The chassis requires a permanent connection to a good earth ground for the line cards and power supplies. The procedure requires the following items: ...
Page 85: Figure 37: Removing The Grounding Lug From The Chassis
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 37. Removing the Grounding Lug from the Chassis 3. Insert one end of the grounding wire into the grounding lug, as shown in Figure 38, and use a crimping tool to secure the wire to the grounding lug.
Page 86: Figure 39: Installing The Grounding Lug And Wire
Chapter 4: Installing the Chassis Figure 39. Installing the Grounding Lug and Wire 5. Connect the other end of the grounding wire to the building protective earth. 6. Go to “Installing AT-SBxPWRSYS2 AC Power Supplies” on page 87 or “Installing AT-SBxPWRSYS1-80 DC Power Supplies” on page 91.
Page 87: Installing At-Sbxpwrsys2 Ac Power Supplies
PSU A and PSU B If you are installing only one power supply, you may install it in either slot. Allied Telesis recommends PSU A because that slot does not come with a blank power supply panel. 2. If there is already a power supply in PSU A, lift the handle on the blank power supply panel in PSU B and slide the panel from the slot.
Page 88: Figure 40: Removing The Blank Power Supply Panel From Power Supply Slot B
Chapter 4: Installing the Chassis Figure 40. Removing the Blank Power Supply Panel from Power Supply Slot B 3. Lift the handle on the AT-SBxPWRSYS2 AC Power Supply. Refer to Figure 41. Figure 41. Lifting the Locking Handle on the AT-SBxPWRSYS2 Power Supply 4.
Page 89: Figure 42: Sliding The At-Sbxpwrsys2 Ac Power Supply Into The Chassis
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 42. Sliding the AT-SBxPWRSYS2 AC Power Supply into the Chassis 5. Gently press on the faceplate of the power supply to seat the unit on the connector on the backplane of the chassis, and lower the locking handle to secure the unit in the chassis.
Page 90 Chapter 4: Installing the Chassis 6. Visually inspect the power supply to be sure that its faceplate is flush against the front panel of the chassis and the locking handle is fully down. 7. If necessary, repeat this procedure to install a second power supply. 8.
Page 91: Installing At-Sbxpwrsys1-80 Dc Power Supplies
PSU A and PSU B If you are installing only one power supply, you may install it in either slot. Allied Telesis recommends PSU A because that slot does not come with a blank power supply panel. 2. If there is already a power supply in PSU A, lift the handle on the blank power supply panel in PSU B and slide the panel from the slot.
Page 92: Figure 44: On/Off Switch On The At-Sbxpwrsys1-80 Dc Power Supply
Chapter 4: Installing the Chassis On/Off Switch Figure 44. On/Off Switch on the AT-SBxPWRSYS1-80 DC Power Supply 4. With a #2 Phillips-head screwdriver, loosen the handle locking screw on the power supply, as shown in Figure 45. Figure 45. Loosening the Handle locking Screw on the AT- SBxPWRSYS1-80 DC Power Supply 5.
Page 93: Figure 46: Lifting The Locking Handle On The At-Sbxpwrsys1-80 Dc Power Supply
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 46. Lifting the Locking Handle on the AT-SBxPWRSYS1-80 DC Power Supply 6. Carefully align the power supply in the slot and slide it into the slot until it makes contact with the connector inside the chassis. Refer to Figure 47.
Page 94: Figure 48: Lowering The Locking Handle On The At-Sbxpwrsys1-80 Dc Power Supply
Chapter 4: Installing the Chassis Figure 48. Lowering the Locking Handle on the AT-SBxPWRSYS1-80 DC Power Supply 8. Visually inspect the power supply to be sure that its faceplate is flush against the front panel of the chassis and the locking handle is fully down.
Page 95: Installing Ethernet Line Cards
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing Ethernet Line Cards This section contains the procedure for installing Ethernet line cards in the chassis. The illustrations show the AT-XEM2-12XT Line Card. The procedure is the same for all line card models. Caution The device can be damaged by static electricity.
Page 96: Figure 50: Removing The Ethernet Line Card From The Anti-Static Bag
Chapter 4: Installing the Chassis 3. Carefully remove the new Ethernet line card from its shipping container and anti-static bag. Refer to Figure 50. Figure 50. Removing the Ethernet Line Card from the Anti-static Bag 4. Position the line card with the notch on the faceplate in the upper left corner, as shown in Figure 51 on page 97, and carefully slide it into the slot.
Page 97: Figure 51: Sliding The Ethernet Line Card Into The Slot
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Notch Bottom Flange Figure 51. Sliding the Ethernet Line Card into the Slot Caution Do not force the card into the slot. If you feel resistance, remove it and try again. 5. When you feel the line card make contact with the connector on the backplane of the chassis.
Page 98: Figure 52: Seating An Ethernet Line Card In The Chassis
Chapter 4: Installing the Chassis Figure 52. Seating an Ethernet Line Card in the Chassis 6. Visually inspect the line card to verify that its faceplate is flush against the front panel of the chassis. 7. Tighten the two captive screws on the card to secure it in the chassis. Refer to Figure 53.
Page 99: Installing Blank Line Card Slot Covers
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing Blank Line Card Slot Covers After installing the Ethernet line cards, inspect slots 1 to 8 for empty slots. Empty slots need to be covered with the blank slot covers that come with the chassis.
Page 100: Figure 55: Tightening The Captive Screws On A Blank Slot Cover
Chapter 4: Installing the Chassis Figure 55. Tightening the Captive Screws on a Blank Slot Cover 3. Repeat this procedure to install additional blank slot covers. 4. Go to “Installing the Blank Power Supply Slot Cover” on page 101...
Page 101: Installing The Blank Power Supply Slot Cover
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing the Blank Power Supply Slot Cover If you installed only one power supply in the chassis, check that the empty power supply slot is covered with the blank power supply slot cover included with the chassis.
Page 102: Figure 57: Aligning The Blank Power Supply Cover In The Slot
Chapter 4: Installing the Chassis Figure 57. Aligning the Blank Power Supply Cover in the Slot 3. Lower the locking handle on the blank power supply slot cover to secure the cover in the chassis. Refer to Figure 58. Figure 58. Lowering the Locking Handle on the Blank Power Supply Slot Cover 4.
Page 103: Installing The Power Cord Retaining Clips
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing the Power Cord Retaining Clips The chassis comes with two power cord retaining clips in the accessory kit. They are used to prevent the power cords for the AT-SBxPWRSYS2 AC power supply from being accidentally disconnected from the unit. To install a power cord retaining clip, press in the sides and insert the ends into the holes above and below the AC connector.
Page 104 Chapter 4: Installing the Chassis...
Page 105: Chapter 5: Powering On The Chassis
Chapter 5 Powering On the Chassis This chapter contains the following procedures:  “Verifying the Installation” on page 106  “Powering On AT-SBxPWRSYS2 Power Supplies” on page 107  “Powering On AT-SBxPWRSYS1-80 DC Power Supplies” on page 110  “Monitoring the Initialization Processes” on page 137...
Page 106: Verifying The Installation
Chapter 5: Powering On the Chassis Verifying the Installation Please perform the following procedure before powering on the chassis: 1. Verify that the chassis has at least one power supply in slot PSU A or 2. If the chassis has only one power supply, verify that the empty power supply slot on the front panel is covered with a blank panel.
Page 107: Powering On At-Sbxpwrsys2 Power Supplies
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Powering On AT-SBxPWRSYS2 Power Supplies The procedure in this section explains how to power on AT-SBxPWRSYS2 Power Supplies. If you have not installed the power supplies, refer to “Installing AT-SBxPWRSYS2 AC Power Supplies” on page 87 for instructions.
Page 108: Figure 60: Connecting The Ac Power Cord
Chapter 5: Powering On the Chassis Figure 60. Connecting the AC Power Cord 2. Move the retaining clip over the power cord to secure the cord to the chassis. Refer to Figure 61. Figure 61. Securing the Power Cord with the Retaining Clip 3.
Page 109: Figure 62: Connecting The Power Cord To An Ac Power Source
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 62. Connecting the Power Cord to an AC Power Source Note The illustration shows the North American power cord. Your power cord may be different. Note The power cords included with AT-SBxPWRSYS2 Power Supplies for 100-125 VAC installations have 20 Amp, 125 V NEMA 5-20P plugs.
Page 110: Powering On At-Sbxpwrsys1-80 Dc Power Supplies
Chapter 5: Powering On the Chassis Powering On AT-SBxPWRSYS1-80 DC Power Supplies The procedure in this section explains how to power on AT- SBxPWRSYS1-80 DC Power Supplies. If you have not installed the power supplies, refer to “Installing AT-SBxPWRSYS1-80 DC Power Supplies” on page 91 for instructions.
Page 111: Figure 63: Components On The At-Sbxpwrsys1-80 Dc Power Supply
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  “Connecting Bare DC Power Wires” on page 133 The components on the power supply are identified in Figure 63. Positive (+) Negative (-) On/Off Terminal Terminal Switch Plastic Locking Cover Handle Screw Locking Ground Post...
Page 112: Choosing A Method For Attaching The Grounding Wire
Chapter 5: Powering On the Chassis Choosing a You may attach the grounding wire to the power supply using the supplied terminal, shown in Figure 64, or bare wire. Method for Attaching the Grounding Wire Figure 64. Grounding Wire Terminal The two methods are described in the following sections: ...
Page 113: Figure 67: On/Off Switch On The At-Sbxpwrsys1-80 Dc Power Supply
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 3. Verify that the On/Off switch on AT-SBxPWRSYS1-80 DC Power Supply is in the Off position. Refer to Figure 67. On/Off Switch Figure 67. On/Off Switch on the AT-SBxPWRSYS1-80 DC Power Supply 4.
Page 114: Figure 68: Removing The Nut And Washer From The Grounding Post
Chapter 5: Powering On the Chassis Grounding post Figure 68. Removing the Nut and Washer from the Grounding Post 5. Attach the grounding lug and wire to the grounding post. Refer to Figure 69 on page 115. Review the following before installing the grounding wire: ...
Page 115: Figure 69: Attaching The Grounding Lug And Wire To The Grounding Post
Figure 69. Attaching the Grounding Lug and Wire to the Grounding Post 6. Secure the grounding wire with the nut and washer removed in step 4, with an 8 mm wrench. Refer to Figure 70 on page 116. Allied Telesis recommends tightening the nut and washer to 26 inch- lbs.
Page 116: Figure 70: Securing The Grounding Wire
Chapter 5: Powering On the Chassis Figure 70. Securing the Grounding Wire 7. Connect the other end of the grounding wire to the building protective earth. Warning When installing this equipment, always ensure that the power supply ground connection is installed first and disconnected last.  E11 Note This system will work with a positive grounded or negative grounded DC system.
Page 117: Connecting The Grounding Wire With Bare Wire
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Connecting the To attach the grounding wire to the power supply with bare wire, perform the following procedure: Grounding Wire with Bare Wire 1. Prepare an adequate length of solid or stranded 10 AWG grounding wire by stripping it as shown in Figure 71.
Page 118: Figure 73: Securing The Bare Grounding Wire To The Grounding Post
5. Secure the wire with the nut and washer removed in step 2, and an 8 mm wrench, as shown in Figure 73. Allied Telesis recommends tightening the nut and washer to 26 inch- lbs. Figure 73. Securing the Bare Grounding Wire to the Grounding Post 6.
Page 119: Choosing A Method For Attaching The Power Wires
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Choosing a The AT-SBxPWRSYS1-80 DC Power Supply comes with the two sets of power wire terminals, shown in Figure 74. You may use either set to Method for connect the positive (+) and negative (-) wires to the terminal block on the Attaching the power supply.
Page 120: Figure 75: Stripping The Power Wires
Chapter 5: Powering On the Chassis Figure 75. Stripping the Power Wires Note You must use stranded wires with the terminal lugs. You may not use solid wires. 2. Insert the power wires into the terminals included with the power supply and use a crimping tool to secure the wires to the terminals.
Page 121: Figure 77: Opening The Plastic Cover
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 77. Opening the Plastic Cover 5. Use a #3 Phillips-head screwdriver to remove the two screws from the positive and negative terminals, as shown in Figure 78 on page 122.
Page 122: Figure 78: Removing The Terminal Screws
You may attach the terminals with the wires either above or below the terminal block. Figure 79 on page 123 shows the positive wire above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 123: Figure 79: Connecting The Positive (+) Power Wire With A Straight Terminal
You may attach the terminals with the wires either above or below the terminal block. Figure 80 on page 124 shows the wires above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 124: Figure 80: Connecting The Negative (-) Power Wire With A Straight Terminal
Chapter 5: Powering On the Chassis Figure 80. Connecting the Negative (-) Power Wire with a Straight Terminal Warning Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block.
Page 125: Figure 81: Closing The Plastic Cover Over The Terminal Connectors
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 81. Closing the Plastic Cover over the Terminal Connectors 9. With a #2 Phillips-head screwdriver, tighten the handle locking screw to secure the power supply to the chassis. See Figure 82 on page 126.
Page 126: Figure 82: Tightening The Handle Locking Screw
Chapter 5: Powering On the Chassis Handle locking screw Figure 82. Tightening the Handle Locking Screw 10. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off. 11.
Page 127: Connecting The Dc Power Wires With The Right Angle Terminals
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Connecting the To use the right angle terminals to connect the DC power wires to the positive and negative terminals on the AT-SBxPWRSYS1-80 DC Power DC Power Wires Supply, perform the following procedure: with the Right Angle Terminals 1.
Page 128: Figure 84: Removing The Plastic Cover
Chapter 5: Powering On the Chassis Figure 84. Removing the Plastic Cover 5. Use a #3 Phillips-head screwdriver to remove the two screws from the positive and negative terminals, as shown in Figure 85 on page 129.
Page 129: Figure 85: Removing The Terminal Screws
The positive terminal is on the left. Refer to Figure 86 on page 130. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 130: Figure 86: Connecting The Positive (+) Power Wire With A Right Angle Terminal
5. The negative terminal is on the right. Refer to Figure 87 on page 131. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 131: Figure 87: Connecting The Negative (-) Power Wire With A Right Angle Terminal
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 87. Connecting the Negative (-) Power Wire with a Right Angle Terminal Warning Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block.
Page 132: Figure 88: Tightening The Handle Locking Screw
Chapter 5: Powering On the Chassis Handle locking screw Figure 88. Tightening the Handle Locking Screw 9. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off. 10.
Page 133: Connecting Bare Dc Power Wires
You may attach the wire to the terminal so that it extends either above or below the terminal block. Figure 90 on page 134 shows the wire above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.
Page 134: Figure 90: Connecting The Positive Wire With Bare Wire
Chapter 5: Powering On the Chassis Figure 90. Connecting the Positive Wire With Bare Wire 5. Wrap the negative lead wire clockwise around the remaining terminal screw and secure the screw and wire to the negative terminal connection on the terminal block with a #3 Phillips-head screwdriver, as shown in Figure 91 on page 135.
Page 135: Figure 91: Connecting The Negative Lead Wire With Bare Wire
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 91. Connecting the Negative Lead Wire with Bare Wire Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs. Warning Check to see if there are any exposed copper strands coming from the installed wires.
Page 136 Chapter 5: Powering On the Chassis 7. With a #2 Phillips-head screwdriver, tighten the handle locking screw to secure the power supply to the chassis. See Figure 88 on page 132. 8. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off.
Page 137: Monitoring The Initialization Processes
/ /______\ \ \_ __/ /| ______ | | ______ | \ ____ / /______/\____\ \/ /____________/ Allied Telesis Inc. AlliedWare Plus (TM) v0.0.0 Current release filename: sbx908ng-broadcomdev-20170406-1.rel Built: Wed Apr 5 20:36:24 UTC 2017 Mounting static filesystems... Attaching to /dev/mtd1...
Page 138: Figure 93: Switch Initialization Messages (Continued)
Chapter 5: Powering On the Chassis Starting base/modules... Received event modules.done Starting base/reboot-stability... Checking system reboot stability... Starting base/apteryx... Starting base/crond... Starting base/appmond... Starting base/clockcheck... Starting hardware/timeout... Starting base/inet... Received event apteryx.done Starting base/alfred... Starting base/kernond... Starting base/plugman... Starting hardware/openhpi... Received event apteryx-sync.done Received event board.inserted Starting hardware/hardware-done...
Page 139: Figure 94: Switch Initialization Messages (Continued)
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Assigning Active Workload to HA processes: hsl, authd, epsrd, imi, imiproxyd, irdpd, lacpd lldpd, loopprotd, mstpd, nsm, ospfd, ripd, rmond sflowd, vrrpd Received event network.activated Loading default configuration ..done! Received event network.configured awplus login: Figure 94.
Page 140 Chapter 5: Powering On the Chassis...
Page 141: Chapter 6: Configuring Switches For Stacking
Chapter 6 Configuring Switches for Stacking This chapter contains the following procedures:  “Introduction” on page 142  “Starting a Local Management Session” on page 145  “Verifying the Switch with AlliedWare Plus Commands” on page 148  “Viewing the AlliedWare Plus Version Number” on page 149 ...
Page 142: Introduction
Chapter 6: Configuring Switches for Stacking Introduction This chapter contains instructions on how to configure switches for stacking with VCStack. Please review the following information before performing the instructions:  The procedures should be performed in the order presented here. ...
Page 143 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 12. Switch Configuration Procedures (Continued) AlliedWare Plus Step Description Procedure Command or Manual Write down the feature “Viewing Optional Feature SHOW LICENSE BRIEF licenses. Licenses” on page 150 command in User Exec or Privileged Exec mode.
Page 144 Chapter 6: Configuring Switches for Stacking Table 12. Switch Configuration Procedures (Continued) AlliedWare Plus Step Description Procedure Command or Manual Confirm that the switches are powered off. Cable the trunk ports. Chapter 7, “Cabling the AT-XEM2 Line Card Ports” on page 157 Power on the stack.
Page 145: Starting A Local Management Session
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Starting a Local Management Session To start a local management session on the switch, perform the following procedure. If the switch is powered off, start with step 1. If the switch is already powered on, start with step 3: Note The initial management session has to be a local session because...
Page 146: Figure 95: Connecting The Management Cable To The Console Rs-232 Port
Chapter 6: Configuring Switches for Stacking Figure 95. Connecting the Management Cable to the Console RS-232 Port 4. Connect the other end of the cable to an RS-232 port on a terminal or personal computer with a terminal emulation program. 5.
Page 147: Figure 96: User Exec Mode Prompt
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Note User names and passwords are case sensitive. The local management session starts when the User Exec mode prompt, shown in Figure 96. is displayed. awplus> Figure 96. User Exec Mode Prompt Note The User Exec mode is the first level in the command mode interface.
Page 148: Verifying The Switch With Alliedware Plus Commands
SHOW INTERFACE STATUS command in the Privileged Exec mode. For information about the command line interface, refer to the Software Reference for SwitchBlade x908 GEN2 Series Switches on the Allied Telesis web site. 5. Go to “Viewing the AlliedWare Plus Version Number” on page 149.
Page 149: Viewing The Alliedware Plus Version Number
For upgrade instructions, refer to the Software Reference for SwitchBlade x908 GEN2 Series Switches on the Allied Telesis web site. 4. Write the version number of the operating software on paper. After viewing the version numbers on all the switches, you will compare them to confirm that all switches have the same version.
Page 150: Viewing Optional Feature Licenses
Chapter 6: Configuring Switches for Stacking Viewing Optional Feature Licenses You should check whether the switches have optional Allied Telesis feature licenses and, if they do, whether they all have the same licenses. Switches with different licenses can still operate as a stack. However, licenses and their features are only available on those switches that have the licenses.
Page 151: Enabling The Vcstack Feature
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Enabling the VCStack Feature The default setting for the VCStack feature is disabled. The following procedure explains how to enable it. Note This procedure requires reseting the switch. Some network traffic will be lost if the switch is connected to an active network. To enable the stacking feature, perform the procedure in Table 13.
Page 152 Chapter 6: Configuring Switches for Stacking Table 13. Commands for Enabling the VCStack Feature (Continued) Command Description awplus# write Enter the WRITE command to Building configuration ... save your change. [OK] awplus# If this is the initial management session of the switch, the WRITE command automatically adds to flash memory a new configuration file called DEFAULT.CFG to store...
Page 153: Designating Trunk Ports
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Designating Trunk Ports This procedure explains how to designate the trunk ports of the switch. The trunk is a physical network pathway, linking the switches together into a stack. For guidelines, refer to “Stacking Guidelines” on page 41. Please review the following information before performing this procedure: ...
Page 154: Table 14: Example Of Designating Trunk Ports
Chapter 6: Configuring Switches for Stacking Table 14. Example of Designating Trunk Ports Command Description Start a local or remote management session on the switch. For instructions, refer to “Starting a Local Management Session” on page 145. awplus> enable Enter the ENABLE command to awplus# move from the User Exec mode to the Privileged Exec mode.
Page 155 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 14. Example of Designating Trunk Ports (Continued) Command Description Start a new management session on the switch. For instructions, refer to “Starting a Local Management Session” on page 145. awplus> enable Enter the ENABLE command to awplus# move from the User Exec mode...
Page 156: Powering Off The Switch
Chapter 6: Configuring Switches for Stacking Powering Off the Switch After performing the previous procedures in this chapter to confirm the hardware operations of the switch and configure the device for stacking, perform the following procedure: 1. Power off the switch by doing one of the following: ...
Page 157: Chapter 7: Cabling The At-Xem2 Line Card Ports
Chapter 7 Cabling the AT-XEM2 Line Card Ports This chapter contains the following procedures:  “Cabling 1Gbps and 10Gbps Ports on AT-XEM2-12XT Line Cards” on page 158  “Guidelines to Handling Twisted Pair or Fiber Optic Transceivers” on page 159 ...
Page 158: Cabling 1Gbps And 10Gbps Ports On At-Xem2-12Xt Line Cards
Chapter 7: Cabling the AT-XEM2 Line Card Ports Cabling 1Gbps and 10Gbps Ports on AT-XEM2-12XT Line Cards Here are the guidelines to cabling the 1Gbps/10Gbps twisted pair ports on AT-XEM2-12XT line cards:  The cable specifications for the ports are listed in Table 1 on page 22.
Page 159: Guidelines To Handling Twisted Pair Or Fiber Optic Transceivers
 For a list of supported transceivers, refer to the product data sheet on the Allied Telesis web site.  The operational specifications and fiber optic cable requirements are provided in the documents included with the transceivers.
Page 160: Installing And Cabling Fiber Optic Transceivers
Chapter 7: Cabling the AT-XEM2 Line Card Ports Installing and Cabling Fiber Optic Transceivers Table 15 lists the types of fiber optic transceivers that are supported by the AT-XEM2 line cards. Refer to the product datasheet for a list of approved transceivers.
Page 161: Figure 100: Installing An Sfp Transceiver In The At-Xem2-12Xs Line Card
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Handle Figure 100. Installing an SFP Transceiver in the AT-XEM2-12XS Line Card  AT-XEM2-4QS Line Card - Figure 101 shows an AT-QSFPLR4 transceiver being installed in an AT-XEM2-4QS Line Card. Figure 101. Installing a Fiber Optic Transceiver in the AT-XEM2-4QS Line Card ...
Page 162: Figure 102: Installing An 100Gbps Qsfp28 Transceiver In The At-Xem2-1Cq Line Card
Chapter 7: Cabling the AT-XEM2 Line Card Ports Figure 102. Installing an 100Gbps QSFP28 Transceiver in the AT-XEM2- 1CQ Line Card Note If you are ready to attach the fiber optic cable to the transceiver, continue with the next step. Otherwise, repeat steps 1 to 4 to install additional transceivers.
Page 163: Installing Direct Connect Cables
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Installing Direct Connect Cables The AT-XEM2-12XS and AT-XEM2-4QS line cards support direct connect cables, which offer an economical way to add 10Gbps or 40Gbps connections over short distances. Refer to Table 16. Table 16.
Page 164: Figure 103: Installing At-Sp10Tw Cables In The At-Xem2-12Xs Line Card
Chapter 7: Cabling the AT-XEM2 Line Card Ports Release Tab Figure 103. Installing AT-SP10TW Cables in the AT-XEM2-12XS Line Card  AT-XEM2-4QS line card - Orient the connector on the AT- QSFPCU Cable with the release tab on the left side and slide it into the slot until it clicks into place.
Page 165 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 5. Connect the other end of the cable into a compatible slot on another network device. 6. Repeat this procedure to install additional direct connect cables. Note To remove the connector and cable from the slot, gently push on the connector, pull on the release tab, and slide the connector from the slot.
Page 166 Chapter 7: Cabling the AT-XEM2 Line Card Ports...
Page 167: Chapter 8: Powering On And Verifying The Stack
Chapter 8 Powering On and Verifying the Stack This chapter contains the following procedures:  “Introduction” on page 168  “Powering On the Switches Sequentially” on page 169  “Powering On the Switches Simultaneously” on page 172  “Verifying the Stack” on page 174...
Page 168: Introduction
Chapter 8: Powering On and Verifying the Stack Introduction This chapter contains instructions on powering on the stack for the first time. As you will learn, how you initially power on the switches, either sequentially or simultaneously, determines how the switch ID numbers are assigned.
Page 169: Powering On The Switches Sequentially
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Powering On the Switches Sequentially This procedure explains how to control the assignment of the ID numbers of the switches by powering on the units one at a time, during the initial power-on sequence.
Page 170 Chapter 8: Powering On and Verifying the Stack To sequentially power on the switches, perform the following procedure: 1. Power on the switch you want assigned ID number 1, by doing one of the following  If the switch has an AC power supply, connect the AC power cord to the power supply on the back panel and to an AC power source.
Page 171 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking store their ID numbers in special files in the flash memories and retain them even when you reset or power cycle the devices. 6. To continue with the installation, go to “Verifying the Stack” on page 174.
Page 172: Powering On The Switches Simultaneously
Chapter 8: Powering On and Verifying the Stack Powering On the Switches Simultaneously If you want the switches to automatically assign the ID numbers themselves using their MAC addresses during the initial power-on sequence, you can power them on simultaneously. Here are the steps the switches perform: ...
Page 173 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking supply. (If you have not yet wired the DC connector on the power supply, refer to “Powering On AT-SBxPWRSYS1-80 DC Power Supplies” on page 110.) Refer to “Power Specifications” on page 209 for the power specifications of the switches.
Page 174: Verifying The Stack
Chapter 8: Powering On and Verifying the Stack Verifying the Stack To verify the operations of the stack, perform the following procedure: 1. Establish a local management session from the Console port on any switch in the stack. For instructions, refer to “Starting a Local Management Session”...
Page 175: Setting The Priority Numbers
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 3. Do one of the following:  If you want to change the priority values of the switches, go to “Setting the Priority Numbers” on page 175. The procedure is optional.  Otherwise, the installation is complete.
Page 176: Figure 107: Returning To The Privileged Exec Mode
Chapter 8: Powering On and Verifying the Stack 3. After setting the priority values, enter the EXIT command to return to the Privileged Exec mode, as shown in Figure 107. awplus(config)# exit awplus# Figure 107. Returning to the Privileged Exec Mode 4.
Page 177: Chapter 9: Replacing Modules
Chapter 9 Replacing Modules This chapter contains the following procedures:  “Replacing AT-SBxPWRSYS2 AC Power Supplies” on page 178  “Replacing AT-SBxPWRSYS1-80 DC Power Supplies” on page 181  “Replacing AT-XEM2 Line Cards” on page 192  “Replacing AT-FAN08 Modules” on page 197...
Page 178: Replacing At-Sbxpwrsys2 Ac Power Supplies
PSU A. The procedure is the same for removing a power supply from slot PSU B. Note Allied Telesis recommends saving a backup copy of the configuration file in the switch before removing or replacing power supplies. For instructions, refer to the Software Reference for SwitchBlade x908 Gen2 Switches.
Page 179: Figure 110: Disconnecting The Ac Power Cord From The Chassis
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking 2. Move the retaining clip from the appropriate power cord on the rear panel of the chassis, and disconnect the cord. Refer to Figure 110. Figure 110. Disconnecting the AC Power Cord from the Chassis 3.
Page 180: Figure 112: Removing The At-Sbxpwrsys2 Ac Power Supply
Chapter 9: Replacing Modules Warning The power supply is heavy. Use both hands to hold the module as you remove it from the chassis. Figure 112. Removing the AT-SBxPWRSYS2 AC Power Supply 5. Do one of the following:  To install a new power supply, refer to “Installing AT- SBxPWRSYS2 AC Power Supplies”...
Page 181: Replacing At-Sbxpwrsys1-80 Dc Power Supplies
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Replacing AT-SBxPWRSYS1-80 DC Power Supplies To replace an AT-SBxPWRSYS1-80 DC Power Supply, perform the following procedure: 1. Turn off the circuit breaker to the AT-SBxPWRSYS1-80 DC Power Supply. 2. Turn off the On/Off switch on the front panel of the power supply. Refer to Figure 44 on page 92.
Page 182: Figure 114: Opening The Plastic Window Over The Terminal Block
Chapter 9: Replacing Modules Note If the power wires are connected to the terminal block with the right angle terminals, go to step 5. 4. Use a #1 screwdriver to loosen the two screws that secure the plastic cover over the terminal block and slide the cover to the right. You may need to slightly lift the locking handle to access the bottom screw.
Page 183: Figure 115: Removing The Negative Lead Wire
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 115. Removing the Negative Lead Wire 6. Use a #3 screwdriver to remove the positive (+) lead wire from the terminal block. Refer to Figure 116 on page 184.
Page 184: Figure 116: Removing The Positive Lead Wire From The Terminal Block
Chapter 9: Replacing Modules Figure 116. Removing the Positive Lead Wire from the Terminal Block 7. Reinstall the two screws on the negative (-) and positive (+) terminals. Refer to Figure 117 on page 185.
Page 185: Figure 117: Reinstalling The Screws On The Positive And Negative Terminals
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 117. Reinstalling the Screws on the Positive and Negative Terminals 8. Slide the plastic cover to the left and lightly tighten the two screws to secure it in place. Refer to Figure 118 on page 186. Caution Do not over tighten the screws or you might crack or break the plastic cover.
Page 186: Figure 118: Closing The Plastic Cover
Chapter 9: Replacing Modules Figure 118. Closing the Plastic Cover 9. Use an 8 mm wrench to remove the grounding wire from the grounding post. Refer to Figure 119 on page 187.
Page 187: Figure 119: Removing The Grounding Wire
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 119. Removing the Grounding Wire 10. Reinstall the nut and washer on the grounding post. Refer to Figure 120 on page 188.
Page 188: Figure 120: Reinstalling The Nut And Washer On The Grounding Post
Chapter 9: Replacing Modules Figure 120. Reinstalling the Nut and Washer on the Grounding Post Note If you did not perform step 3 to loosen the retaining screw on the power supply, perform the step before continuing. 11. Lift the locking handle and slide the power supply from the chassis. Refer to Figure 121 on page 189.
Page 189: Figure 121: Lifting The Locking Handle And Removing The Power Supply
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 121. Lifting the Locking Handle and Removing the Power Supply 12. Do one of the following:  To install a new power supply, refer to “Installing AT- SBxPWRSYS2 AC Power Supplies” on page 87 or “Installing AT- SBxPWRSYS1-80 DC Power Supplies”...
Page 190: Figure 122: Installing The Blank Power Supply Slot Cover
Chapter 9: Replacing Modules Figure 122. Installing the Blank Power Supply Slot Cover 14. Lower the locking handle to secure the slot cover to the slot. Refer to Figure 123 on page 191.
Page 191: Figure 123: Lowering The Locking Handle On The Power Supply Slot Cover
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 123. Lowering the Locking Handle on the Power Supply Slot Cover...
Page 192: Replacing At-Xem2 Line Cards
Please review the following guidelines before performing the procedure:  Allied Telesis recommends saving a backup copy of the configuration file in the switch before removing or replacing line cards. For instructions, refer to the Software Reference for SwitchBlade x908 Gen2 Switches.
Page 193: Figure 124: Loosening The Screws On The Ethernet Line Card
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Note 100Gbps transceivers for the AT-XEM2-1CQ Line Card have handles. Use the handles when installing or removing transceivers. 4. Use a #2 Phillips-head screwdriver to loosen the two screws on the faceplate of the card. Refer to Figure 124. Figure 124.
Page 194: Figure 125: Disconnecting An Ethernet Line Card From The Chassis
Chapter 9: Replacing Modules Figure 125. Disconnecting an Ethernet Line Card from the Chassis 6. Carefully slide the card from the chassis. Refer to Figure 126 on page 195.
Page 195: Figure 126: Sliding An Ethernet Line Card From The Chassis
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 126. Sliding an Ethernet Line Card from the Chassis 7. If you are not installing the line card in another slot or chassis, return it to its anti-static bag and shipping container. Refer to Figure 127 on page 196.
Page 196: Figure 127: Placing The Ethernet Line Card In Its Anti-Static Bag
Chapter 9: Replacing Modules Figure 127. Placing the Ethernet Line Card in its Anti-static Bag 8. For instructions on how to install the card in another slot in either the same or a different chassis, refer to “Installing Ethernet Line Cards” on page 95.
Page 197: Replacing At-Fan08 Modules
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Replacing AT-FAN08 Modules This section contains the procedure for replacing AT-FAN08 Modules in the AT-SBx908 Gen2 Switch. The procedures are listed here:  “Removing AT-FAN08 Modules,” next  “Installing AT-FAN08 Modules” on page 198 Removing AT- This procedure requires the following tool: FAN08 Modules...
Page 198: Installing At-Fan08 Modules
Chapter 9: Replacing Modules Figure 129. Disconnecting the AT-FAN08 Module from the Chassis 3. Continue with the next procedure to install a new AT-FAN08 Module. Installing AT- This procedure requires the following tool: FAN08 Modules  #2 Phillips-head screwdriver (not provided) The illustrations show the installation of the fan module in Fan A slot on the back panel.
Page 199: Figure 130: Aligning The At-Fan08 Module In The Chassis Slot
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Figure 130. Aligning the AT-FAN08 Module in the Chassis Slot 2. When you feel the module make contact with the connector inside the chassis, gently press on both sides to seat the module on the connector.
Page 200: Figure 132: Tightening The Two Captive Screws On The At-Fan08 Module
Chapter 9: Replacing Modules 3. Tighten the two screws on the module to secure it in the chassis. Refer to Figure 132. Figure 132. Tightening the Two Captive Screws on the AT-FAN08 Module...
Page 201: Chapter 10: Troubleshooting
This chapter contains suggestions on how to troubleshoot problems with the switch. Note For further assistance, please contact Allied Telesis Technical Support at www.alliedtelesis.com/support. Problem 1: All the port LEDs and Switch ID LED are off, and the fans are not operating.
Page 202 Chapter 10: Troubleshooting  Verify that the DC circuit break has power by attaching another device to it.  Verify that the power from the DC circuit break is within the required levels of the power supply. Refer to “Power Specifications”...
Page 203 AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking  Verify that the twisted pair cable does not exceed 100 meters (328 feet).  Verify that you are using the appropriate category of twisted pair cable. Cable requirements are listed in Table 1 on page 22. ...
Page 204 If the trunk is using fiber optic transceivers, verify that they are fully inserted into the transceiver slots.  Verify that the transceivers are from Allied Telesis.  Verify that the fiber optic cables are securely connected to the ports on the transceivers.
Page 205: Appendix A: Technical Specifications
Appendix A Technical Specifications This appendix contains the following sections:  ”Physical Specifications” on page 206  ”Environmental Specifications” on page 208  ”Power Specifications” on page 209  ”Certifications” on page 211  ”Port Pinouts” on page 212...
Page 206: Physical Specifications
Appendix A: Technical Specifications Physical Specifications Dimensions (H x W x D) Table 17 lists the product dimensions. Table 17. Product Dimensions AT-SBx908 Gen2 Chassis 133 x 441 x 473 cm (5.22 x 17.34 x 18.64 in.) (H x W x D) AT-SBxPWRSYS2 AC Power 4.34 x 10.16 x 32.21 cm Supply System...
Page 207: Table 19: Ventilation Requirements
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Ventilation Table 19 lists the ventilation requirements. Table 19. Ventilation Requirements Recommended Minimum 10 cm (4.0 in) Ventilation on All Sides...
Page 208: Environmental Specifications
Appendix A: Technical Specifications Environmental Specifications Table 20 lists the environmental specifications of the switches. Table 20. Environmental Specifications Operating Temperature Range 0° C to 50° C (32° F to 122° F) Storage Temperature Range -25° C to 70° C (-13° F to 158° F) Operating Humidity Range 5% to 90% noncondensing Storage Humidity Range...
Page 209: Power Specifications
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Power Specifications This section contains the maximum power consumption values, input voltages, and heat dissipation values. AC Voltage, Frequency Requirements (Volts, Hertz) Table 21 lists the AC voltage and frequency requirements. Table 21. AC Voltage and Frequency Requirements AT-SBxPWRSYS2 AC Power 100 - 120 / 200 - 240 VAC 12/6A Supply...
Page 210: Table 25: Maximum Power Supply Efficiency (Based On 100V Input Voltage)
Appendix A: Technical Specifications Maximum Power Supply Efficiency Table 25 on page 210 lists the maximum power supply efficiency. Table 25. Maximum Power Supply Efficiency (Based on 100V Input Voltage) AT-SBxPWRSYS2 AC Power Up to 85% Supply AT-SBxPWRSYS1-80 DC Power Up to 90% Supply Heat Dissipation...
Page 211: Certifications
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Certifications Table 27 lists the product certificates. Table 27. Product Certifications EMI (Emissions) FCC Class A CISPR 22 Class A EN55032 Class A VCCI Class A ICES-003 Class A EMC (Immunity) EN55024 EN61000-3-2 EN61000-3-3 Electrical and Laser Safety...
Page 212: Port Pinouts
Appendix A: Technical Specifications Port Pinouts The port pinouts are given in the following subsections. AT-XEM2-12XT Line Card Figure 133 illustrates the pin layout of the RJ-45 connectors of the 1Gbps or 10Gbps ports on the AT-XEM2-12XT Line Card. Figure 133. Pin Layout (Front View) of the 1Gbps or 10Gbps Ports on the AT-XEM2-12XT Line Card Table 28 lists the pin signals when a port operating at 1GBase or 10GBase.
Page 213: Table 29: Rj-45 Pin Signals For The Console Port On The Management Panel
AT-SBx908 GEN2 Installation Guide for Virtual Chassis Stacking Table 29. RJ-45 Pin Signals for the Console Port on the Management Panel Signal Looped to pin 8. Looped to pin 7. Transmit Data Ground Ground Receive Data Looped to pin 2. Looped to pin 1.
Page 214 Appendix A: Technical Specifications...

This manual is also suitable for:

At-xem2-12xt At-fan08 At-xem2-12xs At-sb*pwrsys2 At-xem2-4qs At-sb*pwrsys1-80 ... Show all

Allied Telesis AT-SB*908 GEN2 Installation Manual

Preface

Chapter 1: Overview

Chapter 2: Virtual Chassis Stacking

Chapter 3: Beginning the Installation

Chapter 4: Installing the Chassis

Chapter 5: Powering on the Chassis

Chapter 6: Configuring Switches for Stacking

Chapter 7: Cabling the AT-XEM2 Line Card Ports

Chapter 8: Powering on and Verifying the Stack

Chapter 9: Replacing Modules

Chapter 10: Troubleshooting

Appendix A: Technical Specifications

Quick Links

Need help?

Questions and answers

Related Manuals for Allied Telesis AT-SB*908 GEN2

Summary of Contents for Allied Telesis AT-SB*908 GEN2
