To Configure SSH Settings

Using Web Manager
To configure SSH settings, click CLI in the menu and select Configuration.

Using the CLI
To enter the SSH command level: enable -> config -> cli -> ssh

Using XML
Include in your file:

<configgroup name="ssh">
and
<configitem name="state">

XML Settings

The PremierWave allows for the configuration of units using an XML configuration record (XCR).
Export a current configuration for use on other PremierWave or import a saved configuration file.

XML: Export Configuration

You can export the current system configuration in XML format. The generated XML file can be
imported later to restore a configuration. It can also be modified and imported to update the
configuration on this PremierWave unit or another. The XML data can be dumped to the screen or
exported to a file on the file system.
By default, all groups are exported. You may also select a subset of groups to export.
XML Export Configuration
Settings
Export to browser
Export to local file
Export secrets
Comments
Lines to Export
PremierWave XC HSPA+ User Guide
PRELIMINARY DRAFT

Table 14-5 XML Exporting Configuration

Description
Select this option to export the XCR data in the selected fields to the
browser. Use the "xcr dump" command to export the data to the browser.
Select this option to export the XCR data to a file on the device. If you select
this option, enter a file name for the XML configuration record. Use the "xcr
export" command to export the data to a local file.
Select to export secret password and key information. Use only with a
secure link, and save only in secure locations.
Note: Only use with extreme caution.
Select this option to include descriptive comments in the XML.
Select instances to be exported in the line, serial, tunnel and terminal
groups.
PRELIMINARY DRAFT
14: Advanced Settings
87
