4 How to Install
4.7 Connection Examples for Control of Motor with External Signal Pro-
vider
NB!
The following examples refer only to the drive control card (right LCP),
4

4.7.1 Start/Stop

Terminal 18 Digital Input [8] Start
Terminal 18 = par. 5-10
Terminal 27 Digital Input [0] No operation (De-
Terminal 27 = par. 5-12
coast inverse )
fault
Terminal 37 = Safe stop

4.7.2 Pulse Start/Stop

Terminal 18 Digital Input [9] Latched start
Terminal 18 = par. 5-10
Terminal 27 Digital Input [6] Stop inverse
Terminal 27= par. 5-12
Terminal 37 = Safe stop
60
VLT AQUA Low Harmonic Drive Operating In-
not the filter.
®
