C8051F340/1/2/3/4/5/6/7/8/9/A/B/C/D

15.3. General Purpose Port I/O

Port pins that remain unassigned by the Crossbar and are not used by analog peripherals can be used for
general purpose I/O. Ports 3-0 are accessed through corresponding special function registers (SFRs) that
are both byte addressable and bit addressable. Port 4 (48-pin packages only) uses an SFR which is
byte-addressable. When writing to a Port, the value written to the SFR is latched to maintain the output
data value at each pin. When reading, the logic levels of the Port's input pins are returned regardless of the
XBRn settings (i.e., even when the pin is assigned to another signal by the Crossbar, the Port register can
always read its corresponding Port I/O pin). The exception to this is the execution of the read-modify-write
instructions. The read-modify-write instructions when operating on a Port SFR are the following: ANL,
ORL, XRL, JBC, CPL, INC, DEC, DJNZ and MOV, CLR or SETB, when the destination is an individual bit
in a Port SFR. For these instructions, the value of the register (not the pin) is read, modified, and written
back to the SFR.
R/W R/W
P0.7 P0.6
Bit7 Bit6
Bits7–0: P0.[7:0]
Write - Output appears on I/O pins per Crossbar Registers (when XBARE = '1').
0: Logic Low Output.
1: Logic High Output (high impedance if corresponding P0MDOUT.n bit = 0).
Read - Always reads '0' if selected as analog input in register P0MDIN. Directly reads Port
pin when configured as digital input.
0: P0.n pin is logic low.
1: P0.n pin is logic high.

SFR Definition 15.5. P0MDIN: Port0 Input Mode

R/W R/W
Bit7 Bit6
Bits7–0: Analog Input Configuration Bits for P0.7–P0.0 (respectively).
Port pins configured as analog inputs have their weak pull-up, digital driver, and digital
receiver disabled.
0: Corresponding P0.n pin is configured as an analog input.
1: Corresponding P0.n pin is not configured as an analog input.
150

SFR Definition 15.4. P0: Port0 Latch

R/W R/W R/W
P0.5 P0.4 P0.3
Bit5 Bit4 Bit3
R/W R/W R/W
Bit5 Bit4 Bit3
Rev. 1.3
R/W R/W R/W
P0.2 P0.1 P0.0
Bit2 Bit1 Bit0
(bit addressable)
R/W R/W R/W
Bit2 Bit1 Bit0
Reset Value
11111111
SFR Address:
0x80
Reset Value
11111111
SFR Address:
0xF1
