Figure 2-2: Settings for configuring Element for
operation with Telos phone systems
If this source is a Telos Nx12,
•
PHONE LINE:
TWOx12, Series 2101 or Telos TWO and you will
be operating in Euro mode and wish to dedicate a
phone line to this fader, enter it here.
•
PHONE HYBRID (FOR NX12):
option title says "for Nx12", if this source is a Telos
Nx12, TWOx12 or Series 2101 and you will be oper-
ating in Euro mode, you may specify hybrid 1 - 4 for
this line assignment.
•
USE 2ND SHOW (SPLIT MODE FOR NX12):
though the option title says "for Nx12", if this source
is a Telos Nx12, TWOx12 or Series 2101 and you
will be operating in Euro mode, you may check this
to designate Split Studio Mode, where two hybrids
are assigned to one show, and the other 2 assigned to
a second show. Element will connect to the second
Show in the list.
The next 4 options are used for US mode only:
•
PHONE MODULE ID:
Series 2101 operating in US mode. If you are con-
structing a Source Profile for a telephone hybrid and
have multiple Phone Modules installed, this allows
you to determine which module will control this hy-
brid. For details on setting up a phone system with
Element, please refer to Appendix D: Working With
Phone Hybrids.
For Telos Nx12, TWOx12 or Series
•
HYBRID NR.:
2101 operating in US mode. Specify which hybrid
this Source Profile will control.
Even though the
Even
For Telos Nx12, TWOx12 or
©2008 Axia Audio — Rev. 3.0
Nx Users Note: For Nx12's second show,
you would STILL enter "1" for Hybrid 3 and "2"
for Hybrid 4. Why? Because, to Nx12's internal
logic table, Hybrid 3 is really the first hybrid in
Show 2 and Hybrid 4 is the second hybrid in
Show 2.
•
CONFERENCING ALLOWED:
TWOx12 or Series 2101 operating in US mode. Spec-
ifies whether or not "button mash" conferencing is
permitted. Select
Yes
For Telos Nx12, TWOx12 or Series
•
FIXED LINE:
2101 operating in US mode. When working with a
Telos hybrid that supports it, this command lets you
assign a line permanently to a specific fader, emulat-
ing a dedicated hybrid.
means there is no fixed line assigned.
0
»
slaves the specific line to this source's
1 - 24
»
fader.
Note: For complete instructions on setting up a
phone system with Element, please refer to Ap-
pendix D: Working With Phone Hybrids.
Allows you to set the channel activa-
•
FADER MODE:
tion method of the fader this source is assigned to.
conforms to the US method of requiring
»
Normal
talent to manually turn the channel on and off.
follows the common European
Fader Start
»
standard of activating the channel and associated
machine logic when the fader is raised from ∞.
•
PREVIEW SWITCHING MODE:
will happen to a source's off-air
ment when that source is taken to air.
Normal, Auto-Switching Disabled:
»
bus assignment will be retained even after
view
the fader is turned
»
CHANNEL ON turns Preview OFF:
source is assigned to
tioning, turning its channel
assignment.
Preview
•
HYBRID ANSWER MODE:
to tailor Element's Hybrid Answer mode to suit your
facility's operating style.
For Telos Nx12,
to allow,
to prohibit.
No
Determines what
assign-
Preview
The
Pre-
ON.
If this
for off-air audi-
Preview
will cancel its
ON
This setting allows you
