3.7. Connection Examples
3.7.1. Start/Stop
Terminal 18 = Par. 5-10 [8]
Terminal 27 = Par. 5-12 [0]
3
fault
Terminal 37 = Safe stop (where available!)
3.7.2. Pulse Start/Stop
Terminal 18 = Par. 5-10 [9]
Terminal 27= Par. 5-12 [6]
Terminal 37 = Safe stop (where available!)
62
Start
No operation
coast inverse
)
Latched start
Stop inverse
