VLT AQUA High Power Instruction Manual
Array [8]
Select options to define the function of the relays.
The selection of each mechanical relay is realized in an array parameter.
[0]
[1]
[2]
[3]
[4]
*
[5]
[6]
[8]
[9]
[10]
[11]
[12]
[13]
[14]
[15]
[16]
[17]
[18]
[19]
[20]
[21]
[25]
[26]
[27]
[28]
[29]
[30]
[35]
[36]
[37]
[40]
[41]
[42]
[45]
[46]
[47]
(Relay 1 [0], Relay 2 [1], Relay 7 [6], Relay 8 [7], Relay 9
No Operation
Control Ready
Drive Ready
Drive Ready/Remote
Stand-by/No Warning
Running
Running/No Warning
Run on Ref./No Warn-
ing
Alarm
Alarm or Warning
At Torque Limit
Out of Current Range
Below Current, low
Above Current, high
Out of Speed Range
Below Speed, low
Above Speed, high
Out of Feedb. Range
Below Feedback, low
Above Feedback, high
Thermal Warning
Reverse
Bus OK
Torque Limit & Stop
Brake, No Warning
Brake Ready, No Fault
Brake Fault (IGBT)
External Interlock
Control Word Bit 11
Control Word Bit 12
Out of Ref. Range
Below Reference, low
Above Ref. high
Bus ctrl
Bus ctrl, 1 if timeout
Bus ctrl, 0 if timeout
®
MG.20.P1.22 - VLT is a registered Danfoss trademark.
4. How to program the adjustable frequency
drive
[8])
4
