ADSP-21367/ADSP-21368/ADSP-21369
Table 46. 256-Ball BGA_ED Pin Assignment (Numerically by Ball Number) (Continued)
Ball No. Signal
J17 GND
J18 GND
2
J19 GND/ID1
J20 DATA17
N01 RD
N02 SDCLK0
N03 GND
N04 V
DDEXT
N17 GND
N18 GND
N19 DATA11
N20 DATA10
U01 MS0
U02 MS1
U03 V
DDINT
U04 GND
U05 V
DDEXT
U06 GND
U07 V
DDEXT
U08 V
DDINT
U09 V
DDEXT
U10 GND
U11 V
DDEXT
U12 V
DDINT
U13 V
DDEXT
U14 V
DDEXT
U15 V
DDINT
U16 V
DDEXT
U17 V
DDINT
U18 V
DDINT
U19 DATA0
U20 DATA2
1
The SDCLK1 signal is only available on the SBGA package. SDCLK1 is not available on the LQFP_EP package.
2
Applies to ADSP-21368 models only.
Ball No. Signal
K17 V
DDINT
K18 V
DDINT
2
K19 GND/ID0
K20 DATA16
P01 SDA10
P02 WR
P03 V
DDINT
P04 V
DDINT
P17 V
DDINT
P18 V
DDINT
P19 DATA8
P20 DATA9
V01 ADDR22
V02 ADDR23
V03 V
DDINT
V04 GND
V05 GND
V06 GND
V07 GND
V08 V
DDINT
V09 GND
V10 GND
V11 GND
V12 V
DDINT
V13 V
DDEXT
V14 GND
V15 V
DDINT
V16 GND
V17 GND
V18 GND
V19 DATA1
V20 DATA3
Rev. D | Page 50 of 56 | November 2008
Ball No. Signal
L17 V
DDINT
L18 V
DDINT
L19 DATA15
L20 DATA14
R01 SDWE
R02 SDRAS
R03 GND
R04 GND
R17 V
DDEXT
R18 GND
R19 DATA6
R20 DATA7
W01 GND
W02 ADDR21
W03 ADDR19
W04 ADDR20
W05 ADDR17
W06 ADDR16
W07 ADDR15
W08 ADDR14
W09 A
VDD
W10 A
VSS
W11 ADDR13
W12 ADDR12
W13 ADDR10
W14 ADDR8
W15 ADDR5
W16 ADDR4
W17 ADDR1
W18 ADDR2
W19 ADDR0
W20 NC
Ball No. Signal
M17 V
DDEXT
M18 GND
M19 DATA12
M20 DATA13
T01 SDCKE
T02 SDCAS
T03 GND
T04 V
DDEXT
T17 GND
T18 GND
T19 DATA5
T20 DATA4
Y01 GND
Y02 NC
Y03 NC
Y04 ADDR18
2
Y05 NC/BR1
2
Y06 NC/BR2
Y07 XTAL
Y08 CLKIN
Y09 NC
Y10 NC
2
Y11 NC/BR3
2
Y12 NC/BR4
Y13 ADDR11
Y14 ADDR9
Y15 ADDR7
Y16 ADDR6
Y17 ADDR3
Y18 GND
Y19 GND
Y20 NC
