USB Register Definition 16.14. IN1IE: USB0 IN Endpoint Interrupt Enable

R/W R/W
- -
Bit7 Bit6
Bits7–4: Unused. Read = 0000b. Write = don't care.
Bit3: IN3E: IN Endpoint 3 Interrupt Enable
0: IN Endpoint 3 interrupt disabled.
1: IN Endpoint 3 interrupt enabled.
Bit2: IN2E: IN Endpoint 2 Interrupt Enable
0: IN Endpoint 2 interrupt disabled.
1: IN Endpoint 2 interrupt enabled.
Bit1: IN1E: IN Endpoint 1 Interrupt Enable
0: IN Endpoint 1 interrupt disabled.
1: IN Endpoint 1 interrupt enabled.
Bit0: EP0E: Endpoint 0 Interrupt Enable
0: Endpoint 0 interrupt disabled.
1: Endpoint 0 interrupt enabled.

USB Register Definition 16.15. OUT1IE: USB0 Out Endpoint Interrupt Enable

R/W R/W
- -
Bit7 Bit6
Bits7–4: Unused. Read = 0000b. Write = don't care.
Bit3: OUT3E: OUT Endpoint 3 Interrupt Enable
0: OUT Endpoint 3 interrupt disabled.
1: OUT Endpoint 3 interrupt enabled.
Bit2: OUT2E: OUT Endpoint 2 Interrupt Enable
0: OUT Endpoint 2 interrupt disabled.
1: OUT Endpoint 2 interrupt enabled.
Bit1: OUT1E: OUT Endpoint 1 Interrupt Enable
0: OUT Endpoint 1 interrupt disabled.
1: OUT Endpoint 1 interrupt enabled.
Bit0: Unused. Read = 0; Write = don't' care.
C8051F340/1/2/3/4/5/6/7/8/9/A/B/C/D
R/W R/W R/W
- - IN3E
Bit5 Bit4 Bit3
R/W R/W R/W
- - OUT3E
Bit5 Bit4 Bit3
Rev. 1.3
R/W R/W R/W
IN2E IN1E EP0E
Bit2 Bit1 Bit0
R/W R/W R/W
OUT2E OUT1E
Bit2 Bit1 Bit0
Reset Value
00001111
USB Address:
0x07
Reset Value
- 00001110
USB Address:
0x09
175
