1 Overview

SoundPoint
Ethernet TCPIP networks. It is designed to facilitate high-quality audio and text mes-
sage communications. This telephone is an endpoint in the overall network topology
designed to interoperate with other compatible equipment including application serv-
ers, media servers, internetworking gateways, voice bridges, and other endpoints.
