13.7.1.2.8-bit MOVX without Bank Select: EMI0CF[4:2] = '101' or '111'.
ADDR[15:8]
ADDR[7:0] P3
DATA[7:0] P4
WR P1.7
RD P1.6
ADDR[15:8]
ADDR[7:0] P3
DATA[7:0] P4
RD P1.6
WR P1.7

Figure 13.6. Non-multiplexed 8-bit MOVX without Bank Select Timing

C8051F340/1/2/3/4/5/6/7/8/9/A/B/C/D
Nonmuxed 8-bit WRITE without Bank Select
EMIF ADDRESS (8 LSBs) from R0 or R1
EMIF WRITE DATA
T
WDS
T
ACS
Nonmuxed 8-bit READ without Bank Select
EMIF ADDRESS (8 LSBs) from R0 or R1
T
ACS
Rev. 1.3
P2
T
WDH
T T
ACW ACH
P2
EMIF READ DATA
T T
RDS RDH
T T
ACW ACH
P3
P4
P1.7
P1.6
P3
P4
P1.6
P1.7
