Danfoss VLT AQUA Drive FC 200 Instruction Manual page 75

VLT AQUA High Power Instruction Manual
4-11 Motor Speed Low Limit [RPM]
Range:
Size re-
lated
4-13 Motor Speed High Limit [RPM]
Range:
Size re-
lated
1-29 Automatic Motor Adaptation (AMA)
Option:
*
[0]
[1]
[2]
down time so that no overvoltage arises in the inverter due to
regenerative operation of the motor, and so that the generated
current does not exceed the current limit set in par. 4-18. See
ramp-up time in par. 3-41.
par
Function:
[0 - 60,000 rpm] Enter the minimum limit for motor speed. The Motor Speed Low
* Limit can be set to correspond to the manufacturer's recom-
mended minimum motor speed. The Motor Speed Low Limit
must not exceed the setting in par. 4-13
[RPM]
Function:
[0 - 60,000 rpm] Enter the maximum limit for motor speed. The Motor Speed
*
High Limit can be set to correspond to the manufacturer's max-
imum rated motor speed. The Motor Speed High Limit must
exceed the setting in par. 4-11
Only par. 4-11 or 4-12 will be displayed depending on other pa-
rameters set in the Main Menu, and depending on default set-
tings specific to global geographical locations.
NOTE
The output frequency value of the adjustable frequency drive must not exceed a
value higher than 1/10 of the switching frequency.
Function:
The AMA function optimizes dynamic motor performance by au-
tomatically optimizing the advanced motor parameters (par.
1-30 to par. 1-35) while the motor is stationary.
OFF No function
Enable complete AMA performs AMA of the stator resistance R
R
X
Enable reduced AMA performs a reduced AMA of the stator resistance R
tem only. Select this option if an LC filter is used between the
adjustable frequency drive and the motor.
®
MG.20.P1.22 - VLT is a registered Danfoss trademark.
4. How to program the adjustable frequency
t n
×
dec norm
.3 − 42 =
ref rpm
Δ
.
, the stator leakage reactance X
r
and the main reactance X .
2 h
par
.1 − 25
s
Motor Speed High Limit
Motor Speed Low Limit [RPM]
, the rotor resistance
S
, the rotor leakage reactance
1
in the sys-
s
drive
4
.
75
