Safety devices

Safety devices

Location of safety devices

Main safety devices on the truck
The operator must be aware of the following
safety devices:
1 Guard grille
2 Anti-crush safety feature
3 Braking by releasing the drive control throttle
4 Emergency stop button
5 OptiSpeed tiller
6 Protective guard
NOTE
These devices must be checked daily, as
described in Chapter 4.
20
7 Horn
8 Electromagnetic brake
9 Truck braking when the tiller arm reaches
the upper end position and lower end
position.
10 Automatic speed reduction with forks raised
approximately 500 mm above the ground.
(only available on 1400 kg version)
