2.2.1.2 Local User Interface Setup Menus

Access to Network Configuration Menu:
Phase 1: bootROM
Phase 2: application
SoundPoint
menu and two sub-menus: DHCP Menu and Server Menu.
Use the soft keys, the arrow keys, the Sel/ , and the Del/X keys to make changes.
Parameters that are dimmed are read-only due to the value of other parameters. For
example, if the DHCP Client parameter is enabled, the Phone IP Addr and Subnet
Mask parameters are dimmed since these are guaranteed to be supplied by the DHCP
server (mandatory DHCP parameters) and the statically assigned IP address and sub-
net mask will never be used in this configuration.
2.2.1.2.1 Main Menu
Configuration parameters that may be edited on the main setup menu are described in
the table below:
Name
DHCP Client
Phone IP Address
Subnet Mask
IP Gateway
6
®
IP
The network configuration menu is accessible during the auto-boot
countdown of the bootROM phase of operation. Press the
key to launch the main menu.
The network configuration menu is accessible from the main menu.
Navigate to Menu>Settings>Network Configuration. This menu is
locked by default. Enter the administrator password to unlock.
(Factory default password: 456)
®
IP network configuration parameters may be edited by means of a main
Possible Values
Enabled, Disabled
dotted-decimal IP
address
dotted-decimal subnet
mask
dotted-decimal IP
address
Copyright © 2004 Polycom, Inc.
a
Description
If enabled, DHCP will be used to obtain the
parameters discussed in 2.2.1.1 DHCP or Man-
ual TCP/IP Setup on page 5.
Telephone's IP address.
Note: Disabled when DHCP client is enabled.
Telephone's subnet mask.
Note: Disabled when DHCP client is enabled.
Telephone's default router.
Installation and Operation
Setup soft
