Maintenance
– Check the condition of the following fuses:
F1 300 A main fuse
F3 7.5 A main fuse
.

Replacing the battery from above for trucks with 1000 kg and 1200 kg capacity

– Before replacing the battery, carry out the
preliminary operations for maintenance:
park the truck on a flat surface, switch off
the truck and then press the emergency off
button.
– Remove the battery hood: open the battery
hood, turn the clasp upwards (3) until it
reaches the (B) position and then remove
the hood by sliding it off sideways.
– Disconnect the socket from the battery male
connector.
45728043430 EN - 05/2017
Maintenance plans
F1
B
A
5
F3
0252_003-089
3
2341
