Overview
NOTE
The speed of the forks is proportional to how
•
hard the button (4) is pressed, except for the
"BASIC" version
When the forks are fully lowered, a reduc-
•
tion in the fork lowering speed is automa-
tically triggered just before the end of the
stroke (soft landing)
Fork lifting button (5)
• Press the button (5) to lift the forks and
reach the maximum height
• Fork movement can be stopped at any time
by releasing the button (5) The forks will
stop in the position reached
• The fork lifting button (5) is active only when
the tiller is angled to the working position
NOTE
The speed of the forks is proportional to how
hard the button (5) is pressed
Horn button (6)
• Press the button (6) to operate the horn
This device allows the driver to signal his
presence when necessary
Anti-crush button (7)
• Press the button (7) while the truck is trav-
elling towards the operator to automatically
reverse the direction of travel When revers-
ing, the truck travels at creep speed for a
few seconds
The button (7) is a safety device. Particularly
useful in narrow areas, it prevents the operator
from being crushed between a wall and the
tiller head.
The direction of travel of the truck will be
reversed if the button (7) comes into contact
with the body of the operator. When the
operator moves away and releases the button
(7), the truck stops.
