Danfoss VLT AQUA Drive FC 200 Instruction Manual page 82

4. How to program the adjustable frequency
drive
[1834] Analog Out X42/9 [V] Shows the value of the signal applied to terminal X42/9 on the
[1835] Analog Out X42/11
[2117] Ext.
[2118] Ext. 1 Feedback [Unit] The value of the feedback signal for extended closed-loop con-
4
[2119] Ext. 1 Output [%]
[2137] Ext.
[2138] Ext. 2 Feedback [Unit] The value of the feedback signal for extended closed-loop con-
[2139] Ext. 2 Output [%]
[2157] Ext.
[2158] Ext. 3 Feedback [Unit] The value of the feedback signal for extended closed-loop con-
[2159] Ext. Output [%]
[2230] No-Flow Power
[2580] Cascade Status
[2581] Pump Status
0-21 Display Line 1.2 Small
Option:
[1662]
0-22 Display Line 1.3 Small
Option:
82
analog I/O card.
Shows the value of the signal applied to terminal X42/11 on the
[V] analog I/O card.
1 Reference The value of the reference for extended closed-loop controller
[Unit] 1.
troller 1.
The value of the output from extended closed-loop controller 1.
2 Reference The value of the reference for extended closed-loop controller
[Unit] 2.
troller 2.
The value of the output from extended closed-loop controller 2.
3 Reference The value of the reference for extended closed-loop controller
[Unit] 3.
troller 3.
The value of the output from extended closed-loop controller 3.
The calculated no-flow power for the actual operating speed.
Status for the operation of the cascade controller.
Status for the operation of each individual pump controlled by
the cascade controller.
NOTE
®
Please consult the VLT
detailed information.
Function:
Select a variable for display in line 1, middle position.
*
Analog input 53 The options are the same as those listed for par. 0-20
Line 1.1 Small
Function:
Select a variable for display in line 1, right position.
MG.20.P1.22 - VLT
VLT AQUA High Power Instruction Manual
AQUA Drive Programming Guide, MG.20.OX.YY
.
®
is a registered Danfoss trademark.
