SwitchBlade x8112
Layer 3+ Chassis Switch
AT-SBx81CFC960
Controller Fabric Card (AlliedWare Plus v5.4.9-0)
AT-SBx8112 Chassis
AT-SBx81GT24 Ethernet Line Card
AT-SBx81GT40 Ethernet Line Card
AT-SBx81GP24 Ethernet PoE Line Card
AT-SBx81GS24a Ethernet SFP Line Card
AT-SBx81GC40 Ethernet SFP and CSFP BiDi Line Card
AT-SBx81XS6 Ethernet SFP+ Line Card
AT-SBx81XS16 Ethernet SFP+ Line Card
AT-SBx81XLEM Ethernet SFP Line Card and Expansion Slot
AT-SBx81XLEM/GT8 Expansion Module
AT-SBx81XLEM/Q2 Expansion Module
AT-SBx81XLEM/XS8 Expansion Module
AT-SBx81XLEM/XT4 Expansion Module
AT-SBxPWRSYS1 and AT-SBxPWRSYS2 System Power Supplies
AT-SBxPWRPOE1 PoE Power Supply
Installation Guide
613-001936 Rev. J

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AT-SBx81GC40 and is the answer not in the manual?

Questions and answers

Related Manuals for Allied Telesis AT-SBx81GC40

Summary of Contents for Allied Telesis AT-SBx81GC40

  • Page 1 AT-SBx81GT40 Ethernet Line Card AT-SBx81GP24 Ethernet PoE Line Card AT-SBx81GS24a Ethernet SFP Line Card AT-SBx81GC40 Ethernet SFP and CSFP BiDi Line Card AT-SBx81XS6 Ethernet SFP+ Line Card AT-SBx81XS16 Ethernet SFP+ Line Card AT-SBx81XLEM Ethernet SFP Line Card and Expansion Slot...
  • Page 2 Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc. has been advised of, known, or should have known, the possibility of such damages.

  • Page 3: Electrical Safety And Emissions Standards

    European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls.

  • Page 4: Translated Safety Statements

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Translated Safety Statements Important: The  indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” on our web site at http://www.alliedtelesis.com/support. Remarque: Les consignes de sécurité portant le symbole  sont traduites dans plusieurs langues dans le document Translated Safety Statements, disponible à...

  • Page 5: Table Of Contents

    AT-SBx81GT40 Line Card..........................41 LEDs ................................42 AT-SBx81GP24 PoE Line Card........................44 LEDs ................................45 AT-SBx81GS24a SFP Line Card ........................47 LEDs ................................47 AT-SBx81GC40 SFP and CSFP Line Card......................49 Port Numbers .............................50 LEDs ................................52 AT-SBx81XS6 SFP+ Line Card........................55 LEDs ................................55 AT-SBx81XS16 SFP+ Line Card........................57 LEDs ................................57 AT-SBx81XLEM SFP Line Card........................59...
  • Page 6 Contents Twisted Pair Ports ............................70 Connector Type ............................70 Speed ................................ 70 Duplex Mode ............................. 70 Maximum Distance ............................ 71 Cable Requirements..........................71 Automatic MDIX Detection ........................71 Port Pinouts ............................... 71 Power over Ethernet on the Ports in the AT-SBx81GP24 Line Card ............... 73 Powered Device Classes...........................
  • Page 7 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Installing Blank Slot Covers..........................169 Chapter 8: Cabling the Ethernet Line Cards .....................171 Cabling Guidelines for Twisted Pair Ports ......................172 Connecting Cables to the AT-SBx81GT40 Line Card................173 Guidelines to Installing Fiber Optic Transceivers ...................175 Installing SFP, SFP+, or CSFP Transceivers ....................176 Installing AT-SP10TW Direct Connect Cables ....................182 Installing AT-QSFPCU Cables ........................185...
  • Page 8 Contents Two Controller Cards..........................292 Removing a Controller Card ........................292 Replacing the AT-SBxFAN12 Fan Module ....................295 Removing the AT-SBxFAN12 Fan Module....................295 Installing a New AT-SBxFAN12 Fan Module................... 299 Chapter 14: Upgrading the Controller Fabric Card .................. 303 Before You Begin ............................
  • Page 9 Figure 24: LEDs for the AT-SBx81GC40 Line Card ......................52 Figure 25: LEDs for the AT-SBx81GC40 Line Card, with CSFP Transceivers..............53 Figure 26: LEDs for the AT-SBx81GC40 Line Card, with SFP Transceivers ..............53 Figure 27: AT-SBx81XS6 Line Card............................ 55 Figure 28: SFP+ Port LEDs on the AT-SBx81XS6 Line Card .....................
  • Page 10 List of Figures Figure 50: Removing the Grounding Lug........................... 124 Figure 51: Attaching the Grounding Wire to the Grounding Lug..................125 Figure 52: Installing the Grounding Lug and Wire ......................125 Figure 53: ESD Socket and Wrist Strap..........................128 Figure 54: Power Supply Slots............................130 Figure 55: Removing the Blank Slot Cover from Power Supply Slot C................
  • Page 11 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 109: Installing the AT-SP10TW Cable in the AT-SBx81XS16 Line Card or AT-SBx81XLEM/XS8 Expansion Module ....................................183 Figure 110: Installing the AT-SP10TW Cable in the AT-SBx81XS6 Line Card ..............184 Figure 111: Removing the Dust Cover from a Slot on the AT-SBx81XLEM/Q2 Expansion Module ......... 185 Figure 112: Sliding the AT-QSFPCU Cable into the Slot....................
  • Page 12 List of Figures Figure 166: Opening the Plastic Window over the Terminal Block ..................273 Figure 167: Removing the Negative Lead Wire ......................... 274 Figure 168: Removing the Positive Lead Wire from the Terminal Block................275 Figure 169: Reinstalling the Screws on the Positive and Negative Terminals..............276 Figure 170: Closing the Plastic Cover..........................
  • Page 13 Table 9. Port LEDs on the AT-SBx81GP24 PoE Line Card ....................45 Table 10. Port LEDs on the AT-SBx81GS24a SFP Line Card ...................48 Table 11. Transceiver Port LEDs on the AT-SBx81GC40 Line Card .................54 Table 12. SFP+ Port LEDs on the AT-SBx81XS6 Line Card .....................56 Table 13.
  • Page 14 List of Tables Table 51. Fiber Optic Port Specifications for the AT-StackOP/0.3 Module ...............367 Table 52. Fiber Optic Port Specifications for the AT-StackOP/9.0 Transceiver ..............367...

  • Page 15: Preface

    “Structure of the Installation Guide” on page 16  “Safety Symbols Used in this Document” on page 17  “Contacting Allied Telesis” on page 18 Note This version of the installation guide applies to release 5.4.9 of the ™ AlliedWare Plus Operating System for the SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Controller Fabric Card.

  • Page 16: Structure Of The Installation Guide

    Preface Structure of the Installation Guide This guide has the following three sections:  Section I: Hardware Overview The chapters in this section describe the hardware components of the product, including the Ethernet line cards, AT-SBx81CFC960 Controller Fabric Card, and power supplies. You should start here if you are unfamiliar with the switch.

  • Page 17: Safety Symbols Used In This Document

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Safety Symbols Used in this Document This document uses the following conventions. Note Notes provide additional information. Caution Cautions inform you that performing or omitting a specific action may result in equipment damage or loss of data. Warning Warnings inform you that performing or omitting a specific action may result in bodily injury.

  • Page 18: Contacting Allied Telesis

    Preface Contacting Allied Telesis If you need assistance with this product, you may contact Allied Telesis technical support by going to the Support & Services section of the Allied Telesis web site at www.alliedtelesis.com/support. You can find links for the following services on this page: ...

  • Page 19: Section I: Hardware Overview

    Section I Hardware Overview This section contains the following chapters:  Chapter 1, “Chassis and Power Supplies” on page 21  Chapter 2, “Ethernet Line Cards” on page 35  Chapter 3, “AT-SBx81CFC960 Controller Fabric Cards” on page 77...

  • Page 21: Chapter 1: Chassis And Power Supplies

    Chapter 1 Chassis and Power Supplies This chapter describes the Layer 3+ SwitchBlade x8112 Chassis Switch in the following sections:  “AT-SBx8112 Chassis” on page 22  “Slots for the Ethernet Line and Controller Cards” on page 25  “Power Supplies and Power Supply Slots” on page 26 ...

  • Page 22: At-Sbx8112 Chassis

    Chapter 1: Chassis and Power Supplies AT-SBx8112 Chassis The SwitchBlade x8112 product is a modular Layer 3+ Ethernet switch. The main components are the AT-SBx8112 Chassis, Ethernet line cards, a controller card, system power supply, Power over Ethernet Plus (PoE+) power supply, and fan module.

  • Page 23: Figure 2: Front View Of The At-Sbx8112 Chassis

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Slots for Ethernet Slots for Ethernet Line Cards and PoE Power System Power Line Cards and Controller Cards Supply Slots Supply Slots Controller Cards Shipping Brace ESD Wrist AT-SBxFAN12 Strap Plug Module Figure 2.

  • Page 24: Figure 3: Rear View Of The At-Sbx8112 Chassis

    Chapter 1: Chassis and Power Supplies Grounding AC Power Power Supply Cord Sockets Interfaces (Opto-couplers) Figure 3. Rear View of the AT-SBx8112 Chassis Figure 4 is an example of a fully populated chassis. Figure 4. AT-SBx8112 Chassis with Line Cards, Controller Cards, and Power Supplies Section I: Hardware Overview...

  • Page 25: Slots For The Ethernet Line And Controller Cards

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Slots for the Ethernet Line and Controller Cards The chassis has slots for ten Ethernet line cards and two AT- SBx81CFC960 Controller Cards. The slot definitions are predefined and may not be changed. Figure 5 identifies the slots. Slot 2 - ELC Slot 1 - ELC Slot 3 - ELC...

  • Page 26: Power Supplies And Power Supply Slots

    Figure 6. Power Supply Units Note Allied Telesis is discontinuing the AT-SBxPWRSYS1 AC Power Supply and replacing it with the AT-SBxPWRSYS2 AC Power Supply. The power supplies are installed in the four slots across the top of the front of the chassis.

  • Page 27: Figure 7: Power Supply Slots

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Slot A Slot B Slot C Slot D PoE Power PoE Power System Power System Power Supply Supply Supply Supply Figure 7. Power Supply Slots Slots C and D are for system power supplies. The three system power supplies are listed here: ...

  • Page 28: Leds

    The AT-SBxPWRSYS2 AC System Power Supply was added to the management software in release 5.4.5-1. It will work with earlier releases, but Allied Telesis recommends updating the software on controller cards with previous versions to the latest release to ensure full compatibility.

  • Page 29: Table 1. Leds On The At-Sbxpwrsys1 And At-Sbxpwrsys2 Power Supplies

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 1. LEDs on the AT-SBxPWRSYS1 and AT-SBxPWRSYS2 Power Supplies State Description Solid Green The power supply is receiving AC power that is within the normal operating range. The power supply is not receiving power from the AC power source.

  • Page 30: Table 3. Leds On The At-Sbxpwrpoe1 Poe Power Supply

    Chapter 1: Chassis and Power Supplies The LEDs on the AT-SBxPWRPOE1 PoE Power Supply are described in Table 3. Table 3. LEDs on the AT-SBxPWRPOE1 PoE Power Supply State Description Solid Green The power supply is receiving AC power that is within the normal operating range.

  • Page 31: At-Sbxfan12 Module

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide AT-SBxFAN12 Module The AT-SBxFAN12 Module, shown in Figure 8, is the cooling unit for the chassis. It is a field- replaceable assembly that is factory installed and shipped with the AT-SBx8112 Chassis. The module is controlled by the AT-SBx81CFC960 Controller Fabric Card.

  • Page 32: Power Supply Interfaces (Opto-Couplers)

    Chapter 1: Chassis and Power Supplies Power Supply Interfaces (Opto-couplers) The chassis has two power supply interfaces, also referred to as opto- couplers, in the lower right corner on the rear panel. The interfaces, labeled Power Supply Interface, are used by the active master controller card to obtain status information from the power supplies.

  • Page 33: Table 5. Power Led On The Power Supply Interface

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 5. Power LED on the Power Supply Interface State Description Solid Green The interface is operating normally. Here are the possible conditions for this LED state:  The corresponding power supply slots of the interface are empty.
  • Page 34 Chapter 1: Chassis and Power Supplies Section I: Hardware Overview...

  • Page 35: Chapter 2: Ethernet Line Cards

    “AT-SBx81GP24 PoE Line Card” on page 44  “AT-SBx81GS24a SFP Line Card” on page 47  “AT-SBx81GC40 SFP and CSFP Line Card” on page 49  “AT-SBx81XS6 SFP+ Line Card” on page 55  “AT-SBx81XS16 SFP+ Line Card” on page 57 ...

  • Page 36: Ethernet Line Cards

    PoE+. AT-SBx81GS24a SFP Ethernet Card with 24 ports for 100 or 1000Mbps, fiber optic or twisted pair SFP transceivers. AT-SBx81GC40 Ethernet Card with 20 ports for 1000Mbps standard SFP or compact SFP (CSFP) BiDi transceivers. AT-SBx81XS6 SFP+ Ethernet Card...

  • Page 37: Figure 11: Expansion Modules For The At-Sbx81Xlem Line Card

    Table 6 lists the types of transceivers and cables supported by line cards and expansion modules with transceiver ports. For a list of transceivers, refer to the SwitchBlade x8112 data sheet on the Allied Telesis web site. Table 6. Transceiver and Cable Support...
  • Page 38 Chapter 2: Ethernet Line Cards Table 6. Transceiver and Cable Support (Continued) 100Mbps 1Gbps Device 1Gbps SFP 40Gbps 10Gbps CSFP BiDi AT-SBx81XLEM/ XS8 Expansion Module AT-SBx81XLEM/ Q2 Expansion Module 1. The line cards support 10Gbps, fiber optic SFP+ transceivers or AT-SP10TW Twinax direct connect cables.

  • Page 39: At-Sbx81Gt24 Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide AT-SBx81GT24 Line Card The AT-SBx81GT24 Line Card, shown in Figure 12, is a Gigabit Ethernet switch. Figure 12. AT-SBx81GT24 Line Card Here are the main features of the line card:  24 10/100/1000Base-T ports ...

  • Page 40: Figure 13: Port Leds On The At-Sbx81Gt24 Line Card

    Chapter 2: Ethernet Line Cards Figure 13. Port LEDs on the AT-SBx81GT24 Line Card Table 7. Port LEDs on the AT-SBx81GT24 Line Card State Description Solid Green The port has established an 1000 Mbps link to a network device. Flashing The port is transmitting or receiving data at Green 1000 Mbps.

  • Page 41: At-Sbx81Gt40 Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide AT-SBx81GT40 Line Card The AT-SBx81GT40 Line Card, shown in Figure 14, is a Gigabit Ethernet switch. Figure 14. AT-SBx81GT40 Line Card Here are the main features of the line card:  40 10/100/1000Base-T ports ...

  • Page 42: Leds

    Chapter 2: Ethernet Line Cards LEDs The LEDs for a port on the AT-SBx81GT40 Line Card are found on the RJ point 5 cable connector. The LEDs are shown in Figure 15. LEDs Figure 15. Port LEDs on an RJ Point 5 Cable Connector for the AT- SBx81GT40 Line Card Only the left LED is active.

  • Page 43: Table 8. Port Leds On The At-Sbx81Gt40 Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 8. Port LEDs on the AT-SBx81GT40 Line Card State Description Solid Green The port has established an 1000 Mbps link to a network device. Flashing The port is transmitting or receiving data at Green 1000 Mbps.

  • Page 44: At-Sbx81Gp24 Poe Line Card

    Chapter 2: Ethernet Line Cards AT-SBx81GP24 PoE Line Card The AT-SBx81GP24 PoE Line Card, shown in Figure 17, is a Gigabit Ethernet switch with Power over Ethernet Plus (PoE+) on all the ports. Figure 17. AT-SBx81GP24 PoE Line Card Here are the main features of the line card: ...

  • Page 45: Leds

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide LEDs Each port on the AT-SBx81GP24 PoE Line Card has two LEDs. The LEDs are shown in Figure 18 and described in Table 9. Figure 18. Port LEDs on the AT-SBx81GP24 PoE Line Card Table 9.
  • Page 46 Chapter 2: Ethernet Line Cards Table 9. Port LEDs on the AT-SBx81GP24 PoE Line Card (Continued) State Description This LED state can result from the following conditions:  The port is not connected to a PD.  The PD is powered off. ...

  • Page 47: At-Sbx81Gs24A Sfp Line Card

     Hot swappable For a list of supported transceivers, refer to the SwitchBlade x8100 data sheet on the Allied Telesis web site. LEDs The SFP ports on the AT-SBx81GS24a SFP Line Card have one LED each, as shown in Figure 20 on page 48 and described in Table 10 on page 48.

  • Page 48: Figure 20: Port Leds On The At-Sbx81Gs24A Sfp Line Card

    Chapter 2: Ethernet Line Cards Figure 20. Port LEDs on the AT-SBx81GS24a SFP Line Card Table 10. Port LEDs on the AT-SBx81GS24a SFP Line Card LED State Description The SFP transceiver in the port has established a Solid Amber 10 or 100 Mbps link to a network device. The SFP transceiver is transmitting and/or Blinking Amber receiving data at 10 or 100 Mbps.

  • Page 49: At-Sbx81Gc40 Sfp And Csfp Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide AT-SBx81GC40 SFP and CSFP Line Card The AT-SBx81GC40 Line Card, shown in Figure 21, is a Gigabit Ethernet switch. Figure 21. AT-SBx81GC40 Line Card Here are the main features:  20 ports for 1000Mbps, standard SFP or compact SFP (CSFP) bidirectional (BiDi) transceivers ...

  • Page 50: Port Numbers

    The AT-SBx81GC40 Line Card does not support 10 or 100 Mbps transceivers. The AT-SBx81GC40 Line Card has 20 ports for standard SFP or CSFP transceivers, and supports 20 or 40 networking ports, depending on the types of transceivers. The line card has 20 ports when the ports have standard SFP transceivers, because each SFP transceiver functions as one port.

  • Page 51: Figure 22: Port Numbers With Csfp Transceivers

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Port 1 Port 3 Port 2 Port 4 Figure 22. Port Numbers with CSFP Transceivers In contrast, the two connectors on an SFP transceiver function as a single port, not as individual ports. Consequently, the switch assigns that type of module one port number instead of two.

  • Page 52: Leds

    Figure 23. Port Numbers for Standard SFP Transceivers LEDs The AT-SBx81GC40 Line Card has two LEDs for each port. The LEDs, which display link and activity information, are located between the ports, in sets of four. The first and third LEDs of each set are for the bottom port and the second and fourth LEDs are for the top port, as shown in Figure 24.

  • Page 53: Figure 25: Leds For The At-Sbx81Gc40 Line Card, With Csfp Transceivers

    Figure 26. Port 1 Not used L/A LED Port 4 Not Used L/A LED Figure 26. LEDs for the AT-SBx81GC40 Line Card, with SFP Transceivers The LED states are described in Table 11 on page 54. Section I: Hardware Overview...

  • Page 54: Table 11. Transceiver Port Leds On The At-Sbx81Gc40 Line Card

    Chapter 2: Ethernet Line Cards Table 11. Transceiver Port LEDs on the AT-SBx81GC40 Line Card State Description Solid Green The SFP transceiver or CSFP transceiver fiber port has established a link with a network device. Flashing The SFP transceiver or CSFP transceiver fiber Green port is transmitting or receiving data.

  • Page 55: At-Sbx81Xs6 Sfp+ Line Card

     Hot swappable For a list of supported transceivers, refer to the SwitchBlade x8100 data sheet on the Allied Telesis web site. LEDs The AT-SBx81XS6 Line Card has one LED for each SFP+ port. The LED is shown in Figure 28 and described in Table 12 on page 56.

  • Page 56: Table 12. Sfp+ Port Leds On The At-Sbx81Xs6 Line Card

    Chapter 2: Ethernet Line Cards Table 12. SFP+ Port LEDs on the AT-SBx81XS6 Line Card State Description Solid Green The transceiver has established a link with a network device. Flashing The transceiver is transmitting or receiving data at Green 10 Gbps. This LED state can result from the following conditions: ...

  • Page 57: At-Sbx81Xs16 Sfp+ Line Card

     Hot swappable For a list of supported transceivers, refer to the SwitchBlade x8100 data sheet on the Allied Telesis web site. Note The AT-SBx81XS16 Line Card is supported in slots 1 to 4, 8, and 10 in the AT-SBx8112 Chassis. The card is not supported in slots 7, 9, 11, and 12.

  • Page 58: Figure 30: Sfp+ Port Leds On The At-Sbx81Xs16 Line Card

    Chapter 2: Ethernet Line Cards Top SFP+ Port LED Bottom SFP+ Port LED Figure 30. SFP+ Port LEDs on the AT-SBx81XS16 Line Card Table 13. SFP+ Port LEDs on the AT-SBx81XS16 Line Card State Description Solid Green The transceiver has established a 10 Gbps link with a network device.

  • Page 59: At-Sbx81Xlem Sfp Line Card

     Hot swappable For a list of supported transceivers, refer to the SwitchBlade x8100 data sheet on the Allied Telesis web site. Note The AT-SBx81XLEM SFP Line Card is hot swappable. However, installing, removing, or replacing an expansion module requires removing the line card from the chassis.

  • Page 60: Large Address Table Modes

    Chapter 2: Ethernet Line Cards Card is supported in all ten line card slots in the AT-SBx8112 Chassis. The bandwidth of the card differs depending on the slot. The card operates at its highest bandwidth in slots 1 to 4, 8, and 10, and at a lower bandwidth in slots 7, 9, 11, and 12.

  • Page 61: Leds

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide  The large table modes require the AT-SBx81CFC960 Controller Fabric Card. The AT-SBx81CFC400 Controller Fabric Card does not support the large table modes. For descriptions of the large table modes and how to activate them, refer to “Command Reference: SwitchBlade x8100 Series Switches and AlliedWare Plus.”...

  • Page 62: At-Sbx81Xlem/Gt8 Expansion Module

    Chapter 2: Ethernet Line Cards AT-SBx81XLEM/GT8 Expansion Module The AT-SBx81XLEM/GT8 Module is an expansion module for the AT- SBx81XLEM Line Card. Refer to Figure 33. Figure 33. AT-SBx81XLEM/GT8Expansion Module The main features of the module are listed here:  Eight 10/100/1000Base-T ports ...

  • Page 63: Table 15. Port Leds On The At-Sbx81Xlem/Gt8 Module

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 15. Port LEDs on the AT-SBx81XLEM/GT8 Module State Description Solid Green The port has established an 1000 Mbps link to a network device. Flashing The port is transmitting or receiving data at Green 1000 Mbps.

  • Page 64: At-Sbx81Xlem/Q2 Expansion Module

    For a list of supported transceivers, refer to the SwitchBlade x8100 data sheet on the Allied Telesis web site. Each port has one LED. The states of the LED are described in Table 16. Table 16. QSFP+ Port LEDs for the AT-SBx81XLEM/Q2 Expansion...
  • Page 65 The port is empty or the transceiver has not established a link to a network device. Note The AT-SBx81XLEM/Q2 Module does not support 40G DAC auto- negotiation. Allied Telesis recommends disabling auto-negotiation on transceiver link partners to ensure proper operation. Section I: Hardware Overview...

  • Page 66: At-Sbx81Xlem/Xs8 Expansion Module

    Jumbo frame support up to 10240 bytes For a list of supported transceivers, refer to the SwitchBlade x8100 data sheet on the Allied Telesis web site. Each port has one LED. The LED states are defined in Table 17. Table 17. Port LEDs on the AT-SBx81XLEM/XS8 Module...
  • Page 67 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 17. Port LEDs on the AT-SBx81XLEM/XS8 Module (Continued) LED State Description The transceiver is transmitting and/or receiving Blinking Green data at 10Gbps. The port is empty or the transceiver has not established a link to a network device.

  • Page 68: At-Sbx81Xlem/Xt4 Expansion Module

    Chapter 2: Ethernet Line Cards AT-SBx81XLEM/XT4 Expansion Module The AT-SBx81XLEM/XT4 Module is an expansion module for the AT- SBx81XLEM Line Card. Refer to Figure 36. Figure 36. AT-SBx81XLEM/XT4 Expansion Module The main features of the module are listed here:  Four ports with RJ-45 connectors for twisted pair cables ...
  • Page 69 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 18. Port LEDs on the AT-SBx81XLEM/XT4 Module (Continued) LED State Description The port is not connected to a network device or the device is not powered on. Section I: Hardware Overview...

  • Page 70: Twisted Pair Ports

    Chapter 2: Ethernet Line Cards Twisted Pair Ports This section applies to the twisted pair ports on the following line cards and expansion modules:  AT-SBx81GT24 Ethernet Line Card  AT-SBx81GT40 Ethernet Line Card  AT-SBx81GP24 Ethernet Line Card  AT-SBx81XLEM/XT4 Expansion Module ...

  • Page 71: Maximum Distance

    Note Patch cables for the AT-SBx81GT40 Line Card, in lengths of 1 meter and 3 meters with RJ point 5 and RJ-45 connectors, are available from Allied Telesis. Contact your Allied Telesis sales representative for information. Automatic MDIX The 10/100/1000 Mbps twisted-pair ports on the AT-SBx81GT24, AT- SBx81GT40, and AT-SBx81GP24 Line Cards are IEEE 802.3ab compliant...
  • Page 72 Chapter 2: Ethernet Line Cards when they operate at 10 or 100 Mbps in the MDI configuration and Table 49 on page 366 for the MDI-X configuration. For the port pinouts when they operate at 1000 Mbps or 10 Gbps, refer to Table 50 on page 366.

  • Page 73: Power Over Ethernet On The Ports In The At-Sbx81Gp24 Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Power over Ethernet on the Ports in the AT-SBx81GP24 Line Card This section applies to the AT-SBx81GP24 PoE Line Card. The twisted- pair ports on the line card support Power over Ethernet (PoE). PoE is a mechanism by which the ports supply power to network devices over the twisted pair cables that carry the network traffic.

  • Page 74: Power Budget

    Chapter 2: Ethernet Line Cards Power Budget The power for PoE on the ports on the AT-SBx81GP24 Line Card is provided by the AT-SBxPWRPOE1 Power Supply. A single power supply can provide up to 1200 watts of power for powered devices. You may install two power supplies in the chassis for a total of 2400 watts for powered devices.
  • Page 75 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide A. Power is transmitted on strands 1, 2, 3, and 6. Thus, the line card can support PDs that receive power using Alternative A. PDs that comply with the IEEE 802.3af and 802.3at standards are required to support both power delivery methods.
  • Page 76 Chapter 2: Ethernet Line Cards Section I: Hardware Overview...

  • Page 77: Chapter 3: At-Sbx81Cfc960 Controller Fabric Cards

    Chapter 3 AT-SBx81CFC960 Controller Fabric Cards This chapter describes the AT-SBx81CFC960 Controller Fabric Card in the following sections:  “Controller Fabric Cards for the AT-SBx8112 Chassis” on page 78  “Front Panel Components” on page 80  “Guidelines” on page 82 ...

  • Page 78: Controller Fabric Cards For The At-Sbx8112 Chassis

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards Controller Fabric Cards for the AT-SBx8112 Chassis Listed here are the two controller fabric cards for the AT-SBx8112 Chassis:  AT-SBx81CFC400  AT-SBx81CFC960 They are shown in Figure 37. AT-SBx81CFC400 Controller Fabric Card AT-SBx81CFC960 Controller Fabric Card Figure 37.
  • Page 79 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Note The AT-SBx81CFC400 and AT-SBx81CFC960 Controller Cards are not compatible. Do not install them in the same chassis. Section I: Hardware Overview...

  • Page 80: Front Panel Components

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards Front Panel Components The front panel components on the controller fabric card are identified in Figure 38 and briefly described in Table 21 on page 80. eco-friendly Button Status Four Ports for 10Gbps SFP+ SBx Linecard Status LEDs LEDs...
  • Page 81 - Stack trunk between two chassis for the VCStack Plus feature. Transceivers are ordered separately. For a list of supported transceivers, refer to the Allied Telesis web site. For more information, refer to “SFP+ Ports” on page 90. Console RS-232 Port Provides local management of the switch.

  • Page 82: Guidelines

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards Guidelines The controller card has the following functions: —  Chassis Management You use the controller card to monitor and configure the parameter settings on the Ethernet line cards. The controller card supports local management sessions through the Console RS-232 port and remote management sessions with Telnet, Secure Shell (SSH), or SNMP clients on workstations on your network.
  • Page 83 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide  The chassis can have either one or two controller cards.  Two controller cards are recommended for redundancy and to increase the per slot backplane bandwidth from up to 80 to 160Gbps.

  • Page 84: Dual Controller Cards

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards Dual Controller Cards You can install either one or two controller cards in the chassis. Here are the advantages to having two controller cards in the chassis.  Having a second controller card improves the performance of the chassis by increasing the backplane bandwidth for the Ethernet line cards.
  • Page 85 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide The active master controller in a chassis with two controller cards is typically the card in slot 5. It manages the system and processes CPU bound network traffic. The standby master runs all network protocol modules and is kept in sync with the active master card, so as to be available in hot-standby for near instantaneous fail over, if required.

  • Page 86: Sys Status Leds

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards SYS Status LEDs The SYS (System) Status LEDs on the controller fabric card display general status information about the controller card, power supplies, and fan module. The LEDs are defined in Table 22 on page 86. Table 22.
  • Page 87 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 22. SYS (System) Status LEDs (Continued) State Description Solid Green Indicates that the fan module is operating properly. Flashing Indicates that the fan module has a problem. The Amber fans are operating below the normal operating range or have stopped.

  • Page 88: Eco-Friendly Button

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards eco-friendly Button You can use the eco-friendly button on the controller card to turn the LEDs on or off. You may turn off the LEDs when you are not using them to monitor the control and Ethernet line cards, to conserve electricity. When the LEDs are off, the overall power consumption of the chassis is slightly reduced, approximately 3 watts in a system with 240 active copper ports.

  • Page 89: Sbx Linecard Status Leds

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide SBx Linecard Status LEDs The SBx Linecard Status LEDs, numbered 1 to 12, display general status information about the Ethernet line cards and controller cards. There is one LED for each chassis slot. If the chassis has two controller cards, the SBx Status LEDs on both cards are active.

  • Page 90: Sfp+ Ports

     You must use direct connect twinax cables or SFP+ transceivers from Allied Telesis to use the ports as the stack trunk for the VCStack Plus feature. The two chassis might not form the stack with cables or transceivers from other network equipment manufacturers.

  • Page 91: Table 24. Leds For The Sfp+ Ports On The At-Sbx81Cfc960 Controller Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 24. LEDs for the SFP+ Ports on the AT-SBx81CFC960 Controller Card State Description Solid Green The transceiver has established a 10Gbps link with a network device. Flashing The transceiver is transmitting or receiving data at Green 10Gbps.

  • Page 92: Console (Rs-232) Port

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards Console (RS-232) Port The Console Port is used to conduct local management sessions with the switch. Local management sessions are established with a terminal or PC with a terminal emulation program, and the management cable that comes with the card.

  • Page 93: Ethernet Management Port (Net Mgmt)

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Ethernet Management Port (NET MGMT) The controller card uses the NET MGMT port as a separate routed eth0 interface. The interface is not part of the switching matrix of the Ethernet line cards, but the CPU on the controller card can route traffic in or out of the port from the line cards.

  • Page 94: Table 25. Net Mgmt Port Led

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards Table 25. NET MGMT Port LED State Description Solid Green The port has a valid 1000 Mbps link. Flashing The port is transmitting or receiving data at Green 1000 Mbps. Solid Amber The port has a valid 10 or 100 Mbps link. Flashing The port is transmitting or receiving data at Amber...

  • Page 95: Usb Port

    The USB port supports a flash drive. You may use a flash drive to perform the following management functions:  Use Allied Telesis Management Framework to provide a centralized network backup location.  Store backup copies of the configuration files on the AT- SBx81CFC960 Controller Fabric Card.

  • Page 96: Reset Button

    Chapter 3: AT-SBx81CFC960 Controller Fabric Cards Reset Button You can use the Reset button to reset either the controller card or all of the cards in the chassis. The action depends on the number of AT- SBx81CFC960 Controller Cards in the chassis and, if the chassis has two controller cards, whether you reset the active or standby master controller card.
  • Page 97 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Note To reset individual line cards in the chassis, use the REBOOT or RELOAD command in the AlliedWare Plus Operating System. Section I: Hardware Overview...

  • Page 98: Alliedware Plus Software Releases For The Hardware Products

    5.4.2 AT-SBx81GT40 Line Card 5.4.3 AT-SBx81XS16 Line Card 5.4.4 AT-SBx81XLEM Line Card 5.4.6 AT-SBx81XLEM Line Card with 5.4.6-1.1 large address table modes AT-SBx81GC40 Line Card 5.4.9 AT-SBx81XLEM Expansion Modules AT-SBx81XLEM/Q2 Expansion 5.4.6 Module AT-SBx81XLEM/XS8 Expansion 5.4.6 Module AT-SBx81XLEM/XT4 Expansion 5.4.6-1.1...
  • Page 99 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 26. AlliedWare Plus Operating System Releases for the Hardware Products (Continued) Product Initial Release Power Supplies and Fan Module AT-SBxPWRSYS1 AC System 5.4.2 Power Supply AT-SBxPWRPOE1 PoE Power 5.4.2 Supply AT-SBxFAN12 Fan Module 5.4.2 AT-SBxPWRSYS1 DC System...
  • Page 100 Chapter 3: AT-SBx81CFC960 Controller Fabric Cards Section I: Hardware Overview...

  • Page 101: Section Ii: Installing The Chassis

    Section II Installing the Chassis This section contains the following chapters:  Chapter 4, “Safety Precautions and Site Requirements” on page 103  Chapter 5, “Installing the Chassis in an Equipment Rack” on page 111  Chapter 6, “Installing the Power Supplies” on page 127 ...

  • Page 103: Chapter 4: Safety Precautions And Site Requirements

    Chapter 4 Safety Precautions and Site Requirements This chapter contains the safety precautions and guidelines for selecting a site for the chassis. The chapter contains the following sections:  “Reviewing Safety Precautions” on page 104  “Selecting a Site for the SwitchBlade x8112” on page 108 ...

  • Page 104: Reviewing Safety Precautions

    Chapter 4: Safety Precautions and Site Requirements Reviewing Safety Precautions Please review the following safety precautions before you begin to install the switch. Note The  indicates that a translation of the safety statement is available for viewing in portable document format (PDF) titled Translated Safety Statements from our web site at www.alliedtelesis.com/support.
  • Page 105 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Note Pluggable Equipment. The socket outlet shall be installed near the equipment and shall be easily accessible.  E5 Caution Air vents must not be blocked and must have free access to the room ambient air for cooling.
  • Page 106 Remove all metal jewelry, such as rings and watches, before installing or removing a line card from a powered-on chassis.  Warning The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E28 Warning This unit might have more than one power cord.
  • Page 107 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Warning To reduce the risk of electric shock, the PoE ports on this product must not connect to cabling that is routed outside the building where this device is located.  E40 Warning This product may have multiple AC power cords installed.

  • Page 108: Selecting A Site For The Switchblade X8112

    Chapter 4: Safety Precautions and Site Requirements Selecting a Site for the SwitchBlade x8112 Please perform the following procedure to determine the suitability of the site for the chassis: 1. Verify that the equipment rack is safely secured so that it will not tip over.

  • Page 109: Figure 39: 100 - 125 Vac 125 V Nema 5-20 Plug And Receptacle

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 39. 100 - 125 VAC 125 V NEMA 5-20 Plug and Receptacle Section II: Installing the Chassis...

  • Page 110: Installation Tools And Material

    Chapter 4: Safety Precautions and Site Requirements Installation Tools and Material Here are the installation tools and material you need to have to install the product. Installing the chassis in an equipment rack requires the following items:  #2 Phillips-head screwdriver ...

  • Page 111: Chapter 5: Installing The Chassis In An Equipment Rack

    Chapter 5 Installing the Chassis in an Equipment Rack This chapter describes how to install the AT-SBx8112 Chassis in an equipment rack. This chapter contains the following sections:  “Required Tools and Material” on page 112  “Preparing the Equipment Rack” on page 113 ...

  • Page 112: Required Tools And Material

     #2 Phillips-head 20 inch-lbs torque screwdriver (optional) Warning The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E30 Section II: Installing the Chassis...

  • Page 113: Preparing The Equipment Rack

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Preparing the Equipment Rack This section explains how to prepare the equipment rack for the chassis. The procedure requires the following items:  #2 Phillips-head screwdriver (not provided)  Two equipment rack screws (not provided) To prepare the equipment rack for the AT-SBx8112 Chassis, perform the following procedure: Caution...

  • Page 114: Figure 40: Reserving Vertical Rack Space

    Chapter 5: Installing the Chassis in an Equipment Rack Figure 40. Reserving Vertical Rack Space Section II: Installing the Chassis...

  • Page 115: Figure 41: Rack Mounting Hole Locations

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 3. Identify the lowest 1/2” screw hole pattern on the rack mounting rails within the space reserved for the AT-SBx8112 Chassis. 4. Install one rack mount screw in each vertical rail, at the same height in the top screw hole of the lowest 1/2”...

  • Page 116: Unpacking The At-Sbx8112 Chassis

    2. Verify the contents of the shipping container by referring to Figure 42 here and Figure 43 on page 117. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. One AT-SBx8112 Chassis One AT-SBxFAN12 Module pre-...

  • Page 117: Figure 43: Components Of The At-Sbx8112 Chassis (Continued)

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Two equipment rack brackets pre-installed on the sides of the chassis. One shipping brace pre-installed diagonally across the line card slots on the front panel One wrist strap Figure 43. Components of the AT-SBx8112 Chassis (Continued) Section II: Installing the Chassis...

  • Page 118: Adjusting The Equipment Rack Brackets

    Chapter 5: Installing the Chassis in an Equipment Rack Adjusting the Equipment Rack Brackets The chassis has two pre-installed equipment rack brackets. You may adjust the brackets so that the front of the chassis is flush with, extends beyond, or is recessed behind the front of the equipment rack. You may also install the brackets so that the rear panel of the chassis is flush with the front of the equipment rack.

  • Page 119: Figure 44: Rack Mounting Bracket Locations

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Factory Installed - Flush with Rack Rails “Dim X” “Dim X” “Dim X” “Dim X” Figure 44. Rack Mounting Bracket Locations Figure 45. Rack Bracket Locations for Reverse Position of Chassis Section II: Installing the Chassis...

  • Page 120: Installing The At-Sbx8112 Chassis In The Equipment Rack

    Warning The chassis may be heavy and awkward to lift. Allied Telesis recommends that you get assistance when mounting the chassis in an equipment rack.  E30...

  • Page 121: Figure 46: Lifting The At-Sbx8112 Chassis Into The Equipment Rack

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 2. Lift the AT-SBx8112 Chassis into the equipment rack and set the bottom of the equipment rack brackets firmly on the two equipment rack screws you installed in “Preparing the Equipment Rack” on page 113, as shown in Figure 46.

  • Page 122: Figure 47: Installing The Rack Mount Screws

    Figure 47. Installing the Rack Mount Screws 5. Tighten all eight screws to secure the chassis to the equipment rack, Allied Telesis recommends tightening the screws to 10 inch-lbs. 6. Go to “Removing the Shipping Brace” on page 123. Section II: Installing the Chassis...

  • Page 123: Removing The Shipping Brace

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Removing the Shipping Brace Now that the chassis is installed in the equipment rack, you may remove the shipping brace from the front of the unit. To remove the shipping brace, remove the six mounting screws with a #2 Phillips-head screwdriver (not provided).

  • Page 124: Installing The Chassis Grounding Wire

    Chapter 5: Installing the Chassis in an Equipment Rack Installing the Chassis Grounding Wire This procedure explains how to connect a grounding wire to the chassis. The chassis requires a permanent connection for the line cards and power supplies to a good earth ground. The procedure requires the following items: ...

  • Page 125: Figure 51: Attaching The Grounding Wire To The Grounding Lug

    4. Install the grounding lug on the rear panel of the chassis, as shown in Figure 52. Allied Telesis recommends tightening the screws to 20 inch-lbs. Figure 52. Installing the Grounding Lug and Wire 5. Connect the other end of the grounding wire to the building protective earth.
  • Page 126 Chapter 5: Installing the Chassis in an Equipment Rack Section II: Installing the Chassis...

  • Page 127: Chapter 6: Installing The Power Supplies

    Chapter 6 Installing the Power Supplies This chapter explains how to install the power supplies. It has the following sections:  “Protecting Against Electrostatic Discharge (ESD)” on page 128  “Installing AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supplies” on page 129 ...

  • Page 128: Protecting Against Electrostatic Discharge (Esd)

    Chapter 6: Installing the Power Supplies Protecting Against Electrostatic Discharge (ESD) To protect the equipment from damage by Electrostatic Discharge (ESD) during the installation procedure, observe proper ESD protection when handling the SwitchBlade x8112 line cards and power supplies. You should be properly grounded with a wrist or foot strap.

  • Page 129: Installing At-Sbxpwrsys1 Or At-Sbxpwrsys2 Ac System Power Supplies

    System power supplies are installed in slots C and D in the chassis. Refer to Figure 54 on page 130. If you are installing only one power supply, you may install it in either slot, but Allied Telesis recommends slot D because the slot does not come with a blank power supply panel.

  • Page 130: Figure 54: Power Supply Slots

    Chapter 6: Installing the Power Supplies AT-SBxPWRSYS1 AT-SBxPWRPOE1 or AT-SBxPWRSYS2 Power Supply Slots Power Supply Slots Figure 54. Power Supply Slots Caution The AT-SBxPWRSYS1 and AT-SBxPWRSYS2 AC System Power Supplies will not work in slot A or B. 2. If the chassis already has a power supply in slot D, remove the blank power supply panel from slot C by lifting the blank panel handle and sliding it out of the slot, as shown in Figure 55.

  • Page 131: Figure 56: Items Included With The At-Sbxpwrsys1 Or At-Sbxpwrsys2 Ac System Power Supply

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 3. Remove the new power supply from the shipping package and verify the package contents, listed in Figure 56. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. One AT-SBxPWRSYS1 or...

  • Page 132: Figure 57: Unlocking The Handle On The Power Supply

    Chapter 6: Installing the Power Supplies 4. Move the locking handle on the power supply to the unlocked or up position. See Figure 57. Figure 57. Unlocking the Handle on the Power Supply 5. Align and insert the power supply into the power supply slot. Figure 58 shows the power supply installed in slot D.

  • Page 133: Figure 59: Lowering The Handle On The At-Sbxpwrsys1 Or At-Sbxpwrsys2 Ac System Power Supply

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 6. Lower the power supply locking handle to secure the power supply to the chassis, as shown in Figure 59. Figure 59. Lowering the Handle on the AT-SBxPWRSYS1 or AT- SBxPWRSYS2 AC System Power Supply Note If the module does not fully seat in the chassis slot, check to be sure you are installing a system power supply and not a PoE power...
  • Page 134 Chapter 6: Installing the Power Supplies Note Retain the tie wrap that comes with the power supply. You will use it to secure the power cord to the chassis when you power on the unit in “Powering On AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supplies”...

  • Page 135: Installing At-Sbxpwrpoe1 Poe Power Supplies

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Installing AT-SBxPWRPOE1 PoE Power Supplies This section contains the installation procedure for the AT-SBxPWRPOE1 Power Supply, for the PoE+ ports on the AT-SBx81GP24 PoE Line Card. For background information, refer to “Power Supplies and Power Supply Slots”...

  • Page 136: Figure 60: Removing The Blank Slot Cover From Power Supply Slot A

    3. Remove the power supply from the shipping package and verify that the shipping package contains the items listed in Figure 61 on page 137. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. Section II: Installing the Chassis...

  • Page 137: Figure 61: Items Included With The At-Sbxpwrpoe1 Power Supply Module

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide One AT-SBxPWRPOE1 Power Supply Module One regional AC power cord One tie wrap Figure 61. Items Included with the AT-SBxPWRPOE1 Power Supply Module Note Store the packaging material in a safe location. You must use the original shipping material if you need to return the unit to Allied Telesis.

  • Page 138: Figure 62: Unlocking The Handle On The At-Sbxpwrpoe1 Power Supply

    Chapter 6: Installing the Power Supplies Figure 62. Unlocking the Handle on the AT-SBxPWRPOE1 Power Supply 5. Align and insert the AT-SBxPWRPOE1 Module into slot A or B. Figure 63 shows the power supply module aligned in slot A. Caution The AT-SBxPWRPOE1 AC Power Supply will not work in slot C or Figure 63.

  • Page 139: Figure 64: Locking The Handle On The At-Sbxpwrpoe1 Power Supply

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 6. Lower the locking handle of the power supply module to secure the module in the slot, as shown in Figure 64. Figure 64. Locking the Handle on the AT-SBxPWRPOE1 Power Supply Note If the module does not fully seat in the chassis slot, check to be sure you are installing a PoE power supply and not a system power...

  • Page 140: Installing At-Sbxpwrsys1 Dc System Power Supplies

    System power supplies are installed in slots C and D in the chassis. Refer to Figure 54 on page 130. If you are installing only one power supply, you may install it in either slot, but Allied Telesis recommends slot D because the slot does not come with a blank power supply panel.

  • Page 141: Figure 65: Removing The Blank Slot Cover From Power Supply Slot C

    3. Remove the power supply from the shipping package and verify that the shipping package contains the items listed in Figure 66 on page 142. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. Section II: Installing the Chassis...

  • Page 142: Figure 66: Items Included With The At-Sbxpwrsys1 Dc Power Supply Module

    Chapter 6: Installing the Power Supplies One AT-SBxPWRSYS1 DC System Power Supply Two straight power wire ring lugs One grounding wire ring lug Two right angle power wire ring lugs Figure 66. Items Included with the AT-SBxPWRSYS1 DC Power Supply Module Note Store the packaging material in a safe location.

  • Page 143: Figure 67: On/Off Switch On The At-Sbxpwrsys1 Dc Power Supply

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide On/Off Switch Figure 67. On/Off Switch on the AT-SBxPWRSYS1 DC Power Supply 5. With a #2 Phillips-head screwdriver, loosen the handle locking screw on the power supply, as shown in Figure 68. Figure 68.

  • Page 144: Figure 69: Raising Handle On The At-Sbxpwrsys1 Dc Power Supply

    Chapter 6: Installing the Power Supplies Figure 69. Raising Handle on the AT-SBxPWRSYS1 DC Power Supply 7. Align and insert the AT-SBxPWRSYS1 Module into slot C or D. Figure 70 shows the power supply installed in slot D. Caution The AT-SBxPWRSYS1 DC System Power Supply will not work in slot A or B.

  • Page 145: Figure 71: Locking The Handle On The At-Sbxpwrsys1 Dc System Power Supply

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 8. Lower the locking handle of the power supply module to secure the module in the slot, as shown in Figure 71. Figure 71. Locking the Handle on the AT-SBxPWRSYS1 DC System Power Supply Note Do not tighten the handle locking screw yet.
  • Page 146 Chapter 6: Installing the Power Supplies Section II: Installing the Chassis...

  • Page 147: Chapter 7: Installing At-Sbx81Cfc960 Controller Cards And Ethernet Line Cards

    Chapter 7 Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards This chapter describes how to install the controller and Ethernet line cards. The chapter has the following sections:  “Guidelines to Handling the Controller and Line Cards” on page 148 ...

  • Page 148: Guidelines To Handling The Controller And Line Cards

    Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards Guidelines to Handling the Controller and Line Cards Please observe the following guidelines when handling controller cards, Ethernet line cards, and expansion modules:  The controller and line cards are hot swappable and can be installed or removed while the chassis is powered on.

  • Page 149: Figure 72: Aligning A Card In A Slot

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide CORRECT INCORRECT INCORRECT Figure 72. Aligning a Card in a Slot Section II: Installing the Chassis...

  • Page 150: Installing At-Sbx81Cfc960 Controller Fabric Cards

    1. Choose a slot in the chassis for the AT-SBx81CFC960 Controller Fabric Card. The cards are installed in slots 5 and 6, shown in Figure 73. If you are installing only one controller card, Allied Telesis recommends installing it in slot 5. Slot 6 Slot 5 Figure 73.

  • Page 151: Figure 74: Items Included With The At-Sbx81Cfc960 Controller Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 2. Remove the new AT-SBx81CFC960 Controller Fabric Card from the shipping package and verify the package contents, listed in Figure 74. If any item is missing or damaged, contact your Allied Telesis sales representative for assistance. One AT-SBx81CFC960 Control Card One 2 m (6.6 ft) local...

  • Page 152: Figure 76: Removing The Battery Insulator

    Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards 4. Carefully remove the battery insulator tab on the controller card by sliding it out from between the battery and battery clip, as shown in Figure 76. Figure 76. Removing the Battery Insulator 5.

  • Page 153: Figure 78: Aligning The At-Sbx81Cfc960 Card In The Chassis Slot

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 78. Aligning the AT-SBx81CFC960 Card in the Chassis Slot 7. Carefully slide the card into the slot. Caution Keep the card level with the chassis as you slide it into the slot. You might damage the components on the top or bottom of the card if you slide it in at an angle.

  • Page 154: Figure 79: Closing The Locking Levers On The At-Sbx81Cfc960 Controller Fabric Card

    Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards Figure 79. Closing the Locking Levers on the AT-SBx81CFC960 Controller Fabric Card 9. Finger tighten the two thumbscrews on the card to secure the card to the chassis, as shown in Figure 80 on page 155. Section II: Installing the Chassis...

  • Page 155: Figure 80: Tightening The Thumb Screws On The At-Sbx81Cfc960 Card

    10. Tighten the screws with a # 2 Phillips-head screwdriver to secure the controller card to the chassis. Allied Telesis recommends tightening the screws to 5 inch-lbs. 11. if the chassis is to have two AT-SBx81CFC960 Controller Fabric Cards, repeat this procedure to install the second card.

  • Page 156: Installing Expansion Modules In At-Sbx81Xlem Ethernet Line Cards

    To install an expansion module in the AT-SBx81XLEM Ethernet Line Card, perform the following procedure: 1. Remove the AT-SBx81XLEM Ethernet Line Card from the shipping package. If it is missing or damaged, contact your Allied Telesis sales representative for assistance. Note Store the packaging material in a safe location.

  • Page 157: Figure 81: Removing The At-Sbx81Xlem Line Card From The Anti-Static Bag

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 81. Removing the AT-SBx81XLEM Line Card from the Anti-static 3. Place the card on a level surface. 4. With a #2 Phillips-head screwdriver, remove the two screws that secure the blank slot cover to the card. Refer to Figure 82. Figure 82.

  • Page 158: Figure 83: Removing The Blank Slot Cover From The At-Sbx81Xlem Line Card

    Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards Figure 83. Removing the Blank Slot Cover from the AT-SBx81XLEM Line Card 6. With your thumb and forefinger, pull out the retaining pin on the side of the line card and turn it clockwise one quarter turn so that it remains in the retracted position.

  • Page 159: Figure 84: Retracting The Retaining Pin On The At-Sbx81Xlem Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 84. Retracting the Retaining Pin on the AT-SBx81XLEM Line Card 7. Remove the expansion module from its shipping container and anti- static bag. Refer to Figure 85. Figure 85. Removing the Expansion Module from the Anti-static Bag Section II: Installing the Chassis...

  • Page 160: Figure 86: Sliding The Expansion Module Into The At-Sbx81Xlem Line Card

    Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards 8. Carefully align the expansion module in the slot, as shown in Figure 86, and slide it into the line card. Caution Keep the module level with the line card as you slide it into the slot. You might damage the components on the top or bottom of the module if you slide it in at an angle.

  • Page 161: Figure 87: Seating The Expansion Module On The Connector In The At-Sbx81Xlem Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 87. Seating the Expansion Module on the Connector in the AT- SBx81XLEM Line Card 10. With a Phillips-head screwdriver, install the two screws from step 4 to secure the expansion module to the line card. Refer to Figure 88. Figure 88.

  • Page 162: Figure 89: Releasing The Retaining Pin

    Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards Figure 89. Releasing the Retaining Pin 12. Retain the blank slot cover removed in step 5 and shown in Figure 90 by storing it in a safe location. You should reinstall it on the AT- SBx81XLEM Line Card if, at a later date, you remove the expansion module.

  • Page 163: Figure 91: Returning The Line Card To Its Anti-Static Bag

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 91. Returning the Line Card to its Anti-static Bag 14. For instructions on how to install the line card in the chassis, go to “Installing Ethernet Line Cards” on page 164. Note In AlliedWare Plus v5.4.6, the AT-SBx81XLEM Line Card was supported in slots 1 to 4, 8, and 10 in the AT-SBx8112 Chassis, but...

  • Page 164: Installing Ethernet Line Cards

    Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards Installing Ethernet Line Cards This section contains the installation procedure for Ethernet line cards. The illustrations show the AT-SBx81GP24 Line Card, but the procedure is the same for all cards. Note Please review “Guidelines to Handling the Controller and Line Cards”...

  • Page 165: Figure 93: Removing A Blank Slot Cover

    Refer to Figure 93. Figure 93. Removing a Blank Slot Cover 3. Remove the line card from the shipping package. If it is missing or damaged, contact your Allied Telesis sales representative for assistance. Note Store the packaging material in a safe location.

  • Page 166: Figure 95: Aligning An Ethernet Line Card In A Chassis Slot

    Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards 5. Align the line card with the internal chassis card guides in the selected slot in the chassis. Figure 95 shows an Ethernet line card aligned with slot 1. Figure 95. Aligning an Ethernet Line Card in a Chassis Slot 6.

  • Page 167: Figure 96: Seating An Ethernet Line Card On The Backplane Connector

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 96. Seating an Ethernet Line Card on the Backplane Connector 8. Finger tighten the two thumbscrews on the sides of the line card to secure it to the chassis, as shown in Figure 97. Figure 97.
  • Page 168 9. Tighten the two screws with a # 2 Phillips-head screwdriver to secure the line card to the chassis. Allied Telesis recommends tightening the screws to 5 inch-lbs. 10. Repeat this procedure to install the remaining Ethernet line cards. 11. After installing the line cards. go to “Installing Blank Slot Covers” on page 169.

  • Page 169: Installing Blank Slot Covers

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Installing Blank Slot Covers After installing the AT-SBx81CFC960 Controller Fabric Cards and Ethernet line cards, check the front panel for unused slots and cover them with the blank slot covers included with the chassis, as explained in this procedure.
  • Page 170 Chapter 7: Installing AT-SBx81CFC960 Controller Cards and Ethernet Line Cards Allied Telesis recommends tightening the screws to 5 inch-lbs. 4. Repeat this procedure to cover the remaining empty slots with blank slot covers. 5. Store any unused blank panels in a secure location for future use.

  • Page 171: Chapter 8: Cabling The Ethernet Line Cards

    Chapter 8 Cabling the Ethernet Line Cards This chapter contains instructions on how to cable the ports and slots on the Ethernet line cards. The chapter has the following sections:  “Cabling Guidelines for Twisted Pair Ports” on page 172 ...

  • Page 172: Cabling Guidelines For Twisted Pair Ports

    Chapter 8: Cabling the Ethernet Line Cards Cabling Guidelines for Twisted Pair Ports This section applies to the twisted pair ports on the following line cards and expansion modules:  AT-SBx81GT24 Line Card  AT-SBx81GP24 Line Card  AT-SBx81GT40 Line Card ...

  • Page 173: Connecting Cables To The At-Sbx81Gt40 Line Card

    Patch cables for the AT-SBx81GT40 Line Card, in lengths of 1 meter and 3 meters with RJ point 5 and RJ-45 connectors, are available from Allied Telesis. Contact your Allied Telesis sales representative for information. Section II: Installing the Chassis...

  • Page 174: Figure 101: Connecting Cables To Ports On The At-Sbx81Gt40 Line Card

    Chapter 8: Cabling the Ethernet Line Cards Connecting a cable to a port in the top row. Release Tab Connecting a cable to a port in the bottom row. Figure 101. Connecting Cables to Ports on the AT-SBx81GT40 Line Card Section II: Installing the Chassis...

  • Page 175: Guidelines To Installing Fiber Optic Transceivers

    When you do remove this cover, retain it for future use.  Your Allied Telesis sales representative can provide you with a list of supported transceivers for the line cards and expansion modules.

  • Page 176: Installing Sfp, Sfp+, Or Csfp Transceivers

    Table 28 lists the basic types of transceivers supported by the above Ethernet line cards. For model names of specific transceivers, refer to the SwitchBlade x8100 data sheet on the Allied Telesis web site. Table 28. Transceiver Support 10Gbps SFP+...

  • Page 177: Figure 102: Removing The Dust Cover From A Transceiver Slot

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide To install SFP or SFP+ transceivers, perform the following procedure: 1. Remove the dust plug from the slot chosen for the SFP or SFP+ transceiver. Figure 102 shows the dust plug removed from slot 1 on the AT-SBx81XS16 Line Card.

  • Page 178: Figure 103: Installing An Sfp Or Sfp+ Transceiver

    Chapter 8: Cabling the Ethernet Line Cards Handle Figure 103. Installing an SFP or SFP+ Transceiver For slots on the AT-SBx81XS6 Line Card, position the handle on top. Refer to Figure 104. Handle Figure 104. Installing an SFP+ Transceiver in the AT-SBx81XS6 Line Card Section II: Installing the Chassis...

  • Page 179: Figure 105: Removing The Dust Cover From A Transceiver

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Note If you are ready to attach the fiber optic cable to the transceiver, continue with the next step. Otherwise, repeat steps 1 to 2 to install the remaining SFP transceivers in the line cards. 3.

  • Page 180: Figure 106: Verifying The Position Of The Handle On The Transceiver In The At-Sbx81Xs16 Line Card

    Chapter 8: Cabling the Ethernet Line Cards Handle Figure 106. Verifying the Position of the Handle on the Transceiver in the AT-SBx81XS16 Line Card 5. Connect the fiber optic cable to the port on the transceiver, as shown in Figure 107. The connector should snap into the port. Figure 107.
  • Page 181 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 7. After installing and cabling the transceivers, do one of the following:  To install and cable additional transceivers in the Ethernet line cards, go to the appropriate section in this chapter for instructions. ...

  • Page 182: Installing At-Sp10Tw Direct Connect Cables

    Chapter 8: Cabling the Ethernet Line Cards Installing AT-SP10TW Direct Connect Cables This procedure explains how to connect AT-SP10TW direct connect Twinax cables to the SFP+ slots in the following line cards and expansion module:  AT-SBx81XS6 Line Card  AT-SBx81XS16 Line Card ...

  • Page 183: Figure 109: Installing The At-Sp10Tw Cable In The At-Sbx81Xs16 Line Card Or At-Sbx81Xlem/Xs8 Expansion Module

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Note Do not remove the dust plug from an SFP+ slot if you are not installing the transceiver at this time. The dust plug protects the line card from dust contamination. 2.

  • Page 184: Figure 110: Installing The At-Sp10Tw Cable In The At-Sbx81Xs6 Line Card

    Chapter 8: Cabling the Ethernet Line Cards Release Tab Figure 110. Installing the AT-SP10TW Cable in the AT-SBx81XS6 Line Card 3. Install the other end of the cable into an SFP+ slot on another network device. 4. Repeat this procedure to install additional AT-SP10TW Cables. Note To remove the connector and cable from the SFP+ slot, gently push on the connector, pull on the release tab, and slide the connector...

  • Page 185: Installing At-Qsfpcu Cables

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Installing AT-QSFPCU Cables This section contains instructions on how to install AT-QSFPCU Cables in the AT-SBx81XLEM/Q2 Expansion Module for the AT-SBx81XLEM Line Card. You can use the cables in place of fiber optic cables and transceivers for 40GbE links of up to 1 or 3 meters.

  • Page 186: Figure 112: Sliding The At-Qsfpcu Cable Into The Slot

    Chapter 8: Cabling the Ethernet Line Cards Release Tab Figure 112. Sliding the AT-QSFPCU Cable into the Slot 3. Install the other end of the cable into a compatible QSFP+ slot on another network device. 4. Repeat this procedure to install additional AT-QSFPCU Cables. Note To remove the connector and cable from the slot, gently push on the connector, pull on the release tab, and slide the connector from the...

  • Page 187: Installing At-Qsfpsr, At-Qsfpsr4, Or At-Qsfplr4 Transceivers

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Installing AT-QSFPSR, AT-QSFPSR4, or AT-QSFPLR4 Transceivers This section contains the procedure for installing AT-QSFPSR, AT- QSFPSR4, or AT-QSFPLR4 transceivers in the slots on the AT- SBx81XLEM/Q2 Expansion Module. Note The AT-QSFPSR, AT-QSFPSR4, and AT-QSFPLR4 transceivers are only supported in the AT-SBx81XLEM/Q2 Expansion Module.
  • Page 188 Chapter 8: Cabling the Ethernet Line Cards Section II: Installing the Chassis...

  • Page 189: Chapter 9: Cabling The At-Sbx81Cfc960 Controller Fabric Card

    Chapter 9 Cabling the AT-SBx81CFC960 Controller Fabric Card This chapter contains instructions on how to cable the ports on the AT- SBx81CFC960 Controller Fabric Card. The chapter has the following sections:  “Cabling the NET MGMT Port” on page 190 ...

  • Page 190: Cabling The Net Mgmt Port

    Chapter 9: Cabling the AT-SBx81CFC960 Controller Fabric Card Cabling the NET MGMT Port For background information on the NET MGMT port on the controller card, refer to “Ethernet Management Port (NET MGMT)” on page 93. Note The NET MGMT port is referred to as “eth0” in the management software.
  • Page 191 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide manually with the POLARITY command. After cabling the NET MGMT port, do one of the following:  To install and cable additional transceivers, go to the appropriate section in this chapter for instructions. ...

  • Page 192: Installing Sfp+ Transceivers

    For background information on the SFP+ slots on the controller card, refer to “SFP+ Ports” on page 90. A list of supported SFP+ transceivers can be found on the Allied Telesis web site. Note The transceiver slots on the controller card do not support 1000Mbps SFP transceivers.

  • Page 193: Figure 113: Removing A Dust Cover From An Sfp+ Slot In The At-Sbx81Cfc960 Controller Fabric Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 113. Removing a Dust Cover from an SFP+ Slot in the AT- SBx81CFC960 Controller Fabric Card Note To protect the controller card from dust contamination, do not remove the dust plug from a transceiver slot until you are ready to install the transceiver.

  • Page 194: Figure 115: Installing An Sfp+ Transceiver In The At-Sbx81Cfc960 Controller Fabric Card

    Chapter 9: Cabling the AT-SBx81CFC960 Controller Fabric Card Figure 115. Installing an SFP+ Transceiver in the AT-SBx81CFC960 Controller Fabric Card Note If you are ready to attach the fiber optic cable to the transceiver, continue with the next step. Otherwise, repeat steps 1 to 3 to install additional SFP+ transceivers in the card.

  • Page 195: Figure 117: Positioning The Handle On The Transceiver

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Note The dust cover protects the fiber optic port on the SFP+ transceiver from dust contamination. Do not remove it until you are ready to connect the fiber optic cable. 5. Verify the position of the handle on the transceiver. If the transceiver is in slot 1 or 3, the handle should be in the upright position, as shown in Figure 117.

  • Page 196: Figure 118: Attaching A Fiber Optic Cable To An Sfp+ Transceiver In The At-Sbx81Cfc960 Controller Fabric Card

    Chapter 9: Cabling the AT-SBx81CFC960 Controller Fabric Card Figure 118. Attaching a Fiber Optic Cable to an SFP+ Transceiver in the AT-SBx81CFC960 Controller Fabric Card 7. Repeat this procedure to install additional SFP+ transceivers in the AT-SBx81CFC960 Controller Fabric Card. 8.

  • Page 197: Installing At-Sp10Tw Cables

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Installing AT-SP10TW Cables This procedure explains how to connect AT-SP10TW Cables to the SFP+ slots in the AT-SBx81CFC960 Controller Fabric Card. The cables may be used in place of fiber optic cables and transceivers for 10 Gbps links of up to seven meters.

  • Page 198: Figure 119: Installing An At-Sp10Tw Cable In The At-Sbx81Cfc960 Controller Fabric Card

    Chapter 9: Cabling the AT-SBx81CFC960 Controller Fabric Card Release Tab Release Tab Figure 119. Installing an AT-SP10TW Cable in the AT-SBx81CFC960 Controller Fabric Card 3. Install the other end of the cable into an SFP+ slot on another network device. 4.

  • Page 199: Chapter 10: Powering On The Chassis

    Chapter 10 Powering On the Chassis This chapter describes how to power on the chassis and monitor the initialization process. The chapter contains the following sections:  “Verifying the Installation” on page 200  “Powering On AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supplies”...

  • Page 200: Verifying The Installation

    Chapter 10: Powering On the Chassis Verifying the Installation Please perform the following procedure before powering on the chassis: 1. Verify that the grounding lug on the back panel of the chassis is properly grounded. For instructions, refer to “Installing the Chassis Grounding Wire”...

  • Page 201: Powering On At-Sbxpwrsys1 Or At-Sbxpwrsys2 Ac System Power Supplies

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Powering On AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supplies The procedure in this section explains how to power on AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supplies in slots C and D on the front panel.

  • Page 202: Figure 120: Ac Sockets On The Rear Panel Of The At-Sbx8112 Chassis

    Chapter 10: Powering On the Chassis Figure 120. AC Sockets on the Rear Panel of the AT-SBx8112 Chassis 2. Plug the AC power cord that comes with the power supply into a plug whose corresponding slot on the front panel has a system power supply.

  • Page 203: Figure 121: Connecting The Ac Power Cord For The At-Sbxpwrsys1 Or At-Sbxpwrsys2 Ac System Power

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 121. Connecting the AC Power Cord for the AT-SBxPWRSYS1 or AT-SBxPWRSYS2 AC System Power Supply 3. Use the twist tie included with the power supply to secure the cord to an anchor on the chassis to protect it from being accidentally pulled out, as shown in Figure 122 on page 204.

  • Page 204: Figure 122: Securing The Power Cord For The At-Sbxpwrsys1 Or At-Sbxpwrsys2 Ac Power Supply To An

    Chapter 10: Powering On the Chassis Figure 122. Securing the Power Cord for the AT-SBxPWRSYS1 or AT- SBxPWRSYS2 AC Power Supply to an Anchor 4. Connect the power cord to an appropriate AC power source to power on the power supply. 5.

  • Page 205: Powering On At-Sbxpwrpoe1 Power Supplies

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Powering On AT-SBxPWRPOE1 Power Supplies If you have not already installed the AT-SBxPWRPOE1 Power Supplies, refer to “Installing AT-SBxPWRPOE1 PoE Power Supplies” on page 135 for installation instructions. To power on the power supplies, perform the following procedure: 1.

  • Page 206: Figure 124: Securing The Power Cord For The At-Sbxpwrpoe1 Power Supply To An Anchor

    Chapter 10: Powering On the Chassis 3. Use the twist tie that comes with the power supply to secure the cord to an anchor on the chassis, as shown in Figure 124. Figure 124. Securing the Power Cord for the AT-SBxPWRPOE1 Power Supply to an Anchor 4.

  • Page 207: Figure 125: Dress And Secure Ac Power Cords

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 125. Dress and Secure AC Power Cords 6. Go to “Monitoring the Initialization Process” on page 235. Section II: Installing the Chassis...

  • Page 208: Wiring The At-Sbxpwrsys1 Dc System Power Supply

    Chapter 10: Powering On the Chassis Wiring the AT-SBxPWRSYS1 DC System Power Supply This section contains instructions on how to wire the AT-SBxPWRSYS1 DC Power Supply. For installation instructions, refer to “Installing AT- SBxPWRSYS1 DC System Power Supplies” on page 140. The power supply unit has a ground connection and positive and negative DC terminals.

  • Page 209: Figure 126: Components Of The At-Sbxpwrsys1 Dc Power Supply

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide The components of the power supply are identified in Figure 126. Positive (+) Negative (-) On/Off Terminal Terminal Switch Plastic Locking Cover Handle Screw Locking Ground Post Handle with Nut and Washer Figure 126.

  • Page 210: Choosing A Method For Attaching The Grounding Wire

    Chapter 10: Powering On the Chassis Choosing a You can attach the grounding wire to the power supply using the supplied terminal, shown in Figure 127, or bare wire. Method for Attaching the Grounding Wire Figure 127. Grounding Wire Terminal The two methods are described in the following sections: ...

  • Page 211: Figure 130: Removing The Nut And Washer From The Grounding Post

     You may route the cable either above or below the locking handle.  Allied Telesis recommends tightening the nut and washer to 26 inch-lbs. The grounding wire is illustrated in Figure 131 on page 212. Section II: Installing the Chassis...

  • Page 212: Figure 131: Installing The Grounding Wire

    Chapter 10: Powering On the Chassis Groundin g wire Figure 131. Installing the Grounding Wire 5. Connect the other end of the grounding wire to the building protective earth. Warning When installing this equipment, always ensure that the power supply ground connection is installed first and disconnected last.

  • Page 213: Connecting The Grounding Wire With Bare Wire

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Connecting the To attach the grounding wire to the power supply with bare wire, perform the following procedure: Grounding Wire with Bare Wire 1. Prepare an adequate length of solid or stranded 10 AWG grounding wire by stripping it as shown in Figure 132.

  • Page 214: Figure 134: Securing The Bare Grounding Wire To The Grounding Post

    Figure 134. Figure 134. Securing the Bare Grounding Wire to the Grounding Post Allied Telesis recommends tightening the nut and washer to 26 inch- lbs. After connecting the grounding wire, go to “Choosing a Method for Attaching the Power Wires”...

  • Page 215: Choosing A Method For Attaching The Power Wires

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Choosing a The AT-SBxPWRSYS1 DC Power Supply comes with the two sets of power wire terminals shown in Figure 135. You may use either set to Method for connect the positive (+) and negative (-) wires to the terminal block on the Attaching the power supply.

  • Page 216: Figure 136: Stripping The Power Wires

    Chapter 10: Powering On the Chassis Figure 136. Stripping the Power Wires Note You must use stranded wires with the terminal lugs. You may not use solid wires. 2. Insert the power wires into the terminals included with the power supply and use a crimping tool to secure the wires to the terminals.

  • Page 217: Figure 138: On/Off Switch On The At-Sbxpwrsys1 Dc Power Supply

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide On/Off Switch Figure 138. On/Off Switch on the AT-SBxPWRSYS1 DC Power Supply 4. Use a #1 Phillips-head screwdriver to loosen the two screws on the plastic cover over the positive and negative terminals on the power supply and slide the cover to the right, as shown in Figure 139 on page 218.

  • Page 218: Figure 139: Opening The Plastic Cover

    Chapter 10: Powering On the Chassis Figure 139. Opening the Plastic Cover 5. Use a #3 Phillips-head screwdriver to remove the two screws from the positive and negative terminals, as shown in Figure 140 on page 219. Section II: Installing the Chassis...

  • Page 219: Figure 140: Removing The Terminal Screws

    You may attach the terminals with the wires either above or below the terminal block. Figure 141 on page 220 shows the positive wire above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs. Section II: Installing the Chassis...

  • Page 220: Figure 141: Connecting The Positive (+) Power Wire With A Straight Terminal

    You may attach the terminals with the wires either above or below the terminal block. Figure 142 on page 221 shows the wires above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs. Section II: Installing the Chassis...

  • Page 221: Figure 142: Connecting The Negative (-) Power Wire With A Straight Terminal

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 142. Connecting the Negative (-) Power Wire with a Straight Terminal Warning Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block.

  • Page 222: Figure 143: Closing The Plastic Cover Over The Terminal Connectors

    Chapter 10: Powering On the Chassis Figure 143. Closing the Plastic Cover over the Terminal Connectors 9. With a #2 Phillips-head screwdriver, tighten the handle locking screw to secure the power supply to the chassis. See Figure 144 on page 223.

  • Page 223: Figure 144: Tightening The Handle Locking Screw

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Handle locking Figure 144. Tightening the Handle Locking Screw 10. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off. 11.

  • Page 224: Connecting The Dc Power Wires With The Right Angle Terminals

    Chapter 10: Powering On the Chassis Connecting the To connect the DC power wires to the positive and negative terminals on the power supply with the right angle terminals, perform the following DC Power Wires procedure: with the Right Angle Terminals 1.

  • Page 225: Figure 147: Removing The Plastic Cover

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 4. Using a #1 Phillips-head screwdriver, remove the two screws that secure the plastic cover over the positive and negative terminals and remove the plastic cover from the power supply, as shown in Figure 147.

  • Page 226: Figure 148: Removing The Terminal Screws

    The positive terminal is on the left. Refer to Figure 149 on page 227. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs. Section II: Installing the Chassis...

  • Page 227: Figure 149: Connecting The Positive (+) Power Wire With A Right Angle Terminal

    5. The negative terminal is on the right. Refer to Figure 150 on page 228. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs. Section II: Installing the Chassis...

  • Page 228: Figure 150: Connecting The Negative (-) Power Wire With A Right Angle Terminal

    Chapter 10: Powering On the Chassis Figure 150. Connecting the Negative (-) Power Wire with a Right Angle Terminal Warning Check to see if there are any exposed copper strands coming from the installed wires. When this installation is done correctly there should be no exposed copper wire strands extending from the terminal block.

  • Page 229: Figure 151: Tightening The Handle Locking Screw

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Handle locking screw Figure 151. Tightening the Handle Locking Screw 9. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off. 10.

  • Page 230: Connecting Bare Dc Power Wires

    You may attach the wire to the terminal so that it extends either above or below the terminal block. Figure 153 on page 231 shows the wire above the terminal block. Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs.

  • Page 231: Figure 153: Connecting The Positive Wire With Bare Wire

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 153. Connecting the Positive Wire With Bare Wire 5. Wrap the negative lead wire clockwise around the remaining terminal screw and secure the screw and wire to the negative terminal connection on the terminal block with a #3 Phillips-head screwdriver, as shown in Figure 154 on page 232.

  • Page 232: Figure 154: Connecting The Negative Lead Wire With Bare Wire

    Chapter 10: Powering On the Chassis Figure 154. Connecting the Negative Lead Wire with Bare Wire Allied Telesis recommends tightening the screw to 30 to 40 inch-lbs. Warning Check to see if there are any exposed copper strands coming from the installed wires.
  • Page 233 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 7. With a #2 Phillips-head screwdriver, tighten the handle locking screw to secure the power supply to the chassis. See Figure 144 on page 223. 8. Before attaching the power wires from the power supply to the circuit breaker in the wiring closet, check that the circuit breaker is off.

  • Page 234: Powering On The At-Sbxpwrsys1 Dc System Power Supply

    Chapter 10: Powering On the Chassis Powering On the AT-SBxPWRSYS1 DC System Power Supply To power on the AT-SBxPWRSYS1 DC Power Supply, perform the following procedure: 1. Turn the DC circuit breaker on. 2. Turn the On/Off switch on the power supply to the On position. Refer to Figure 138 on page 217.

  • Page 235: Monitoring The Initialization Process

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Monitoring the Initialization Process The line and controller cards perform an initialization process whenever you power or reset the chassis. The initialization process takes approximately three minutes to complete. The line cards do not begin to forward traffic from their ports until the process is finished.

  • Page 236: Figure 155: Initialization Messages For A Stand-Alone Switch

    Verifying release... OK Booting... Starting base/first... [ OK ] Mounting virtual filesystems... [ OK ] Allied Telesis Inc. AlliedWare Plus (TM) v5.4.4 Current release filename: SBx81CFC960-5.4.4-0.0.rel Original release filename: SBx81CFC960-5.4.4-.0.rel Built: Thu Dec 19 21:30:52 NZDT 2013 Mounting static filesystems...

  • Page 237: Figure 156: Initialization Messages For A Stand-Alone Switch (Continued)

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Received event network.active 08:00:54 awplus-1.5 chassis[2138]: Card 1.2 (AT-SBx81GT24) has joined the chassis 08:00:54 awplus-1.5 chassis[2138]: Card 1.1 (AT-SBx81GT24) has joined the chassis 08:00:55 awplus-1.5 chassis[2138]: Card 1.3 (AT-SBx81XS6) has joined the chassis 08:00:55 awplus-1.5 chassis[2138]: Card 1.4 (AT-SBx81GP24) has joined the chassis...
  • Page 238 Chapter 10: Powering On the Chassis Section II: Installing the Chassis...

  • Page 239: Chapter 11: Verifying The Hardware Operations Of The Chassis

    “Using the LEDs to Verify the Chassis” on page 240  “Using Local Management to Verify the Chassis” on page 242 Note Allied Telesis recommends using both methods to confirm the initial operations of the chassis, controller cards, and line cards.

  • Page 240: Using The Leds To Verify The Chassis

    LED is solid green. If the LED is off, the fan module has a problem or failed. Power off the chassis and contact your Allied Telesis representative for assistance. Do not operate the chassis without a fully operational fan unit.
  • Page 241 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide prevents them from completing the initialization process. Power off the chassis and replace the cards. 5. To check the status of the Ethernet line cards, inspect the SBx Linecard Status LEDs on the controller card. (If the chassis has two controller cards, you may use the LEDs on either card.) A line card is operating normally when its corresponding LED is solid green.

  • Page 242: Using Local Management To Verify The Chassis

    Chapter 11: Verifying the Hardware Operations of the Chassis Using Local Management to Verify the Chassis This section explains how to use the commands in the AlliedWare Plus Operating System on the controller card to confirm the operations of the chassis.

  • Page 243: Verifying The Chassis With The Alliedware Plus Commands

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 3. Configure the VT-100 terminal or terminal emulation program as follows:  Baud rate: 115,200 bps  Data bits: 8  Parity: None  Stop bits: 1  Flow controller: None Note The port settings are for a DEC VT100 or ANSI terminal, or an equivalent terminal emulator program.

  • Page 244: Figure 159: Show Card Command

    Chapter 11: Verifying the Hardware Operations of the Chassis 2. Compare the version number displayed by the SHOW VERSION command with the information in Table 26 on page 98 to confirm that the version of the AlliedWare Plus Operating System on the controller card supports all the hardware components in the chassis.
  • Page 245 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide For information about the command line interface, refer to the Software Reference for SwitchBlade x8100 Series Switches on the Allied Telesis web site. Section II: Installing the Chassis...
  • Page 246 Chapter 11: Verifying the Hardware Operations of the Chassis Section II: Installing the Chassis...

  • Page 247: Chapter 12: Troubleshooting

    Note If you are unable to resolve a hardware problem with the instructions in this chapter, contact Allied Telesis Technical Support for further assistance. Refer to “Contacting Allied Telesis” on page 18for contact information. The following troubleshooting information is available: ...

  • Page 248: At-Sbxpwrsys1, At-Sbxpwrsys2, And At-Sbxpwrpoe1 Power Supplies

    Chapter 12: Troubleshooting AT-SBxPWRSYS1, AT-SBxPWRSYS2, and AT-SBxPWRPOE1 Power Supplies The AT-SBxPWRSYS1 and AT-SBxPWRSYS2 AC System Power Supplies and AT-SBxPWRPOE1 PoE Power Supply are operating normally when the AC and DC LEDs are solid green and the Fault LED is off. Possible fault conditions and their solutions are described here: Fault Condition 1: If the AC LED is off, the power supply is not receiving power, has overheated and been disabled, or has failed and needs to be replaced.
  • Page 249 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Caution The power supply interfaces are not hot swappable and should only be serviced by an authorized service technician. Section II: Installing the Chassis...

  • Page 250: At-Sbxpwrsys1 Dc System Power Supply

    Chapter 12: Troubleshooting AT-SBxPWRSYS1 DC System Power Supply If you suspect a problem with the DC power supply, examine its LEDs. The power supply is operating normally when the DC IN and DC OUT LEDs are solid green and the Fault LED is off. Possible fault conditions and their solutions are described here: Fault Condition 1: If the DC IN LED is off, the power supply is not receiving power, has overheated and been disabled, or has failed and needs to be...
  • Page 251 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide  The controller card might have an older version of the management software that cannot detect the DC power supply. For instructions on how to verify the software version on the control card, refer to “Using Local Management to Verify the Chassis”...

  • Page 252: Ethernet Line Cards

    Chapter 12: Troubleshooting Ethernet Line Cards A quick and easy way to check the overall heath of the Ethernet line cards in the chassis is with the SBx STATUS LEDs on the controller card. (If the chassis has two controller cards, you may use the LEDs on either card.) There are twelve LEDs, one for each slot.

  • Page 253: Table 29. Alliedware Plus Operating System Releases For The At-Sbx81Xlem Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide If the problem is with the AT-SBx81XS16 Line Card, check the following items:  Verify that the version of the AlliedWare Plus Operating System on the AT-SBx81CFC960 Controller Fabric Card supports the card. The AT-SBx81XS16 Line Card requires version 5.4.4 or later.
  • Page 254 AlliedWare Plus v5.4.6-1 or later, which supports the line card in all ten line card slots.) If the problem is with the AT-SBx81GC40 Line Card, verify that the version of the AlliedWare Plus Operating System on the controller card supports the card.

  • Page 255: Twisted Pair Ports

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Twisted Pair Ports This section applies to the twisted pair ports on the following devices:  AT-SBx81GT24 Line Card  AT-SBx81GT40 Line Card  AT-SBx81GP24 Line Card  AT-SBx81XLEM/XT4 Expansion Module ...
  • Page 256 Chapter 12: Troubleshooting to match the speeds of the network devices.  The ports must be set to Auto-Negotiation, the default setting, to operate at 1000Mbps or 10Gbps.  The default duplex mode setting for the ports is Auto-Negotiation. This setting is appropriate for ports connected to network devices that also support Auto-Negotiation for duplex modes.

  • Page 257: Power Over Ethernet

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Power Over Ethernet This section applies only to the AT-SBx81GP24 Line Card. Each port has two LEDs. The left LED provides port link and activity status and the right LED provides PoE status information. The PoE LED is solid green when a port is delivering power to a powered device (PD).
  • Page 258 Chapter 12: Troubleshooting  Try connecting the PD to a port on a different AT-SBx81GP24 Line Card. Section II: Installing the Chassis...

  • Page 259: Fiber Optic Or Twisted Pair Transceivers

    Verify that the Ethernet line card or expansion module supports the transceiver. A list of supported transceivers can be found in the SwitchBlade x8112 data sheet on the Allied Telesis web site. You should also check the error log for the following message: port doesn’t support this module type.
  • Page 260 Chapter 12: Troubleshooting maximum distance. The cable specifications for the transceivers are provided in the installation instructions that ship with the modules.  Use a fiber optic tester to test whether the optical signal is too weak (i.e., sensitivity) or too strong (i.e., maximum input power). The operating specifications of the fiber optic transceivers are shipped with the units.

  • Page 261: At-Sbx81Cfc960 Controller Fabric Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide AT-SBx81CFC960 Controller Fabric Card If the chassis has one controller card and the card fails, all network operations stop. The Ethernet line cards stop forwarding all network traffic until the controller card is replaced. If the chassis has two controller cards and one fails, the Ethernet line cards continue to forward traffic, but the bandwidth of the backplane is reduced, which, depending on the number of Ethernet line cards present...

  • Page 262: At-Sbxfan12 Fan Module

    Chapter 12: Troubleshooting AT-SBxFAN12 Fan Module The AT-SBxFAN12 Fan Module is operating correctly when the POWER LED on the module is solid green. If the LED on the fan module is off, check the FAN LED in the SYS STATUS section on the active master controller card.

  • Page 263: Local (Console) Management Session

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Local (Console) Management Session If you are unable to establish a local management session with the switch through the Console RS-232 port on the controller card, do the following:  Check to be sure that the RJ-45 serial management cable is securely connected to the Console RS-232 port on the active master controller card and the RS-232 port on the terminal or personal computer.

  • Page 264: Power Supply Interfaces (Opto-Couplers)

    No corrective steps are required. If the PSU LED is solid amber but the LEDs on the power supplies indicate normal operations, there may be a problem with a power supply interface. Contact your Allied Telesis sales representative for assistance.

  • Page 265: Chapter 13: Replacing Modules

    Chapter 13 Replacing Modules This chapter contains procedures on how to replace modules in the chassis. The chapter has the following sections:  “Replacing AT-SBxPWRSYS1, AT-SBxPWRSYS2, and AT- SBxPWRPOE1 Power Supplies” on page 266  “Replacing the AT-SBxPWRSYS1 DC Power Supply” on page 272 ...

  • Page 266: Replacing At-Sbxpwrsys1, At-Sbxpwrsys2, And At-Sbxpwrpoe1 Power Supplies

    Allied Telesis recommends creating a backup copy of the configuration file in the controller card before removing or replacing a power supply. For instructions, refer to the Software Reference for SwitchBlade x8100 Series Switches on the Allied Telesis web site. Note The power supplies are hot swappable.

  • Page 267: Figure 160: Disconnecting The Ac Power Cord From The Ac Socket On The Back Panel

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 160. Disconnecting the AC Power Cord from the AC Socket on the Back Panel 2. Lift the locking hand on the power supply. Refer to Figure 161 on page 268. Section II: Installing the Chassis...

  • Page 268: Figure 161: Lifting The Locking Handle On The Power Supply

    Chapter 13: Replacing Modules Figure 161. Lifting the Locking Handle on the Power Supply 3. Carefully pull on the locking handle to slide the power supply from the chassis. Refer to Figure 162 on page 269. Warning The power supply is heavy. Use both hands to hold the module as you remove it from the chassis.

  • Page 269: Figure 162: Removing The Power Supply From The Chassis

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 162. Removing the Power Supply from the Chassis 4. Do one of the following:  To install a new power supply, refer to Chapter 6, “Installing the Power Supplies” on page 127. ...

  • Page 270: Figure 163: Installing A Blank Power Supply Slot Cover

    Chapter 13: Replacing Modules Figure 163. Installing a Blank Power Supply Slot Cover 6. Lower the locking handle to secure the slot cover to the slot. Refer to Figure 164 on page 271. Section II: Installing the Chassis...

  • Page 271: Figure 164: Lowering The Locking Handle On The Power Supply Slot Cover

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 164. Lowering the Locking Handle on the Power Supply Slot Cover Section II: Installing the Chassis...

  • Page 272: Replacing The At-Sbxpwrsys1 Dc Power Supply

    Chapter 13: Replacing Modules Replacing the AT-SBxPWRSYS1 DC Power Supply To remove an AT-SBxPWRSYS1 DC Power Supply from the chassis, perform the following procedure: 1. Turn off the circuit breaker to the AT-SBxPWRSYS1 DC Power Supply. 2. Turn off the On/Off switch on the front panel of the power supply. Refer to Figure 126 on page 209.

  • Page 273: Figure 166: Opening The Plastic Window Over The Terminal Block

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Note If the power wires are connected to the terminal block with the right angle terminals, go to step 5. 4. Use a #1 screwdriver to loosen the two screws that secure the plastic cover over the terminal block and slide the cover to the right.

  • Page 274: Figure 167: Removing The Negative Lead Wire

    Chapter 13: Replacing Modules Figure 167. Removing the Negative Lead Wire 6. Use a #3 screwdriver to remove the positive (+) lead wire from the terminal block. Refer to Figure 168 on page 275. Section II: Installing the Chassis...

  • Page 275: Figure 168: Removing The Positive Lead Wire From The Terminal Block

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 168. Removing the Positive Lead Wire from the Terminal Block 7. Reinstall the two screws on the negative (-) and positive (+) terminals. Refer to Figure 169 on page 276. Section II: Installing the Chassis...

  • Page 276: Figure 169: Reinstalling The Screws On The Positive And Negative Terminals

    Chapter 13: Replacing Modules Figure 169. Reinstalling the Screws on the Positive and Negative Terminals 8. Slide the plastic cover to the left and lightly tighten the two screws to secure it in place. Refer to Figure 170 on page 277. Caution Do not over tighten the screws or you may crack or break the plastic cover.

  • Page 277: Figure 170: Closing The Plastic Cover

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 170. Closing the Plastic Cover 9. Use an 8 mm wrench to remove the grounding wire from the grounding post. Refer to Figure 171 on page 278. Section II: Installing the Chassis...

  • Page 278: Figure 171: Removing The Grounding Wire

    Chapter 13: Replacing Modules Figure 171. Removing the Grounding Wire 10. Reinstall the nut and washer on the grounding post. Refer to Figure 172 on page 279. Section II: Installing the Chassis...

  • Page 279: Figure 172: Reinstalling The Nut And Washer On The Grounding Post

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 172. Reinstalling the Nut and Washer on the Grounding Post 11. Lift the locking handle and slide the power supply from the chassis. Refer to Figure 173 on page 280. Warning The power supply is heavy.

  • Page 280: Figure 173: Lifting The Locking Handle And Removing The Power Supply

    Chapter 13: Replacing Modules Figure 173. Lifting the Locking Handle and Removing the Power Supply 12. Do one of the following:  To install a new power supply, refer to Chapter 6, “Installing the Power Supplies” on page 127.  If you are not installing a new power supply, continue with this procedure to install a blank slot cover.

  • Page 281: Figure 174: Installing A Blank Power Supply Slot Cover

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 174. Installing a Blank Power Supply Slot Cover 14. Lower the locking handle to secure the slot cover to the slot. Refer to Figure 175 on page 282. Section II: Installing the Chassis...

  • Page 282: Figure 175: Lowering The Locking Handle On The Power Supply Slot Cover

    Chapter 13: Replacing Modules Figure 175. Lowering the Locking Handle on the Power Supply Slot Cover Section II: Installing the Chassis...

  • Page 283: Replacing Ethernet Line Cards

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Replacing Ethernet Line Cards This section contains the procedure for replacing Ethernet line cards from the chassis. Note Please review “Guidelines to Handling the Controller and Line Cards” on page 148 before performing this procedure. The Ethernet line cards are hot-swappable.
  • Page 284 Chapter 13: Replacing Modules Caution Keep the card level as you slide it out of the chassis. You might damage the components on the top or bottom of the card if you slide it out at an angle. Refer to Figure 72 on page 149. 7.

  • Page 285: Replacing Expansion Modules In At-Sbx81Xlem Line Cards

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Replacing Expansion Modules in AT-SBx81XLEM Line Cards This section contains the procedure for replacing expansion modules in AT-SBx81XLEM Line Cards. Note Please review “Guidelines to Handling the Controller and Line Cards” on page 148 before performing this procedure. Caution The expansion modules are not hot-swappable.

  • Page 286: Figure 176: Removing The Screws From The Expansion Module

    Chapter 13: Replacing Modules Figure 176. Removing the Screws from the Expansion Module 4. With your thumb and forefinger, pull out the retaining pin on the side of the line card and turn it clockwise one quarter turn until it remains in the retracted position.

  • Page 287: Figure 178: Disconnecting The Expansion Module From The At-Sbx81Xlem Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 5. Lift the front of the line card and carefully insert the tip of a flathead screwdriver into the slot beneath the expansion module on the bottom panel. Gently twist the screwdriver to disconnect the module from the connector in the line card.

  • Page 288: Figure 179: Sliding The Expansion Module From The At-Sbx81Xlem Line Card

    Chapter 13: Replacing Modules Figure 179. Sliding the Expansion Module from the AT-SBx81XLEM Line Card 7. If you are not installing the expansion module in another AT- SBx81XLEM Line Card, store it in an anti-static bag. Refer to Figure 180. Figure 180.

  • Page 289: Figure 181: Sliding The Blank Slot Cover Into The At-Sbx81Xlem Line Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 181. Sliding the Blank Slot Cover into the AT-SBx81XLEM Line Card 10. Secure the blank slot cover to the card with a Phillips-head screwdriver and the two screws removed in step 3. Refer to Figure 182. Figure 182.

  • Page 290: Figure 183: Releasing The Retaining Pin

    Chapter 13: Replacing Modules Figure 183. Releasing the Retaining Pin 12. To install the line card back in the chassis, go to “Installing Ethernet Line Cards” on page 164 and start with step 5. Section II: Installing the Chassis...

  • Page 291: Replacing At-Sbx81Cfc960 Controller Fabric Cards

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Replacing AT-SBx81CFC960 Controller Fabric Cards This section contains procedures for replacing the controller fabric cards in the AT-SBx8112 Chassis. There are different procedures depending on the number of controller cards in the chassis: ...

  • Page 292: Two Controller Cards

    Chapter 13: Replacing Modules 5. Wait a minimum of three minutes for the line and controller cards to complete the initialization process. 6. Restore the configuration to the Ethernet line and controller cards by uploading the latest archived copy of the configuration file to the new controller card.

  • Page 293: Figure 184: Loosening The Screws On The At-Sbx81Cfc960 Controller Card

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 2. Disconnect the cables from the SFP+ transceivers in the controller card and remove the transceivers. 3. Use a #2 Phillips-head screwdriver to loosen the two screws on the faceplate of the card. Refer to Figure 184. Figure 184.

  • Page 294: Figure 186: Removing The At-Sbx81Cfc960 Controller Card

    Chapter 13: Replacing Modules Caution Keep the card level as you slide it out of the chassis. You might damage the components on the top or bottom of the card if you slide it out at an angle. Refer to Figure 72 on page 149. Caution Do not hold the controller card by its retaining handles.

  • Page 295: Replacing The At-Sbxfan12 Fan Module

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Replacing the AT-SBxFAN12 Fan Module This section contains the procedures for replacing the AT-SBxFAN12 Fan Module, located in the slot on the right side of the front panel. Caution Although the fan module is hot swappable and can be replaced while the chassis is powered on, the chassis may overheat if it is operated for more than one or two minutes without a fan module.

  • Page 296: Figure 187: Loosening The Screw On The At-Sbxfan12 Fan Module

    Chapter 13: Replacing Modules Figure 187. Loosening the Screw on the AT-SBxFAN12 Fan Module 3. Carefully pull on the handle to disconnect the fan module from the connector on the backplane of the chassis. Refer to Figure 188 on page 297. Section II: Installing the Chassis...

  • Page 297: Figure 188: Loosening The At-Sbxfan12 Fan Module From The Backplane Connector

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 188. Loosening the AT-SBxFAN12 Fan Module from the Backplane Connector 4. Slowly pull out the module 51 mm (2 in.). Refer to Figure 189 on page 298. Section II: Installing the Chassis...

  • Page 298: Figure 189: Withdrawing The At-Sbxfan12 Fan Module 51 Mm (2 In.) From The Chassis

    Chapter 13: Replacing Modules 50 mm (2 in.) Figure 189. Withdrawing the AT-SBxFAN12 Fan Module 51 mm (2 In.) from the Chassis 5. Wait ten seconds for the fans to stop. Warning The fan module has hazardous moving parts. Keep fingers away from moving fan blades.

  • Page 299: Installing A New At-Sbxfan12 Fan Module

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 190. Removing the AT-SBxFAN12 Fan Module from the Chassis Installing a New This procedure assumes that you have already removed the old fan module from the chassis and are continuing directly from the previous AT-SBxFAN12 procedure, “Removing the AT-SBxFAN12 Fan Module”...

  • Page 300: Figure 191: Installing A New At-Sbxfan12 Fan Module

    Chapter 13: Replacing Modules Figure 191. Installing a New AT-SBxFAN12 Fan Module 2. When you feel the fan module make contact with the connector on the backplane, gently push on the top and bottom of the faceplate to seat the module on the connector. Refer to Figure 192 on page 301. Section II: Installing the Chassis...

  • Page 301: Figure 192: Securing The At-Sbxfan12 Fan Module On The Backplane Connector

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Figure 192. Securing the AT-SBxFAN12 Fan Module on the Backplane Connector 3. With a #2 Phillips-head screwdriver, tighten the screw at the base of the module to secure the module to the chassis. Refer to Figure 193 on page 302.

  • Page 302: Figure 193: Tightening The Screw On The At-Sbxfan12 Fan Module

    Chapter 13: Replacing Modules Figure 193. Tightening the Screw on the AT-SBxFAN12 Fan Module 4. Reconnect any network cables you may have disconnected to access the fan module. Section II: Installing the Chassis...

  • Page 303: Chapter 14: Upgrading The Controller Fabric Card

    Chapter 14 Upgrading the Controller Fabric Card This chapter contains the procedure for upgrading the AT-SBx8112 Chassis from the AT-SBx81CFC400 Controller Fabric Card to the AT- SBx81CFC960 Card. The chapter contains the following sections:  “Before You Begin” on page 304 ...

  • Page 304: Before You Begin

    Chapter 14: Upgrading the Controller Fabric Card Before You Begin The instructions in this chapter explain how to update a chassis from the AT-SBx81CFC400 Controller Fabric Card to the AT-SBx81CFC960 Card. Here are the basic steps to the procedure: 1. Download the configuration file on the AT-SBx81CFC400 Controller Fabric Card to a flash drive with the COPY command in the Privileged Exec mode of the command line interface.
  • Page 305 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Card in the chassis has a feature license, you must order a new license from Allied Telesis for the AT-SBx81CFC960 Card and install it after installing the new controller card. ...

  • Page 306: Upgrading The Controller Fabric Card

    Chapter 14: Upgrading the Controller Fabric Card Upgrading the Controller Fabric Card This section contains step-by-step instructions on how to upgrade the chassis from the AT-SBx81CFC400 Controller Fabric Card to the AT- SBx81CFC960 Card. Caution This procedure is disruptive to network operations because it requires powering off the chassis.
  • Page 307 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide 7. Power off the chassis. 8. Remove the AT-SBx81CFC400 Controller Fabric Card from the unit. If the unit has two controller cards, remove both cards. 9. Install the new AT-SBx81CFC960 Card. If there are two cards, install both cards.
  • Page 308 Chapter 14: Upgrading the Controller Fabric Card controller card. The name can be the same as or different from the source filename. The filename must include the suffix “.cfg”. This example of the command copies the Enginerring_sw1.cfg configuration file from flash drive to the controller card: copy usb:/Engineering_sw1.cfg Engineering_sw1.cfg This example of the command copies the switch2a_rm12.cfg configuration file from flash drive to the controller card, and renames it...
  • Page 309 SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide refer to the Software Reference for SwitchBlade x8100 Series Switches. Section II: Installing the Chassis...
  • Page 310 Chapter 14: Upgrading the Controller Fabric Card Section II: Installing the Chassis...

  • Page 311: Section Iii: Building A Stack With Vcstack Plus

    Section III Building a Stack with VCStack Plus This section contains the following chapters:  Chapter 15, “VCStack Plus Overview” on page 313  Chapter 16, “Building a Stack” on page 327...

  • Page 313: Chapter 15: Vcstack Plus Overview

    Chapter 15 VCStack Plus Overview This chapter contains a brief overview of the VCStack Plus feature. For more information, refer to the Software Reference for SwitchBlade x8100 Series Switches. The chapter contains the following sections:  “Overview” on page 314 ...

  • Page 314: Overview

    Chapter 15: VCStack Plus Overview Overview The VCStack Plus feature is an optional feature for the AT-SBx8112 Chassis. The feature is used to connect two chassis together so that the devices function as a single networking unit. This is referred to as a virtual switch.

  • Page 315: Stack Trunk

    7 meters (23.0 feet) If the switches are further apart, you can build the trunk with short or long distance Allied Telesis 10G SFP+ fiber optic transceivers. A list of supported transceivers is available from the product data sheet or the Allied Telesis web site.
  • Page 316 Chapter 15: VCStack Plus Overview Please review the following information:  You must build the trunk with Allied Telesis 10Gbps SFP+ transceivers or direct connect cables. The switches will not form the stack with transceivers or cables from other network equipment manufacturers.

  • Page 317: Cabling Configurations For The Trunk

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Cabling Configurations for the Trunk This section illustrates the cabling configurations for the trunk of the stack. One Controller Figure 194 illustrates the correct wiring configuration for the trunk when each chassis has only one AT-SBx81CFC960 Controller Fabric Card. The Card Per Chassis transceiver in SFP+ port 1 in the controller card in the first chassis is connected to the transceiver in SFP+ port 1 in the card in the second...

  • Page 318: Two Controller Cards Per Chassis

    Chapter 15: VCStack Plus Overview Two Controller Figure 195 illustrates the wiring configuration of the trunk when both switches have two controller cards. Cards Per Chassis Figure 195. Cabling the SFP+ Ports When Both Switches have Two Controller Cards Table 31 on page 319 presents the same information, in table format. Section III: Building a Stack with VCStack Plus...

  • Page 319: Table 31. Cabling The Sfp+ Ports When Both Switches Have Two Controller Cards

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 31. Cabling the SFP+ Ports When Both Switches have Two Controller Cards Chassis 1 Connects to Chassis 2 port1.5.1 <----------------> port2.5.1 port1.5.2 <----------------> port2.5.2 port1.5.3 <----------------> port2.6.3 port1.5.4 <----------------> port2.6.4 port1.6.1 <---------------->...

  • Page 320: Vcstack Plus Feature License

    VCStack Plus Feature License An important component of the stack is the VCStack Plus feature license from Allied Telesis. The license contains an activation code that activates the stacking feature in the management software on the controller cards in the chassis.

  • Page 321: Optional Feature Licenses

    Here are the guidelines to ordering and installing feature licenses.  Feature licenses are ordered from Allied Telesis on a per chassis basis.  A chassis that has two controller cards needs only one feature license.

  • Page 322: Chassis Id Numbers

    Chapter 15: VCStack Plus Overview Chassis ID Numbers The switches in the stack have to be assigned ID numbers. The valid ID numbers are 1 and 2. A switch can have only one ID number. The two switches of the stack must be assigned different ID numbers. The switches will not form a stack if they have the same ID number.

  • Page 323: Priority Numbers

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Priority Numbers The switches of the stack perform an initialization procedure whenever they are reset or powered on. During the process, which involves activating the management software and forming the stack, the units select the active master controller card.
  • Page 324 Chapter 15: VCStack Plus Overview optional. If you choose not to set the value, the controller cards use their MAC addresses to select the active master controller card for the stack. The process for selecting the active master controller card is different if the two switches are reset or power on one after the other.

  • Page 325: Stacking Guidelines

    The trunk that connects the two switches of the stack are built with SFP+ transceivers in the SFP+ ports in the controller cards. The transceivers must be from Allied Telesis.  There cannot be any network devices, such as other switches or media converters, between the stacking transceivers in the two switches.
  • Page 326 Chapter 15: VCStack Plus Overview Section III: Building a Stack with VCStack Plus...

  • Page 327: Chapter 16: Building A Stack

    Chapter 16 Building a Stack This chapter contains step-by-step instructions on how to configure the switches to build a stack with the VCStack Plus feature. The chapter contains the following sections:  “Before You Begin” on page 328  “Displaying the Management Software Version Number” on page 329 ...

  • Page 328: Before You Begin

    Chapter 16: Building a Stack Before You Begin Please review the following information before you begin to configure the switches for stacking:  You must perform the procedures in the order presented here.  You should configure only one chassis at a time. ...

  • Page 329: Displaying The Management Software Version Number

    If the management software is version 5.4.5 or later, continue with the next step.  If the management software is version 5.4.4, Allied Telesis recommends upgrading the controller card to version 5.4.5 or later. Version 5.4.4 supports stacking, but only with AT-Stack/OP transceivers for the stack trunk.
  • Page 330 Chapter 16: Building a Stack 7. Do one of the following:  If you are configuring the first chassis of the stack, write down on paper the software version number of the AlliedWare Plus operating software on the active controller card. You will compare it with the same information on the second chassis to confirm that both units have the same version of management software.

  • Page 331: Activating The Vcstack Plus Feature License

     The encryption keys on the VCStack Plus feature licenses you receive from Allied Telesis may be the same or different. The two switches can form a stack regardless of whether the encryption keys are the same or different.

  • Page 332: Figure 198: License Command

    Chapter 16: Building a Stack Note If the chassis has two controller cards, the active controller automatically activates the VCStack Plus feature license on the standby controller. After you enter the command, the switch displays the prompt in Figure 198: A restart of affected modules may be required.

  • Page 333: Enabling The Stacking Feature

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Enabling the Stacking Feature Now that you have activated the VCStack Plus feature license on the controller card, you may enable the stacking feature, as explained in this section. To activate the stacking feature, perform the following procedure: 1.
  • Page 334 Chapter 16: Building a Stack Table 32. Descriptions of the STACK ENABLE Command Messages Message Description This message reminds you that Save the config and restart the you need to save the configuration system for this change to take change and reboot the switch to effect.

  • Page 335: Displaying The Feature Licenses

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Displaying the Feature Licenses The two switches of a stack must have the same feature licenses. Otherwise, they will not form a stack. To compare the licenses of the switches, perform the following procedure: 1.
  • Page 336 Chapter 16: Building a Stack the first chassis. If the two chassis have the same licenses and enabled features, you may go to “Setting the ID Number” on page 337. If they are different, do not continue. The two chassis cannot form a stack if they do not have identical features.

  • Page 337: Setting The Id Number

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Setting the ID Number The chassis must be assigned the ID number 1 or 2. The ID number is used to identify the chassis when you configure the device with the command line interface.

  • Page 338: Figure 204: Stack Renumber Command Messages

    Chapter 16: Building a Stack configuring the first switch of the stack and want to assign it the number 1, you probably do not need to set the number because that is the default value.  If you need to change the ID number for the chassis, continue with step 3.

  • Page 339: Table 33. Descriptions Of The Stack Renumber Command Messages

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Table 33. Descriptions of the STACK RENUMBER Command Messages Message Description This message reminds you that Warning: Stacking is currently even though you activated the disabled. stacking feature with the STACK ENABLE command in an earlier procedure, the feature is disabled because the chassis has not been...

  • Page 340: Figure 205: Show Stack Command

    Chapter 16: Building a Stack Virtual Chassis Stacking summary information Pending ID MAC address Priority Status Role eccd.6d9e.07e1 Ready Active CFC eccd.6d9e.0145 Ready Backup Member Current ID Pending ID Number Number Figure 205. SHOW STACK Command 7. Verify the pending ID number change. Each controller card should now have two ID numbers.

  • Page 341: Setting The Priority Number

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Setting the Priority Number This procedure is optional. It explains how to set the stack priority number on the chassis, which controls the selection of the active controller card for the stack. For background information, refer to “Priority Numbers” on page 323.

  • Page 342: Powering Off The Chassis

    Powering off the chassis to install the SFP+ transceivers for the trunk is optional. The transceivers are hot-swappable and can be installed while the chassis is powered on. However, Allied Telesis recommends that both chassis be powered off when you power on the stack for the first time.

  • Page 343: Configuring The Second Chassis

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Configuring the Second Chassis Configure the second chassis by repeating the previous procedures, starting with “Displaying the Management Software Version Number” on page 329. Please note the following as you configure the second unit: ...

  • Page 344: Cabling The Sfp+ Slots On The Controller Cards

    Chapter 16: Building a Stack Cabling the SFP+ Slots on the Controller Cards Now that you have configured both chassis for the stacking feature, you are ready to cable the SFP+ slots on the controller cards to build the trunk between the two units.

  • Page 345: Powering On The Stack

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Powering On the Stack The two switches are now ready to operate as a stack. But before powering on the stack for the first time, you may find it useful to review the information in “Controlling the Selection of the Initially Active Master Controller Card”...

  • Page 346: Powering On The Switches

    Chapter 16: Building a Stack stack and its configuration file is used as the initial configuration for the stack. After the stack is operating, the active master card periodically shares its configuration file with all the other controller cards in the stack. Thus, the order in which the units are subsequently reset or powered on is not important because all the controller cards have the same configuration file.

  • Page 347: Figure 206: Initialization Messages For The Stack

    Verifying release... OK Booting... Starting base/first... [ OK ] Mounting virtual filesystems... [ OK ] Allied Telesis Inc. AlliedWare Plus (TM) v5.4.5 Current release filename: SBx81CFC960-5.4.5-0.0.rel Original release filename: SBx81CFC400-5.4.5-.0.rel Built: Thu Dec 19 21:30:52 NZDT 2014 Mounting static filesystems...

  • Page 348: Figure 207: Initialization Messages For The Stack (Continued)

    Chapter 16: Building a Stack Received event network enabled Initializing HA processes: cbtrd, hostd, nms, atmfd, bgpd, epsr exfx, hsl, imi, imiproxyd, irdpd, lacp, lldpd loopprot, mstp, ospf6d, ospfd, pdmd, pim6d, pimd ripd, ripngd, rmon, sflowd, udidd, vrrpd Received event network.initialized 08:00:54 awplus-1.5 chassis[2105]: Waiting for all chassis cards to initialize.

  • Page 349: Verifying The Stack

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Verifying the Stack After resetting or powering on the devices and waiting four minutes for the switches to complete initializing the management software and form the stack, you should verify the stack. To verify the stack, perform the following procedure: 1.
  • Page 350 Chapter 16: Building a Stack 4. Do one of the following:  If the SHOW STACK command is displaying all the controller cards in the stack, the stack is operating normally. If you have optional feature licenses to install, go to “Installing Optional Feature Licenses”...

  • Page 351: Installing Optional Feature Licenses

    Please review the following information before installing a feature license:  When ordering a feature license from Allied Telesis for the stack, you must order two licenses, one for each chassis. However, you use only one license to activate the feature. The active controller card automatically copies new feature license to all the controller cards in the stack, thereby activating the license on both switches.

  • Page 352: Troubleshooting The Stack

    Here are some things to check:  If the switches are using AlliedWare Plus v5.4.5 or later, verify that the SFP+ transceivers of the trunk are from Allied Telesis. The switches will not form the stack with transceivers from another network equipment manufacturer.
  • Page 353 Switches running AlliedWare Plus 5.4.5 or later display the following message if one or more of the SFP+ transceivers in the stack trunk are not from Allied Telesis. Replace the transceivers with transceivers from Allied Telesis. Only ATI qualified SFP+ modules are support in this port.
  • Page 354 Chapter 16: Building a Stack update the software on one of both systems so that they have the same version. chassis[nnn]: Neighbor on link portn.n.n cannot join stack - incompatible stack S/W versions. Section III: Building a Stack with VCStack Plus...

  • Page 355: Appendix A: Technical Specifications

    Appendix A Technical Specifications The sections in the appendix are listed here:  “Physical Specifications” on page 356  “Environmental Specifications” on page 359  “Power Specifications” on page 360  “Safety and Electromagnetic Emissions Certifications” on page 364  “Port Pinouts”...

  • Page 356: Physical Specifications

    (1.03 in x 11.73 in x 4.05 in) Line Cards AT-SBx81GT24 AT-SBx81GT40 20.67 x 31.32 cm x 4.06 cm AT-SBx81GP24 (8.14 in x 12.33 in x 1.6 in) AT-SBx81GS24a AT-SBx81GC40 AT-SBx81XS6 AT-SBx81XS16 AT-SBx81XLEM AT-SBx81XLEM Expansion Modules AT-SBx81XLEM/GT8 9.4 cm x 16.0 cm x 3.6 cm (3.7 in x 6.3 in x 1.4 in)

  • Page 357: Table 35. Product Weights

    1.04 kg (2.30 lb) AT-SBx81GP24 PoE Line Card 1.06 kg (2.34 lb) AT-SBx81GS24a SFP Line Card 1.06 kg (2.34 lb) AT-SBx81GC40 SFP and CSFP 1.11 kg (2.45 lb) Line Card AT-SBx81XS6 SFP+ Line Card 1.06 kg (2.34 lb) AT-SBx81XS16 SFP+ Line Card 1.4 kg (3.09 lb)
  • Page 358 Appendix A: Technical Specifications Table 35. Product Weights (Continued) AT-SBxPWRPOE1 PoE Power 2.73 kg (6.00 lb) with power cord Supply AT-SBxPWRSYS1 DC System 1.9 kg (4.2 lb) Power Supply AT-SBxFAN12 Tray Module 1.82 kg (4.00 lb)

  • Page 359: Environmental Specifications

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Environmental Specifications Table 36. Environmental Specifications Operating Temperature -0° C to 40° C (32° F to 104° F) Storage Temperature -25° C to 70° C (-13° F to 158° F) Operating Humidity 5% to 90% non-condensing Storage Humidity 5% to 95% non-condensing...

  • Page 360: Power Specifications

    Typical power savings in eco-friendly mode (Watts) Table 40. Typical Power Savings in eco-friendly Mode AT-SBx81GT24 0.12 W AT-SBx81GT40 0.79 W AT-SBx81GP24 0.24 W AT-SBx81GS24a 0.20 W AT-SBx81GC40 0.42 W AT-SBx81XS6 0.10 W AT-SBx81XS16 0.66 W AT-SBx81XLEM (no expansion 0.14 W module) AT-SBx81XLEM and AT- 0.25 W...

  • Page 361: Table 41. Maximum Power Consumption

    Maximum power consumption (Watts) Table 41. Maximum Power Consumption AT-SBx81GT24 34.4 W AT-SBx81GT40 53.9 W AT-SBx81GP24 34.4 W AT-SBx81GS24a 56.3 W AT-SBx81GC40 64.0 W AT-SBx81XS6 54.8 W AT-SBx81XS16 78.4 W AT-SBx81XLEM (no expansion 43.7 W module) AT-SBx81XLEM and AT- 48.6 W...

  • Page 362: Table 43. Heat Dissipation

    Heat dissipation (British Thermal Units/hour) Table 43. Heat Dissipation AT-SBx81GT24 117.39 BTU/hr AT-SBx81GT40 183.93 BTU/hr AT-SBx81GP24 117.39 BTU/hr AT-SBx81GS24a 192.12 BTU/hr AT-SBx81GC40 272.8 BTU/hr AT-SBx81XS6 187.00 BTU/hr AT-SBx81XS16 267.6 BTU/hr AT-SBx81XLEM (no expansion 149.19 BTU/hr module) AT-SBx81XLEM and AT- 165.88 BTU/hr...

  • Page 363: Table 44. Available Power Over Ethernet With One Poe Power Supply

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Available Power over Ethernet (Watts/port): Table 44. Available Power Over Ethernet with One PoE Power Supply One PoE Power Supply Installed 1200 W @ 56 VDC IEEE 802.3at Class 4 (30 W /port) 40 ports Maximum IEEE 802.3af Class 3 (15.4 W /port) 77 ports Maximum IEEE 802.3af Class 2 (7.3 W /port) 171 ports Maximum...

  • Page 364: Safety And Electromagnetic Emissions Certifications

    Appendix A: Technical Specifications Safety and Electromagnetic Emissions Certifications Safety and Electromagnetic Emissions: Table 47. Safety and Electromagnetic Emissions EMI/RFI FCC Class A, EN55022 Class A, EN61000-3-2, EN61000-3-3, CISPR Class A, VCCI Class A, AS/NZS Class A Immunity EN55024 Electrical Safety EN60950-1 (TUV), UL60950-1 ), EN60825 Safety Agency Approvals...

  • Page 365: Port Pinouts

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Port Pinouts This section has the pinouts for the RJ-45 and RJ point 5 ports on the following devices:  AT-SBx81GT24 Line Card  AT-SBx81GT40 Line Card  AT-SBx81GP24 Line Card ...

  • Page 366: Table 49. Mdi-X Pin Signals (10Base-T Or 100Base-Tx)

    Appendix A: Technical Specifications Table 49. MDI-X Pin Signals (10Base-T or 100Base-TX) Signal Table 50 lists the port pin signals for twisted pair ports operating at 1000 Mbps or 10 Gbps. Table 50. 1000Base-T or 10GBase-T Connector Pinouts Pair Signal TX and RX+ TX and RX- TX and RX+...

  • Page 367: Fiber Optic Specifications Of The At-Stackop/0.3 And At-Stackop/9.0 Transceivers

    SwitchBlade x8112 Chassis Switch and AT-SBx81CFC960 Card Installation Guide Fiber Optic Specifications of the AT-StackOP/0.3 and AT-StackOP/9.0 Transceivers Table 51 lists the fiber optic port specifications for the AT-StackOP/0.3 transceiver. Table 51. Fiber Optic Port Specifications for the AT-StackOP/0.3 Module General Maximum Distances 33 m with 62.5/125 µm (core/...
  • Page 368 Appendix A: Technical Specifications Table 52. Fiber Optic Port Specifications for the AT-StackOP/9.0 Transceiver (Continued) Transmitter Wavelength 1310 nm Output Optical Power -8.2 dBm min. +0.5 dBm max. Receiver Wavelength 1310 nm Maximum Sensitivity -14.4 dBm Maximum Input Power 0.5 dBm...

This manual is also suitable for:

Switchblade x8112

Table of Contents
