SFR Definition 16.2. USB0ADR: USB0 Indirect Address

R/W R/W
BUSY AUTORD
Bit7 Bit6
Bits7: BUSY: USB0 Register Read Busy Flag
This bit is used during indirect USB0 register accesses. Software should write '1' to this bit to
initiate a read of the USB0 register targeted by the USBADDR bits (USB0ADR.[5-0]). The
target address and BUSY bit may be written in the same write to USB0ADR. After BUSY is
set to '1', hardware will clear BUSY when the targeted register data is ready in the
USB0DAT register. Software should check BUSY for '0' before writing to USB0DAT.
Write:
0: No effect.
1: A USB0 indirect register read is initiated at the address specified by the USBADDR bits.
Read:
0: USB0DAT register data is valid.
1: USB0 is busy accessing an indirect register; USB0DAT register data is invalid.
Bit6: AUTORD: USB0 Register Auto-read Flag
This bit is used for block FIFO reads.
0: BUSY must be written manually for each USB0 indirect register read.
1: The next indirect register read will automatically be initiated when software reads
USB0DAT (USBADDR bits will not be changed).
Bits5–0: USBADDR: USB0 Indirect Register Address
These bits hold a 6-bit address used to indirectly access the USB0 core registers. Table 16.2
lists the USB0 core registers and their indirect addresses. Reads and writes to USB0DAT
will target the register indicated by the USBADDR bits.
C8051F340/1/2/3/4/5/6/7/8/9/A/B/C/D
R/W R/W R/W
USBADDR
Bit5 Bit4 Bit3
Rev. 1.3
R/W R/W R/W
Bit2 Bit1 Bit0
Reset Value
00000000
SFR Address:
0x96
163
