Checks and actions prior to use
• Check that the battery wiring is intact;
• Check that the battery lock system is
operating correctly (only for trucks designed
for side removal of the battery). Check that
the battery is locked in place.
• Check the correct operation of the auto-
matic speed reduction system with forks
raised approximately 500 mm above the
ground. (only available on 1400 kg version)
DANGER
If you notice any malfunctions or if you have any
doubts about the correct operation of the truck,
DO NOT use the truck, but call the manufacturer's
authorised service network.
Checking the anti-crush safety
device
Anti-crush safety function
The truck moves in reverse when the anti-
crush button (2) is pressed.
If the truck is being operated in narrow areas
such as a lift, for example, the operator may
hit the wall if care is not taken. The operator
would be injured by the tiller if this occurred
and the truck was not fitted with an anti-crush
device.
The truck automatically shifts into reverse
when the anti-crush device on the tiller head
comes into contact with the driver's body.
When the operator moves away from the
anti-crush device, the vehicle stops, even if
forward travel is selected again.
Normal operation may be resumed after
releasing the throttles.

Checking the anti-crush safety device

WARNING
Ensure that the test area is free of people and
objects, both in front of and behind the truck.
– Operate the throttle (1) or (3) for forward
travel.
60
3
45728043430 EN - 05/2017
Application
2
1
0203_003-010
