selector keys - like preset buttons on a
External
car radio.
»
Press and hold both
open the
Monitor 1 Source
lows you to select from a list of Program and Aux
Send buses.
Programming the External Monitor Selec-
tor keys: If you press and hold either of these
keys for five seconds, a list of available audio
streams will pop up onscreen. You can then
scroll through this list and select the source you
want to hear in the monitors when that key is
pressed. Each External key is independently
programmable.
You can also pre-program the source assigned
to these keys when you construct or capture
Show Profiles, using the options available on the
Monitor page of the Show Profile setup menu.
•
Headphone Knob
This knob, at the bottom right of the Monitor section,
controls the volume of the source heard in the board
operator's headphones.
»
Rotate to vary the gain of the
»
By default, the
Headphone
and follows the
Monitor 1
unlink the two and choose an independent head-
phone source, please see the description on Page
66 of this manual.
•
Preview To HP Key
This key toggles the
Preview To Headphone
tion. When active, this function sends
to the board operator's headphones. When inactive, au-
dio from the
bus is heard exclusively in the
Preview
speakers. The
Preview
Preview To HP
when this function is active.
There are three different Preview to HP modes; the
current mode is indicated by an annunciator on the Ele-
ment display screen just below the headphone selection
tally.
When Preview to HP is off, the selector key
Off:
»
is unlit. No preview audio will be heard in the
board-op's HP path.
Pressing the
»
On:
Preview to HP
selector keys to
External
menu, which al-
feed.
Headphone
feed is linked to
source selection. To
func-
audio
Preview
key illuminates
key once from
©2008 Axia Audio — Rev. 3.0
the Off state sends preview audio, when present,
into both sides of the operator's headphone feed,
overriding the Monitor audio. The
key is now lit.
HP
Pressing the
Auto:
»
ond time toggles Auto mode. In this mode, audio
from the Preview channel overrides the Head-
phone Monitor selection in the left headphone
channel only. Program audio is still present in
the right channel of the operator's headphones.
•
Preview Knob
This knob, at the top right of the Monitor section,
controls the volume of the source heard in the
(cue) speakers. Rotate the knob to vary the gain of the
speakers.
Preview
The
knob is also used to select the source
Preview
of the CR Headphone feeed when headphones are not
linked to the CR Monitor selection. Please see Page 66
of this manual for more information on this function.
•
Monitor 2 Knob
This knob, at the top left of the Monitor section, con-
trols the selection and volume of the source heard in the
speakers (typically Studio or News booth
Monitor 2
monitors).
»
Rotate to vary the
Monitor 2
»
Push the knob to see an on-screen display of
sources that can be assigned to the
feed. Rotate to highlight the desired source, and
push again to "take".
•
Talk To Monitor 2 Key
The board operator can push and hold this key to
talk to the talent listening to the
the key is depressed, audio from the Control Room mic
channel is fed, pre-fader, to the
and headphones (if used). Releasing the key ends the
talkback function.
Other Controls
Keys in this section are used to load Show Profiles,
Preview to
key a sec-
Preview to HP
Preview
speaker gain.
Monitor 2
feed. While
Monitor 2
speakers
Monitor 2
