Axia Element Installation & User Manual page 43

GPIO Film Legendable User Button Module / Accessory Panel / Rack Panel
Name
INPUTS
User Button 1 Lamp
User Button 2 Lamp
User Button 3 Lamp
User Button 4 Lamp
User Button 5 Lamp
OUTPUTS
User Button 1 Switch
User Button 2 Switch
User Button 3 Switch
User Button 4 Switch
User Button5 Switch
POWER & COMMON
Source Common
Logic Common
Logic + 5 Volt supply
Source Supply
NOT CONNECTED
Pin
11
12
13
14
15
1
2
3
4
5
7
8
9
10
6
©2008 Axia Audio — Rev. 3.0
Type
Active Low Input
Active Low Input
Active Low Input
Active Low Input
Active Low Input
Open Collector to Logic Com-
mon Return
Open Collector to Logic Com-
mon Return
Open Collector to Logic Com-
mon Return
Open Collector to Logic Com-
mon Return
Open Collector to Logic Com-
mon Return
Logic Common
Internal 5 Volt return
Logic Supply, Individually
Fused
Common for all 5 inputs
Notes
Illuminates User Button 1
Lamp
Illuminates User Button 2
Lamp
Illuminates User Button 3
Lamp
Illuminates User Button 4
Lamp
Illuminates User Button 5
Lamp
Active when User Button 1 is
pushed
Active when User Button 2 is
pushed
Active when User Button 3 is
pushed
Active when User Button 4 is
pushed
Active when User Button 5 is
pushed
Connect to ground of source
device or to Pin 8
Can be connected to Pin 7 if
source is not providing com-
mon
Can be connected to Pin 10
if source is not providing
voltage; active only when
source has been assigned to
channel.
Connect to power supply of
source device or to Pin 9
GPIO v."Z" 12/2007
