4.6.1.15 Indicators <indicators/>
Indicators (graphic icons, animations, and LED patterns) used by SoundPoint
defined in this section.
Attribute
ind.idleDisplay.enabled
a. This will be implemented in a future release.
4.6.1.15.1 Animations <Animations/><IP_500/> and <IP_600/>
This section defines bitmap animations composed of bitmap/duration couples. In the
following table, x=IP_500 or IP_600, y is the animation number, z is the step in the
animation.
Attribute
ind.anim.x.y.frame.z.bitmap
ind.anim.x.y.frame.z.duration
4.6.1.15.2 Patterns <Patterns/>
This section defines patterns for the LED indicators. In the following table, x is the
pattern number, y is the step in the pattern.
Attribute
ind.pattern.x.step.y.state
ind.pattern.x.step.y.duration
ind.pattern.x.step.y.colour
92
®
IP SIP
Permitted
Values
0, 1
Permitted Values
A bitmap name
defined previously.
positive integer
Permitted
Values
On or Off
positive integer
Red or Green
(default is Red
if not specified)
Copyright © 2004 Polycom, Inc.
Default Interpretation
0 If set to 1, the idle display may support cus-
tom icon presentation if configured prop-
erly in the animation section of ipmid.cfg.
Interpretation
Bitmap to use.
Duration in milliseconds for this step.
0=infinite.
Interpretation
Turn LED on or off for this step.
Duration in milliseconds for this step. 0=infinite
For bi-color LEDs, specify color.
Optimizing SoundPoint
® IP are
