Tiller controls
Slow-speed button (8) (optional — Creep
Speed)
• The button (8) is fitted with the optional "tiller
always active" option (Creep Speed)
• Keeping the button (8) pressed while
turning the throttle (2 – 3) activates creep
speed, regardless of the tiller position
• Keeping the button (8) pressed at the same
time as the fork lifting button (5) activates
fork lifting, regardless of the tiller position
NOTE
This function is ideal for manoeuvres in
confined spaces.
Initial lift (9 and 10) (optional)
The straddle lifting function increases the
ground clearance, meaning that the truck can
be used on uneven ground or slopes.
WARNING
Risk of crushing feet.
Be careful not to put your feet under the straddles
while using the initial lift function.
Straddle lifting button (9)
• Press the button (9) to lift the straddles;
when the button is released, the straddles
will stop in the position reached
• The straddle lifting button (9) is active only
when the tiller is angled to the working
position
Straddle lowering button (10)
• Press the button (10) to lower the straddles;
when the button is released, the straddles
will stop in the position reached
• The straddle lowering button (10) is active
only when the tiller is angled to the working
position
