I I I I I MOTOR STOP
By using the MOTOR STOP command, a drive in
positioning, speed or synchronizing mode can be
decelerated with programmed acceleration and
arrested at the momentary position.
A drive arrested with this command can, at a later
point, via the CONTINUE command, resume its
original motion. (Exception: CONTINUE does not
continue an interrupted synchronization command.)
NB!
If MOTOR STOP is executed in a subpro-
gram or if NOWAIT is set to ON, then the
next lines in the program are already processed
while MOTOR STOP is being processed; the bra-
king process runs in the background.
Therefore, in order to slow the drive down to a
speed of zero it is necessary to ascertain that no
new positioning command is given during braking.
Summary
stops the drive
Syntax
MOTOR STOP
Command group
CON
Cross Index
POSA, POSR, CSTART, CONTINUE, CSTOP
Syntax-Example
MOTOR STOP /* interrupt motion of the axis */
Program sample
MSTOP_01.M
MG.10.J4.02 – VLT is a registered Danfoss trade mark
®
VLT 5000 SyncPos option
I I I I I MOVESYNCORIGIN
The command shifts the origin of synchronization
in relation to the master. While SET
SYNCPOSOFFS sets the offset position absolutely,
MOVESYNCORIGIN always relates to the last one
and shifts the offset position relatively. If you have
to shift the offset position continually, you can pre-
vent too large numbers or an overflow in this way.
Summary
Relative shifting of the origin of synchronization
Syntax
MOVESYNCORIGIN mvalue
Parameter
mvalue = Relative offset in relation to the Master
in qc
NB!
Valid for position synchronization SYNCP
and position synchronization with marker
correction SYNCM.
Command group
SYN
Cross Index
SET, SYNCPOSOFFS (54)
Syntax example
MOVESYNCORIGIN 1000
