VLT AQUA High Power Instruction Manual
Line power supply (L1, L2, L3):
Supply voltage
Supply voltage
Supply frequency
Max. imbalance temporary between line phases
True Power Factor (λ)
Displacement Power Factor (cosφ) near unity
Switching on input supply L1, L2, L3 (power-ups) ≤ enclosure type A
Switching on input supply L1, L2, L3 (power-ups) ≥ enclosure type B, C
Switching on input supply L1, L2, L3 (power-ups) ≥ enclosure type D, E maximum once/2 min.
Environment according to EN60664-1
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS sym-
metrical Amperes, 480/690 V maximum.
Motor output (U, V, W):
Output voltage
Output frequency
Switching on output
Ramp times
Torque characteristics:
Starting torque (Constant torque)
Starting torque
Overload torque (Constant torque)
*Percentage relates to VLT AQUA Drive's nominal torque.
Cable lengths and cross-sections:
Max. motor cable length, shielded/armored
Max. motor cable length, unshielded/unarmored
Max. cross-section to motor, line power, load sharing and brake *
Maximum cross-section to control terminals,
rigid wire
Maximum cross-section to control terminals, flexible cable
Maximum cross-section to control terminals, cable with en-
closed core
Minimum cross-section to control terminals
* See Line Supply tables for more information!
®
MG.20.P1.22 - VLT is a registered Danfoss trademark.
5. General Specifications
3.0% of rated supply voltage
≥ 0.9 nominal at rated load
maximum twice/min.
maximum once/min.
overvoltage category III / pollution degree 2
0 - 100% of supply voltage
maximum 110% for 1 min.
maximum 135% up to 0.5 sec.
maximum 110% for 1 min.
VLT AQUA Drive: 492 ft [150 m]
VLT AQUA Drive: 984 ft [300 m]
2 2
0.0023 in. [1.5 mm ]/16 AWG (2 x 0.0012 in.
0.0016 in. 2
2
0.00078 in. [0.5 mm
0.00039 in.
380-480 V ±10%
525-690 V ±10%
50/60 Hz
(> 0.98)
0 - 1000 Hz
Unlimited
1 - 3600 sec.
*
*
*
2
2
[2 x 0.75 mm ])
[1 mm 2 ]/18 AWG
2
]/20 AWG
2 2
[0.25 mm ]
