VLT AQUA High Power Instruction Manual
[1672] Counter A
[1673] Counter B
[1675] Analog input X30/11
[1676] Analog input X30/12
[1677] Analog output X30/8
[1680] Ser. Com. Bus CTW 1 Control word (CTW) received from the bus master.
[1682] Ser. com. bus REF 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
[1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V] Shows the value of the signal applied to terminal X42/7 on the
View the present value of Counter A.
View the present value of Counter B.
Actual value of the signal on input X30/11 (General Purpose I/
O Card. Option)
Actual value of the signal on input X30/12 (General Purpose I/
O Card. Optional)
Actual value at output X30/8 (General Purpose I/O Card. Op-
[mA] tional) Use Par. 6-60 to select the variable to be shown.
Main reference value sent with control word via the serial com-
munications network, such as from the BMS, PLC or another
master controller, for example.
Extended serial communication bus option status word.
Control word (CTW) received from the bus master.
Status word (STW) sent to the bus master.
One or more alarms in a Hex code (used for serial communica-
tions).
One or more alarms in a Hex code (used for serial communica-
tions).
One or more warnings in a Hex code (used for serial communi-
cations).
One or more warnings in a Hex code (used for serial communi-
cations).
One or more status conditions in a Hex code (used for serial
communications).
One or more status conditions in a Hex code (used for serial
communications).
The bits reflect the status for the programmed preventive main-
tenance events in parameter group 23-1*.
Shows the value of the signal applied to terminal X42/1 on the
analog I/O card.
Shows the value of the signal applied to terminal X42/3 on the
analog I/O card.
Shows the value of the signal applied to terminal X42/5 on the
analog I/O card.
analog I/O card.
®
