C8051F340/1/2/3/4/5/6/7/8/9/A/B/C/D

USB Register Definition 16.18. E0CNT: USB0 Endpoint 0 Data Count

R R
-
Bit7 Bit6
Bit7: Unused. Read = 0; Write = don't care.
Bits6–0: E0CNT: Endpoint 0 Data Count
This 7-bit number indicates the number of received data bytes in the Endpoint 0 FIFO. This
number is only valid while bit OPRDY is a '1'.

16.11. Configuring Endpoints1-3

Endpoints1-3 are configured and controlled through their own sets of the following control/status registers:
IN registers EINCSRL and EINCSRH, and OUT registers EOUTCSRL and EOUTCSRH. Only one set of
endpoint control/status registers is mapped into the USB register address space at a time, defined by the
contents of the INDEX register (USB Register Definition 16.4).
Endpoints1-3 can be configured as IN, OUT, or both IN/OUT (Split Mode) as described in
The endpoint mode (Split/Normal) is selected via the SPLIT bit in register EINCSRH.
When SPLIT = '1', the corresponding endpoint FIFO is split, and both IN and OUT pipes are available.
When SPLIT = '0', the corresponding endpoint functions as either IN or OUT; the endpoint direction is
selected by the DIRSEL bit in register EINCSRH.

16.12. Controlling Endpoints1-3 IN

Endpoints1-3 IN are managed via USB registers EINCSRL and EINCSRH. All IN endpoints can be used
for Interrupt, Bulk, or Isochronous transfers. Isochronous (ISO) mode is enabled by writing '1' to the ISO bit
in register EINCSRH. Bulk and Interrupt transfers are handled identically by hardware.
An Endpoint1-3 IN interrupt is generated by any of the following conditions:
1. An IN packet is successfully transferred to the host.
2. Software writes '1' to the FLUSH bit (EINCSRL.3) when the target FIFO is not empty.
3. Hardware generates a STALL condition.

16.12.1.Endpoints1-3 IN Interrupt or Bulk Mode

When the ISO bit (EINCSRH.6) = '0' the target endpoint operates in Bulk or Interrupt Mode. Once an end-
point has been configured to operate in Bulk/Interrupt IN mode (typically following an Endpoint0
SET_INTERFACE command), firmware should load an IN packet into the endpoint IN FIFO and set the
INPRDY bit (EINCSRL.0). Upon reception of an IN token, hardware will transmit the data, clear the
INPRDY bit, and generate an interrupt.
180
R R R
E0CNT
Bit5 Bit4 Bit3
Rev. 1.3
R R R
Bit2 Bit1 Bit0
Reset Value
00000000
USB Address:
0x16
Section 16.5.1 .
