6-21 Terminal 54 High Voltage
Range:
10.0 V
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0.000
*
Unit
6-25 Terminal 54 high ref./feedb. value
Range:
100.000
*
Unit
6-50 Terminal 42 Output
Option:
[0]
[100]
[101]
[102]
[103]
[104]
[105]
[106]
[107]
[108]
[113]
[114]
[115]
[130]
[131]
[132]
[133]
[134]
[135]
[136]
[137]
Function:
* [Par. 6-20 to 10.0 V] Enter the high voltage value. This analog input scaling value
should correspond to the high reference/feedback value set in
par. 6-25.
Function:
[-1,000,000.000 to Enter the analog input scaling value that corresponds to the low
par. 6-25] voltage/low current value set in par. 6-20/6-22.
Function:
[Par. 6-24 to Enter the analog input scaling value that corresponds to the high
1,000,000.000] voltage/high current value set in par. 6-21/6-23.
Function:
No operation
* Output frequency
Reference
Feedback
Motor current
Torque rel to lim
Torque rel to rated
Power
Speed
Torque
Ext. closed-loop 1
Ext. closed-loop 2
Ext. closed-loop 3
Output freq. 4-20 mA
Reference 4-20 mA
Feedback 4-20 mA
Motor cur. 4-20 mA
Torque % lim. 4-20
mA
Torque % nom 4-20
mA
Power 4-20 mA
Speed 4-20 mA
®
