3

Overviews

Overviews
20
19
18
17
16
15
0252_003-066
1 Mast
2 Lift chains
3 Protective screen
4 Tiller
5 Emergency isolator button
6 Fuse carrier
7 Battery connector
8 Built-in battery charger (if present)
9 Pump motor
10 Hydraulic oil reservoir
26
14
13
45728043430 EN - 05/2017
1
2
11
12
11 Stabiliser wheel
12 Traction wheel
13 Gearbox
14 Traction motor
15 Brake
16 Forks
17 Load wheels
18 Electronic panel
19 Battery
20 Lift cylinder
Overview
3
4
5
6
7
8
9
10
