4
Moving the load
CAUTION
Insert the fork without bumping into either the
shelving or the load.
– Insert the forks as far as possible below
the load. If possible, the forks should be
inserted far enough in that the load is resting
against the fork carriage. The load centre of
gravity must be centred between the forks.
DANGER
Pay attention to the part of the forks protruding from
the load to be lifted.
Do not strike the wall, the shelving or other loads
and/or objects behind the load to be picked up.
– Lift the load a few centimetres from the
ground and read the "Transporting loads"
section.
Load pick up from shelving.
– Approach the shelving at moderate speed.
Use the drive control throttles to gradually
slow down and stop the truck perpendicular
to the shelving with the tiller in the braking
position.
– Check that there is sufficient space between
the forks and the shelving.
