Server Redundancy - Polycom SoundPoint IP 600 SIP Administrator's Manual

Administrator Guide - SoundPoint
use for outgoing calls or which registration to use when initiating new instant message
dialogs.
Central
(boot
server)
Local

3.6.3 Server Redundancy

SoundPoint
more backup. SoundPoint
server fails. Backup server configuration can be static or use advanced DNS methods.
®
IP
Configuration file:
sip.cfg
Configuration file:
phone1.cfg
Web Server
(if enabled)
Local Phone User
Interface
® IP can be configured with multiple SIP servers, one primary and one or
®
IP will switch to a backup server when the current primary
Copyright © 2004 Polycom, Inc.
Specify the local SIP signaling port and an array of SIP serv-
ers to register to. For each server specify the registration
period and the signaling failure behavior.
• For more information, see 4.6.2.1.1 Local <local/> on
page 101 and 4.6.2.1.2 Server <server/> on page 102.
For up to six registrations, specify a display name, a SIP
address, an optional display label, an authentication user ID
and password, and an optional array of registration servers.
The authentication user ID and password are optional and
for security reasons can be omitted from the configuration
files. The local flash parameters will be used instead. The
optional array of servers and their associated parameters will
override the servers specified in sip.cfg if non-Null.
• For more information, see 4.6.3.1 Registration <reg/>
on page 108.
Specify the local SIP signaling port and an array of SIP serv-
ers to register to.
Navigate to: http://<phoneIPAddress>/appConf.htm
For up to six registrations, specify a display name, a SIP
address, an optional display label, an authentication user ID
and password, and an optional array of registration servers.
The authentication user ID and password are optional and
for security reasons can be omitted from the configuration
files. The local flash parameters will be used instead. The
optional array of servers will override the servers specified
in sip.cfg in non-Null. This will also override the servers on
the appConf.htm web page.
Navigate to: http://<phoneIPAddress>/reg.htm
Changes are saved to local flash and backed up to <Ethernet
address>-phone.cfg on the boot server. Changes will perma-
nently override global settings unless deleted via the Reset
User Settings menu selection.
None
Features
45
