Danfoss VLT AQUA Drive FC 200 Instruction Manual page 78

4. How to program the adjustable frequency
drive
Q3-20 Digital Reference
3-02 Minimum Reference
3-03 Maximum Reference
3-10 Preset Reference
5-13 Terminal 29 Digital Input
5-14 Terminal 32 Digital Input
5-15 Terminal 33 Digital Input
4
Q3-30 Feedback Settings
1-00 Configuration Mode
20-12 Reference/Feedb.Unit
3-02 Minimum Reference
3-03 Maximum Reference
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-24 Terminal 54 Low Ref/Feedb Value
6-25 Terminal 54 High Ref/Feedb Value
6-00 Live Zero Timeout Time
6-01 Live Zero Timeout Function
0-20 Display Line 1.1 Small
Option:
[0]
[37]
[38]
[39]
[89]
[953]
[1005] Readout Transmit Er-
[1006] Readout Receive Er-
[1007] Readout
[1013] Warning Parameter
[1115] LON Warning Word
78
Q3-2 Open-loop Settings
Q3-3 Closed-loop Settings
Function:
Select a variable for display in line 1, left position.
None No display value selected
Display Text 1 Present control word
Display Text 2 Enables an individual text string to be written, for display in the
LCP or to be read via serial communication.
Display Text 3 Enables an individual text string to be written, for display in the
LCP or to be read via serial communication.
Date and Time Read- Displays the current date and time.
out
Profibus Warning Displays Profibus communication warnings.
Word
View the number of CAN control transmission errors since the
ror Counter last power-up.
View the number of CAN control receipt errors since the last
ror Counter power-up.
Bus Off View the number of Bus Off events since the last power-up.
Counter
View a DeviceNet-specific warning word. One separate bit is as-
signed to every warning.
Shows the LON-specific warnings.
MG.20.P1.22 - VLT
VLT AQUA High Power Instruction Manual
Q3-21 Analog Reference
3-02 Minimum Reference
3-03 Maximum Reference
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-14 Terminal 53 Low Ref/Feedb. Value
6-15 Terminal 53 High Ref/Feedb. Value
Q3-31 PID Settings
20-81 PID Normal/Inverse Control
20-82 PID Start Speed [RPM]
20-21 Setpoint 1
20-93 PID Proportional Gain
20-94 PID Integral Time
®
is a registered Danfoss trademark.
