SFR Definition 12.3. FLSCL: Flash Scale

R/W R/W
FOSE Reserved Reserved
Bit7 Bit6
Bits7: FOSE: Flash One-shot Enable
This bit enables the Flash read one-shot. When the Flash one-shot disabled, the Flash
sense amps are enabled for a full clock cycle during Flash reads. At system clock frequen-
cies below 10 MHz, disabling the Flash one-shot will increase system power consumption.
0: Flash one-shot disabled.
1: Flash one-shot enabled.
Bits6–5: RESERVED. Read = 00b. Must Write 00b.
Bit 4: FLRT: FLASH Read Time.
This bit should be programmed to the smallest allowed value, according to the system clock
speed.
0: SYSCLK <= 25 MHz.
1: SYSCLK <= 48 MHz.
Bits3–0: RESERVED. Read = 0000b. Must Write 0000b.
C8051F340/1/2/3/4/5/6/7/8/9/A/B/C/D
R/W R/W R/W
FLRT Reserved Reserved Reserved Reserved 10000000
Bit5 Bit4 Bit3
Rev. 1.3
R/W R/W R/W
Bit2 Bit1 Bit0
Reset Value
SFR Address:
0xB6
