4.6.1.15.3 Classes <Classes/>
This section defines the available classes for the LED and graphical icon indicator
types. In the following table, x is the class number, y is the identifier of the state num-
ber for that class.
Attribute
ind.class.x.state.y.index
4.6.1.15.4 Assignments <Assignments/>
This section assigns a type, a class, and, in the case of the GraphicIcon type, a physical
location and size in pixels on the LCD display or in the case of the LED type, a physi-
cal LED number.
4.6.1.15.4.1 LEDs <led/>
In the following table, x is the LED number.
Attribute
ind.led.x.index
ind.led.x.class
ind.led.x.physNum
4.6.1.15.4.2 Graphic Icons <gi/> <IP_500/> and <IP_600/>
In the following table, x=IP_500 or IP_600, y is the graphic icon number.
Attribute
ind.gi.x.y.index
ind.gi.x.y.class
®
IP SIP
Permitted
Values
positive integer
Permitted
Values Interpretation
This is for internal usage only and should not be changed
(this is the logical index).
positive integer Assigns the class (defined above) for this indicator.
This maps logical index to a specific physical LED.
Permitted
Values Interpretation
This is for internal usage only and should not be changed
(this is the logical index).
positive integer Assigns the class (defined above) for this indicator.
Copyright © 2004 Polycom, Inc
Interpretation
For LED type indicators, index refers to pattern
index, i.e. index x in the <Patterns/> tag above. For
GraphicIcon type indicators, index refers to anima-
tion index, i.e. index y in the <Animations/> tag
above.
