Using Web Manager
To configure a specific line, click Line in the menu and select Line 1 -> Configuration

9-1).
To configure a specific line in Command Mode, click Line in the menu and select Line 1 ->

Command Mode
Using the CLI
To enter Line 1 command level: enable -> line 1

Using XML
Include in your file: <configgroup name="line" instance="1">

Include in your file: <configgroup name="serial command mode" instance="1">


To View Line Statistics

Using Web Manager
To view statistics for a specific line, click Line in the menu and select Line 1 -> Statistics.

Using the CLI
To view Line statistics: enable -> line 1, show statistics

Using XML
Include in your file: <statusgroup name="line" instance="1">


Tunnel Settings

Tunneling allows serial devices to communicate over a network, without "being aware" of the
devices which establish the network connection between them. Tunneling parameters are
configured using the Tunnel menu and submenus. The Tunnel settings allow you to configure
how the Serial-Network tunneling operates. Tunneling is available on all serial lines. The
connections on one serial line are separate from those on another serial port.
Notes: The following section describes the steps to view and configure Tunnel 1 settings;
these steps apply to other tunnel instances of the device.

Serial Settings

These serial settings for the tunnel apply to the Serial Line interface. The Line Settings and
Protocol are displayed for informational purposes and must be configured from the Line settings.
PremierWave XC HSPA+ User Guide
PRELIMINARY DRAFT
(Table 9-2).
PRELIMINARY DRAFT
9: Line and Tunnel Settings
(Table
47
