  • Page 1 Original instructions Electric pallet truck EXD-S 0282 50028043344 EN - 01/2018...
  • Page 3 • Information on transport, initial commis- sioning and storage of industrial trucks Internet address and QR code The information can be accessed at any time by pasting the address https://m.still.de/vdma in a web browser or by scanning the QR code. 50028043344 EN - 01/2018...

  • Page 5: Table Of Contents

    Table of contents Introduction Forklift data ............2 General information .
  • Page 6 Table of contents Overviews Technical description ..........22 Sample graphics .
  • Page 7 Table of contents Driving ............48 Driving safety guidelines .
  • Page 8 Table of contents Handling the battery ..........82 Battery type .
  • Page 9 Table of contents Technical data Dimensions ............108 VDI data sheet for standard EXD-S 20 .

  • Page 11: Introduction

    Introduction...

  • Page 12: Forklift Data

    Introduction Forklift data Forklift data We recommend that you record the principal forklift data in the following table so that they are available if required by the sales network or authorised service centre. Type Serial number Date of delivery General information •...
  • Page 13 Introduction How to Consult the Manual CAUTION ENVIRONMENT NOTE Failure to observe the instructions highlighted with Failure to observe the instructions highlighted this symbol may cause damage to the forklift and, with this symbol may cause environmental in some cases, result in warranty invalidity. damage.

  • Page 14: Date Of Edition And Latest Update Of This Manual

    Introduction Date of edition and latest update of this manual Date of edition and latest update of this manual The publication date of these operating instructions is printed on the cover sheet. The manufacturer makes continuous efforts to improve its industrial trucks, and therefore reserves the right to implement changes and to accept no claims concerning the information provided in this manual.

  • Page 15: Ce Labelling

    Introduction CE labelling CE labelling The manufacturer uses CE labelling to indi- cate that the truck complies with the standards and regulations valid at the time of marketing. This is confirmed by the issued EC declaration of conformity. The CE labelling is attached to the nameplate.

  • Page 16: Ec Declaration Of Conformity In Accordance With Machinery Directive

    Introduction EC declaration of conformity in accordance with Machinery Directive EC declaration of conformity in accordance with Machinery Di- rective Declaration STILL GmbH Berzeliusstraße 10 D-22113 Hamburg Germany We declare that the according to these operating instructions Industrial truck according to these operating instructions Model conforms to the latest version of the Machinery Directive 2006/42/EC.

  • Page 17: Technical Service And Spare Parts

    Introduction Technical service and spare parts Technical service and spare parts For scheduled maintenance and any repairs to the technical characteristics of the forklift over the forklift, contact only the authorised service time. network. Only original spare parts provided by the man- The authorised service network has personnel ufacturer may be used for forklift maintenance trained by the manufacturer, original spare...

  • Page 18: Modifications To Forklift

    Introduction Modifications to Forklift Do not use beyond the limits of the climatic use precautions are necessary. Contact the conditions indicated below: authorised sales network for more informa- tion. • Maximum ambient temperature: +40°C • Minimum ambient temperature: +5°C DANGER •...

  • Page 19: Environmental Considerations

    Introduction Environmental considerations Environmental considerations Disposal of components and batteries The truck is composed of different materials. If components or batteries need to be replaced and disposed of, they must be: • disposed of, • treated or • recycled in accordance with regional and national regulations.

  • Page 20: Packaging

    Introduction Environmental considerations Packaging During delivery of the truck, certain parts are packaged to provide protection during transport. This packaging must be removed completely prior to initial start-up. ENVIRONMENT NOTE The packaging material must be disposed of properly after delivery of the truck. 50028043344 EN - 01/2018...

  • Page 21: Safety

    Safety...

  • Page 22: Safety Guidelines

    Safety Safety guidelines Safety guidelines General Precautions regulations integrate those in the manual NOTE "Rules for approved use of industrial vehicles". Some safety regulations to be followed when using the forklift are listed below. These General Safety Rules • Only allow qualified, trained and authorized •...

  • Page 23: Battery Connection Cables

    Safety Safety guidelines CAUTION Passing over cracks or damaged parts of the floor with the truck is prohibited. Dirt and any objects in the work path must be removed immediately. Battery connection cables CAUTION Using sockets with NON-ORIGINAL battery con- nection cables can be dangerous (see purchase references in the parts catalogue) Requirements for the traction-battery...

  • Page 24: Safety Regulations Relative To Operating Materials

    Safety Safety guidelines Safety Regulations Relative to Operating Materials Rules for handling and disposing of Oils operating materials • Do not allow to come into contact with the skin. ENVIRONMENT NOTE • Do not inhale oil vapors. Improper use and disposal of operating and •...

  • Page 25: Residual Risk

    Safety Residual risk and disposal of the life-expired battery must NOTE be carried out as required by law. We advise For greater information, consult the specific you to contact the authorised service network battery manual that comes with the battery. that is equipped for eco-friendly disposal in accordance with current regulations.
  • Page 26 Safety Residual risk • Human error resulting from failure to observe the safety guidelines. • Unrepaired damage or defective and worn components. • Insufficient maintenance and testing • Use of incorrect consumables • Maintenance intervals exceeded The manufacturer shall not be held responsi- ble for accidents involving the truck caused by the failure of the operating company to comply with these regulations either intentionally or...

  • Page 27: Electromagnetic Radiation

    Safety Electromagnetic radiation Electromagnetic radiation The limit values for electromagnetic emissions and for immunity relative to the forklift are those provided by the EN 12895 standard. Non-ionised radiation If the forklift is equipped at the factory or later with devices that emit non-ionising radiation (such as radio transmitters, RFID players, data terminals, scanners, etc), the compatibility of such devices must be verified...

  • Page 28: Vibrations

    Safety Vibrations Vibrations Vibrations to which the hands and arms CAUTION are exposed The value expressed above can be used to com- pare forklift trucks of the same category. It cannot The following value is valid for all truck models: be used to determine the operator's daily expo- •...

  • Page 29: Safety Tests

    Safety tests Regular safety inspection of the truck Safety inspection based on time and extraordinary incidents STILL GmbH Hamburg The operating company must ensure that the truck is checked at least once a year, or Regelmäßige Prüfung following noteworthy incidents.
  • Page 30 Safety Safety tests 50028043344 EN - 01/2018...

  • Page 31: Overviews

    Overviews...

  • Page 32: Technical Description

    1 tonne on ground proportional to the load on the forks. each level, for optimal loading/unloading of • For lateral stability, two exclusive STILL lorries and transfer of loads. twin wheels have been specially designed...
  • Page 33 Overviews Technical description Cockpit • Both EXD-S platform types always provide great comfort with their innovative, unique, • The new "cockpit" console contains all the fully sprung platform floors. functions for access, operation and control • The truck incorporates various storage on the EXD-S.

  • Page 34: Sample Graphics

    Mast and initial lift tive 98/37 and carry the "CE" symbol. • The new mast design provides excellent • STILL is certified to ISO 9001. visibility when loading. • Optispeed allows speed reduction with • Full view of the load.

  • Page 35: Overviews

    Overviews Overviews Overviews 0249_003-002 Lift cylinder main lift Drive motor Mast Steering motor Emergency stop switch Steer control Cockpit Brake Lift cylinder, basic lift Fuse mount Pump motor Battery Hydraulic oil tank Load wheel Stabiliser Forks Gearbox Travel control Traction wheel Protective screen 50028043344 EN - 01/2018...

  • Page 36: Control And Display Elements

    Overviews Control and display elements Control and display elements View of the control elements 0249_003-003 Battery cover Battery compartment lock Cockpit Document holder Emergency isolator button 50028043344 EN - 01/2018...

  • Page 37: Cockpit

    Overviews Control and display elements Cockpit 6 7 8 0249_003-062 Lower button Numbers button Lift button button Hare Horn button Horn button button Main lift up button Tortoise PRG ↑ (scrolling) button Main lift down button Numbers button Handle Display Travel control (ON) button Emergency brake switch...

  • Page 38: Markings

    Overviews Markings Markings Location of plates and labels DANGER DANGER DANGER DANGER DANGER DANGER DANGER DANGER 0249_003-004 Brand label Label "Danger of getting pinched for hands" Label "Fill hydraulic oil here" Label "Danger of getting pinched for feet" Brand label and truck designation Manufacturer's plate Label "Lifting slings here"...

  • Page 39: Chassis Frame Labelling

    Overviews Markings Notice labels The warning labels and warning notices must always be obeyed. Chassis frame labelling The truck's serial number is marked on the chassis frame (1). 2265 50028043344 EN - 01/2018...

  • Page 40: Data Plate

    Overviews Options and variants Data plate NOTE Please indicate the serial number for all technical enquiries. 2327 Model Rated capacity in kg Manufacturer Serial no. Unladen weight (without battery) in kg Year of manufacture EC conformity symbol QR code Battery voltage V Nominal power rating in kW Minimum battery weight Maximum battery weight...

  • Page 41: Overview Of Accessories

    Overviews Options and variants • Document holder • Preparation for data input terminal • Customer's logo • Rollover bar (various types) • FleetManager • Tray 71 • Battery electrolyte level indicator LED Overview of accessories • Master code (factory setting "1 2 3 4") •...
  • Page 42 Overviews Options and variants 50028043344 EN - 01/2018...

  • Page 43: Application

    Application...

  • Page 44: Authorised And Safe Use

    Application Authorised and safe use Authorised and safe use Intended use of the trucks CAUTION This machine is intended for the transport of loads packed on pallets or in industrial containers de- signed for this purpose, as well as for placing pallets into and removing pallets from stock.
  • Page 45 Application Authorised and safe use • The truck has not been designed to trans- port anyone other than the operator and must not be used for this purpose. • The operator must always stay within the truck clearance. • Stay in the safety area (working area defined by the manufacturer).

  • Page 46: Definition Of Directions

    Application Definition of directions There must be sufficient distance between the highest part of the truck or the load and the surrounding fixed installations. The height depends on the lift height and the dimensions of the load. Refer to the technical characteristics.

  • Page 47: Truck Transport And Lifting

    Application Truck transport and lifting Truck transport and lifting Transporting the truck The forklift is normally transported by road and rail. If the forklift's dimensions exceed the max. clearance size allowed, it is trans- ported disassembled. The sales network is in charge of the disassembly and reassembly operations.

  • Page 48: Checks And Actions Prior To Commissioning

    Application Checks and actions prior to commissioning Checks and actions prior to commissioning Visual inspections WARNING Damages or any other defects on the truck or the attachment (option) can lead to accidents. If damages or any other defects on the truck or on attachment (option) are detected during the following checks, do not use the truck until it is properly repaired.
  • Page 49 Application Checks and actions prior to commissioning – The latch (7) must be closed. – The battery cover (6) must be closed. 0249_003-006 – The cover (3) must be fitted. – The protective screen (2) must be fitted and undamaged. –...

  • Page 50: Connecting The Battery Plug (Charging Station)

    Application Checks and actions prior to commissioning Connecting the battery plug (charg- ing station) – Disconnect the battery socket (1) from the charging station and insert into the plug on the truck. 0249_003-080 – The latch (2) must be closed. –...

  • Page 51: Commissioning

    Application Commissioning Commissioning Turning on the truck NOTE The pallet truck is equipped with a digital control and is taken into operation by entering a driver code. The driver code consists of four figures and is assigned by the pool manager. It is used for normal use and operation of the truck by the driver and operator.

  • Page 52: Entering The User Code

    Application Commissioning Entering the user code – Press the key (on) (6). The display (4) shows the message (8). This Code message switches off after approximately one second. You can then enter the 4-digit user code. The digits are entered in the same way as on a mobile phone.

  • Page 53: Starting With Fleetmanager (Optional)

    Application Commissioning – The digit will be deleted and the flashing line (9) will reappear. It is now possible to enter digits again. – After the fourth digit has been entered, confirm this code by pressing (5). PRG ↲ The name of the truck manufacturer is displayed.

  • Page 54: Hour Meter

    Battery discharge indicator – Press the key (browse) (4) to view PRG ↑ the battery charge (3) that is still available. NOTE The correct battery charge status is only indicated approx. 1 minute after connection. The charge status is indicated in % and updates in increments of 5%.

  • Page 55: Display Of Time To Next Servicing

    Application Commissioning Display of time to next servicing – Press the (scrolling) button (4) to PRG ↑ display the time remaining until the next scheduled servicing. The time is shown in hours (6) and with the symbol of a spanner (5).

  • Page 56: Check Of Brake And Presence Area

    Application Commissioning Check of brake and presence area – Start the truck slowly with the throttle (1). 0249_003-065 – Step off the presence area (2) while leaving the throttle actuated. 0249_003-066 50028043344 EN - 01/2018...

  • Page 57: Checking The Emergency Brake Button

    Application Commissioning Checking the emergency brake button – Drive the truck slowly using the traction control (4). – Press the emergency brake button (5). The truck will be braked and remains stationary. – The signal appears on the display StoP (6).

  • Page 58: Driving

    Application Driving Driving Driving safety guidelines Behaviour when driving In the plant, the driver must drive the truck according to regulations for driving on public roads. The speed of the truck must be appro- priate for local conditions. For example, speed must be reduced when cornering, in narrow passages, when driving through swing doors, in areas with reduced visibility and/or on un-...

  • Page 59: Before Driving

    Application Driving Before driving Persons in the danger area Before and during operation of the truck, the driver must ensure that no person is standing in the danger area of the truck. A warning signal must be given in the event of danger to persons.
  • Page 60 Application Driving Dimensions of roads and working aisles The dimensions specified in the description section apply under established conditions and should ensure safe manoeuvring. Check in each case whether a wider aisle is required when, for example, the load dimensions deviate.

  • Page 61: Emergency Stop Procedure

    Application Driving railway crossings and the like must be level and, if necessary, provided with ramps so that they can be crossed without jolts, if possible. There must be sufficient clearance between the highest parts of the truck or load and fixed parts of the surroundings.

  • Page 62: Driving, Ride-On Standing Mode

    Application Driving Driving, ride-on standing mode – Stand upright, with feet placed in the presence zone (1) of the platform. NOTE The truck must be switched on. WARNING The platform floor must be kept free of any object that could activate the operator presence mat by its weight.

  • Page 63: Selecting The Driving Mode

    Application Driving Selecting the driving mode NOTE The pallet truck has 2 selectable driving modes. – For normal travel, push the button (3). Hare – To drive with gentle accelerations, push the button (2). Tortoise NOTE The travel control (4) and (5) can be operated with both the left and the right hand.
  • Page 64 Application Driving Soft braking NOTE The truck is braked electrically. – Release throttle (3) or (4) when driving. 0249_003-067 – Leave the presence area (5). Average braking – Operate the butterfly valve (3) or (4) in the opposite direction. Emergency braking CAUTION This type of braking may only be used in an emer- gency.

  • Page 65: Speed Limitation

    Application Driving The truck is braked by the electromagnetic brake. Speed limitation When the forks are lifted for more than 250 mm, the max. travel speed is reduced as follows: Forward travel 6 km/h Reverse travel 7 km/h > 250 mm 0249_003-011 50028043344 EN - 01/2018...

  • Page 66: Using The Truck On Inclines, Loading Bridges And Lifts

    Application Driving Using the truck on inclines, loading bridges and lifts. Driving on inclines Using the truck on a lift When driving the truck up or down inclines, Using the truck on lifts is only allowed if the you must not exceed the values for inclines lift has sufficient load capacity (check the indicated in the chapter "Technical data".

  • Page 67: Lifting

    Application Lifting Lifting Lifting devices The truck has 2 lifting devices: Initial lift (h5) The initial lift raises the wheel legs to 130 mm maximum. Main lift (h3) The main lift raises the forks to 1580 mm maximum. Types of masts Telescopic When the lift button is pushed, the inner mast 0249_003-012...

  • Page 68: Lifting Device Controls

    Application Lifting Lifting device controls WARNING Risk of injury! The safety regulations must be fol- lowed closely, see Link error: Target with XID = "Sicherheitsvorschriften_im_Um- gang_mit_Lasten" not found! Do not put your hands into moving truck parts (e.g. mast, sideshift, implements, load lifting device etc).
  • Page 69 Application Lifting Raising the initial lift – Press the initial lift button (2) to raise the wheel legs 130 mm. 0249_003-015 Lowering the initial lift – Press the initial lift button (1) to fully lower the wheel legs. 0249_003-016 50028043344 EN - 01/2018...

  • Page 70: Load Placement

    Application Load placement Load placement Safety regulations when handing loads DANGER DANGER Wear protective footwear. Risk of injury and crushing for the operator and for any pedestrians! Risk of damage to the truck and the goods CAUTION During movement of the truck and the loads, espe- cially in reverse gear, be careful not to hit any obst- Transporting passengers is strictly prohibited.

  • Page 71: Checks To Be Carried Out Before Lifting A Load

    Application Load placement Checks to be carried out before lifting a load WARNING Never exceed the capacity of the truck. This ca- pacity is based on the centre of gravity and the lift height of the load. Comply strictly with the load diagram! It is not permitted to increase the capacity by adding extra weight to the truck.

  • Page 72: Load Removal

    Application Load placement Load removal DANGER NOTE Before picking up the load, make sure that its di- Further information on the general rules of mensions and weight fall within the truck specifi- truck use and taking up and depositing loads cations, as indicated in the "TECHNICAL DATA"...
  • Page 73 Application Load placement Picking up one load – Lift the load (1) with the main lift, initial lift Fig 1 (2). Observe the data on the capacity plate (Fig. 1). 0249_003-017 – Before driving, lower the load (1) and the initial lift (2) (Fig.
  • Page 74 Application Load placement – Before driving, lower the upper load (1) as Fig 4 near as possible to the lower load (3) (Fig. 0249_003-020 Never lift or transport persons on the forks. Keeps your hands off moving parts of the truck (eg mast) DANGER CAUTION...
  • Page 75 Application Load placement Do not step under the elevated forks! CAUTION Risk of injury! 0249_003-021 50028043344 EN - 01/2018...

  • Page 76: Transporting Loads

    Application Load placement Transporting loads As a general rule, loads must be transported one by one (e.g. pallets). Transporting several loads at once is only authorised: • If the safety requirements are met • On the orders of the supervisor in charge The operator must ensure that the load is properly packaged.

  • Page 77: Driving Up And Down On An Incline

    Application Load placement Driving up and down on an incline When driving up and down on an incline, the load must always be carried uphill. It is only permitted to drive on inclines which are identified as suitable for traffic and which can be safely negotiated according to the technical data of the truck.

  • Page 78: Entering Lifts

    Application Load placement DANGER DANGER Risk of injury and crushing for the operator! Risk of Never leave the forklift with the forks raised whether damage to the truck and the goods loaded or not. During the entire load placement operation, be careful not to hit any obstacles.

  • Page 79: Cold Store Use

    Application Cold store use Cold store use Designation Your truck is fitted with special equipment for use in cold stores. It can be used for two operating ranges and carries a cold store label. The cold store equipment for the truck consists of using specialised oils (for the hydraulic installation and the gears) suitable for cold stores.
  • Page 80 Application Cold store use – Drive the truck for approximately 5 minutes and operate the brakes several times to ensure the truck operates safely. – Operate all the lifting functions several times. This warming up phase is required to allow the oil to reach operating temperature. Operating range 1 Permanent use in areas with temperatures of–5 °C and for short periods of time down to...

  • Page 81: Digicode

    Application Digicode Digicode Digicode control Access to the electronic control is granted with three different codes: • Driver's code • master code • service code Driver's code The driver's code consists of four digits and must be created by the Pool Manager. It is used for the regular utilisation and opera- tion of the truck by the driver and operator.

  • Page 82: Adding The Master Code

    Application Digicode Service code The service code is only intended for the after-sales service. It allows the diagnosis of the truck for inspections and the access to the driver's and master code. Adding the master code NOTE The truck is turned off, the battery is connec- ted.

  • Page 83: Deleting A Master Code

    Application Digicode – Confirm with the (enter) button (4). PRG ↲ 1044_505-012 A flashing line cursor (8) will appear in the display. – Enter the desired new 4-digit master code with the buttons (1), (2) or (3) as described above. NOTE The controller can store a maximum of five master codes.
  • Page 84 Application Digicode – Press the (ON) button (5). – Enter the valid 4-digit master code with the buttons (1), (2) and (3). 1044_505-009 – Scroll with the (scrolling) button (6) PRG ↑ 1044_505-010 until (7) appears in the display. – Confirm with the (enter) button (4) PRG ↲...

  • Page 85: Adding A Driver's Code

    Application Digicode – Confirm with the (enter) button (4) PRG ↲ 1044_505-013 until the master code (9) to be deleted blinks (an example is shown). – Then release the button. (10) will 1044_505-015 appear again in the display. – Press the (scrolling) button (6) until PRG ↑...
  • Page 86 Application Digicode – Scroll with the (scrolling) button (6) PRG ↑ 1044_505-016 until (7) appears in the display. USEr – Confirm with the (enter) button (4) PRG ↲ 1044_505-011 until (10) appears in the display. – Confirm with the (enter) button (4). PRG ↲...

  • Page 87: Deleting A Driver's Code

    Application Digicode Deleting a driver's code NOTE The truck is turned off, the battery is connec- ted. – Press the (ON) button (5). – Enter the valid 4-digit master code with the buttons (1), (2) and (3). 1044_505-009 – Scroll with the (scrolling) button (6) PRG ↑...
  • Page 88 Application Digicode – Confirm with the (enter) button (4) PRG ↲ 1044_505-013 until the driver's code (9) to be deleted blinks (an example is shown). – Then release the button. (10) will 1044_505-015 appear again in the display. – Press the (scrolling) button (6) until PRG ↑...

  • Page 89: Error Codes

    Application Error codes Error codes Error code 11 12 If an error code such as (15) appears, E380 shut the truck off by pressing button (10) and repeat the start-up ⇒ Chapter "Commission- ing", P. 41. If the error code persists, call your Service.

  • Page 90: Battery Electrolyte Level Indicator Led (Optional)

    Application Battery electrolyte level indicator LED (optional) Error code Description Action Right button operated at power-up. Release the right button (12). Horn Horn E380 Release the right button Lowering Right button operated at power-up. Lowering E381 (13). Right button operated at power-up. Release the right button (14).

  • Page 91: Handling The Truck In Specific Situations

    Application Handling the truck in specific situations Handling the truck in specific situations Hoisting the truck CAUTION Only use a lifting gear and crane with a sufficient load capacity. See the vehicle identification plate for the loading weight. – For hoisting with a crane, always attach the slings to the points identified with the hook symbol.

  • Page 92: Handling The Battery

    Application Handling the battery Handling the battery Battery type The pallet stacker can be equipped with different types of batteries. Observe the information on the nattery type plate. Also refer to ⇒ Chapter "VDI data sheet for standard EXD-S 20", P. 6-109 for this purpose. WARNING The weight and dimensions of the battery affect truck stability.

  • Page 93: Opening/Closing The Battery Compartment

    Application Handling the battery Safe parking Park the truck securely before carrying out work on the battery. The truck can only be operated when the battery cover is closed and the battery outlet is inserted. If the truck is enabled for side removal of the battery, the truck can only be operated once the battery is fixed in place properly using the battery locking system.
  • Page 94 Application Handling the battery – Disconnect the battery connector (3). WARNING Switch the truck and charger off before disconnec- ting the male and female connectors. – Connect the battery connector to the charger connector. NOTE Observe the information in the operating instructions for your battery and battery charger (equalising charge).

  • Page 95: Removing The Battery

    Application Handling the battery Removing the battery – Turn the lock (1) 90° and lift the battery cover (2). 0249_003-069 – Disconnect the battery connector (3). – Lift the battery latch (4) to release the battery. 0249_003-070 50028043344 EN - 01/2018...

  • Page 96: Installing The Battery

    Application Handling the battery – Put the battery trolley (6) opposite the battery. – Stand opposite the battery trolley and push the battery (5) onto the trolley. CAUTION Risk of injury through squeezing. Don't put the hands into the frame or between the battery and the battery trolley.

  • Page 97: Removing The Battery Cover

    Application Handling the battery – Close the battery latch (4). – Connect the battery connector (3). 0249_003-070 – Now the battery cover can be reinstalled. 0249_003-072 Removing the battery cover – Park the pallet truck. 50028043344 EN - 01/2018...
  • Page 98 Application Handling the battery – Push in the emergency isolator switch (2). – To open the battery compartment, turn the latch (1) 90 degrees. 0249_003-074 – Lift the battery cover (3) a few centimetres. 0249_003-075 50028043344 EN - 01/2018...

  • Page 99: Installing The Battery Cover

    Application Handling the battery – Remove the battery cover (3) by lifting. 0249_003-076 Installing the battery cover – Install the battery cover (1). 0249_003-077 50028043344 EN - 01/2018...
  • Page 100 Application Handling the battery – Close the battery cover (1). 0249_003-078 – To close the battery compartment, turn the latch (3) 90 degrees. – Release the emergency isolator switch (2). 0249_003-079 50028043344 EN - 01/2018...

  • Page 101: Decommissioning

    Application Decommissioning Decommissioning Safe parking of the truck – Park the truck in a dry, clean and well- ventilated area. WARNING Do not park the truck on gradients. In exceptional cases, secure the truck with chocks. – Lower the forks (1) on the ground. WARNING –...

  • Page 102: Storage

    Application Storage Storage Measures when storing the stacker for a longer period of time If the stacker is to be held in storage for a longer longer period of time, carry out the following corrosion protection measures. If the stacker is to be stored for over two months, park it in a clean and dry storage area, which is also well ventilated and frost-free.

  • Page 103: Taking Back Into Service After Storage

    Application Storage If the truck is to be taken out of service for an even longer period, contact your after-sales service. Taking back into service after storage If the pallet stacker has been out of service for over six months, it must be inspected carefully before it is taken back into service.
  • Page 104 Application Storage 50028043344 EN - 01/2018...

  • Page 105: Maintenance

    Maintenance...

  • Page 106: General Information

    Maintenance General Information General Information To keep your forklift in good condition, carry NOTE out the servicing indicated regularly, within the Contact the authorised service network for times indicated and using the consumption a maintenance contract appropriate to your materials provided for that purpose, as speci- forklift.

  • Page 107: Scheduled Maintenance

    Maintenance Scheduled maintenance Scheduled maintenance Summary table of maintenance operations EXD-S Operations Completed Intervals in hours 1000 2000 5000 Checks and tests prior to commissioning ● Check the hydraulic system oil level ● Test the insulation between the chassis ● and the electric motors Test the insulation between the chassis ●...
  • Page 108 Maintenance Scheduled maintenance etc.) or at least every 12 months (whichever comes first). 2000 = To be repeated every 2000 hours. For example at 2000, 4000, 6000, 8000, 10,000 etc.) 5000 = To be repeated every 5000 hours. For example at 5000, 10,000, 15,000, 20,000 etc.) ▲...

  • Page 109: Maintenance As Required

    Maintenance Maintenance as required Maintenance as required Cleaning the Forklift Cleaning depends on the type of use and the Use water-dampened rags to clean the parts workplace. Should the truck come into contact of the body. with highly aggressive elements such as salt CAUTION water, fertilizers, chemical products, cement, etc., it should be cleaned as carefully as...

  • Page 110: Fuses

    Maintenance Maintenance as required Fuses CAUTION Before performing any work on the electrical in- stallation, remove any power from the system by disconnecting the battery connector. – Open the battery cover (1). 0249_003-044 – Disconnect the battery connector (3). – Remove the bonnet (2) to gain access to the fuse carrier.

  • Page 111: Battery Replacement With Side Removal

    – Place the manufacturer-approved battery side-removal roller unit next to the truck; position it so that it is still and stable; adjust the height of the roller unit so that it is level with the underside of the battery at the...
  • Page 112 Maintenance Maintenance as required – Pull the battery outwards, sliding it along the rollers on the truck frame and positioning it on the previously prepared external roller unit. – Hook the battery at the two points (8) with a sling or chain. –...
  • Page 113 Maintenance Maintenance as required NOTE After having positioned the battery holddown, check that there is little or no clearance in the battery compartment. 50028043344 EN - 01/2018...

  • Page 114: Decommissioning

    Maintenance Decommissioning Decommissioning General Information The operations to be performed for "Tem- porary decommissioning" and "Permanent decommissioning" are listed in this chapter. 50028043344 EN - 01/2018...

  • Page 115: Forklift Towing

    Maintenance Decommissioning Forklift Towing The forklift may not be towed in the case of breakdown. The forklift must be lifted with due caution, as described on the preceding pages. Temporary Putting Out of Commission The following operations must be performed •...
  • Page 116 Maintenance Decommissioning 50028043344 EN - 01/2018...

  • Page 117: Technical Data

    Technical data...

  • Page 118: Dimensions

    Technical data Dimensions Dimensions 0249_003-081 50028043344 EN - 01/2018...

  • Page 119: Vdi Data Sheet For Standard Exd-S 20

    Technical data VDI data sheet for standard EXD-S 20 VDI data sheet for standard EXD-S 20 Designation EXD-S 20 EXD-S 20 Access from Access from Driver's platform rear the side Power source: Electric, Battery Battery diesel, petrol, LP gas, mains power Operator type: Hand, Ride-on...
  • Page 120 Technical data VDI data sheet for standard EXD-S 20 Basic dimensions EXD-S 20 EXD-S 20 Height with mast lowered h1 (mm) 1355 1355 Height of mast, retracted h1' (mm) 1410 1410 with free lift Lifting h3 (mm) 1580 1580 Overall height with mast h4 (mm) 2070 2070...

  • Page 121: Mast Types Exd-S

    Technical data Mast types EXD-S Motors EXD-S 20 EXD-S 20 Steering motor, rating S2 = 60 min Lift motor, rating S3 = 15% 2.2 kW S3, 5 2.2 kW S3, 5 Battery to DIN 43531/35/36 IEC 254-2: B IEC 254-2: B A, B, C, no Rated battery voltage C5 V/Ah...

  • Page 122: Battery Specifications (To Din 43531 B)

    Technical data Battery specifications (to DIN 43531 B) Battery specifications (to DIN 43531 B) CAUTION Only use batteries in accordance with DIN. The battery tray must be closed at the bottom. Do not change the location of added weights. Max. tray size in mm Weight in kg Battery type Capacity in Ah...

  • Page 123: Supply Table Exd Exd-Sf Exd-S

    Technical data Supply table EXD EXD-SF EXD-S Supply table EXD EXD-SF EXD-S Standard version Traction transmission gear FUCHS Renolin PG 220 Lifting hydraulics Olio idraulico HLF 32 Generic lubricant Tutela MP 02 Chain grease Kluber / Structovis EHD Cold storage version Traction transmission gear FUCHS Renolin PG 220...
  • Page 124 Technical data Supply table EXD EXD-SF EXD-S 50028043344 EN - 01/2018...
  • Page 125 Index Dimensions of roads and working aisles . 50 Disposal Adding a driver's code ....75 Battery ......9 Adding the master code .
  • Page 126 Index Safety Inspection ....19 Safety regulations when handing loads . . 60 Mast types EXD-S ....111 Sample graphics .
  • Page 128 STILL GmbH 50028043344 EN – 01/2018...

This manual is also suitable for:

Exd-s 20

Table of Contents

Save PDF
