Application
Driving
Check the information on the
combined indicator
The instrument can display several of the
truck's functions:
Discharge indicator
1
2
The discharge indicator (3) operates after
the battery connector has been connected.
Monitoring the discharge process protects the
battery against significant discharge.
When the battery is fully charged, the 10 status
3
bars are lighted. As battery capacity falls, the
display moves to the left.
If the battery is 80% discharged, two status
bars are lit. The lifting function is switched off.
The battery must be recharged.
Hourmeter
4
The hour meter (4) indicates the number of
0252_003-049-V2
operating hours of the machine.
The display is activated as soon as the
machine is switched on. The green indicator
light (2) comes on.
