Turns the voice processor's de-
•
DE-ESSER STATUS:
esser module on and off. Choose
•
NOISE GATE THRESHOLD:
at which the Noise Gate will operate (if set to
). Adjustment range is between 0dB and -50dB.
tive
•
COMPRESSOR THRESHOLD:
at which the Compressor will operate (if set to
). Adjustment range is between 0dB and -30dB.
tive
•
DE-ESSER THRESHOLD:
which the De-Esser will operate (if set to
Adjustment range is between 0dB and -20dB.
•
COMPRESSOR RATIO:
pression that will be applied to the mic audio. Ad-
justment range is between 1:1 and 16:1.
Sets how aggressively the de-
•
DE-ESSER RATIO:
esser will remove sibilance from the mic audio. Ad-
justment range is between 1:1 and 8:1.
•
NOISE GATE DEPTH:
reduction that will be applied to the mic audio if
the noise gate is set to
Threshold is reached. Adjustment range is between
0dB and -30 dB.
•
COMPRESSOR MODE:
sor between
and
Freeze
What is this stuff? Radio engineers don't need
a lesson in dynamics processing, but for the ben-
efit of any jocks reading this, here's a quick ex-
planation of what these controls can do.
A Gate is a dynamics device whose function
is to remove unwanted audio material below a
certain threshold. A gain circuit is employed to
raise or lower the volume of the audio signal;
when the signal falls below a certain set thresh-
old, the audio level drops down to a predeter-
mined level. The reason they are called gates
is because when they "close" it sounds as if
the audio has suddenly stopped, or has been
"gated." You might use this on a mic channel to
eliminate background noise during times when
you're not speaking.
Threshold settings determine at what level the
processor will begin working. For example, on
or
Bypass
Active.
Determines the point
Ac-
Determines the point
Ac-
Determines the point at
Active
Sets the amount of com-
Sets the amount of noise
and the Noise Gate
Active
Toggles the voice compres-
modes.
No Freeze
©2008 Axia Audio — Rev. 3.0
a compressor, when signal level exceeds the
threshold setting, it will be compressed; below
the threshold the signal will remain uncom-
pressed. On a gate, threshold determines the
minimum input level required to cause the gate
to open up and pass signal; when input level
drops below the threshold, the gate will be closed
preventing signal from passing. Carefully setting
the threshold allows you to very specifically con-
trol when processing is being applied to a signal.
Compression controls the dynamic range of an
audio signal. It generally reduces the volume of
very loud audio, helping to keep from "blowing
out" the mic channel with too much volume. It
can be used to make your mic channel sound
"fatter," evening out the highs and lows of your
vocal pattern. It can also increase the overall
).
perceived fullness of your voice. Too much com-
pression, however, can make your voice sound
hard and "squashed." Use it sparingly!
To use compression, you must first set your
threshold value (usually expressed in dB). When
the audio signal is louder than this threshold, its
gain is reduced. The amount of gain reduction
applied depends on the Compression Ratio
setting. For example, with a 2:1 ratio, for every
2 decibels the input signal increases, the output
is allowed to increase only 1 decibel.
The Freeze Gate is used to prevent "suck-up"
of room noise during speech pauses. When ac-
tive, gain is not increased by the compressor
when audio is absent. "Freeze" would be the
default, since it almost always improves results.
De-Essing is just what you think it is - a way to
electronically remove extra sibilance from your
mic channel. If your mic is particularly sensitive
to "s" and "th-" sounds and accentuates them
on-air, De-Essing helps reduce these sounds to
more manageable levels. As with compression,
too much de-essing will produce annoying and
unnatural results - you'll wind up sounding like
you're talking through a cotton sock! Stick to
small amounts to get the effect you want.
•
RECORD MODE:
define how this source is sent to the
bus. (
Record
Record
post-fader bus with a special output for a dedicated
recording device.)
sends both sides of the source to both
»
Stereo
sides of the recording device, as normal.
If Phone or Codec Left, otherwise Right
»
sends the source to the recorder's left channel
ONLY if the Source Type is defined as
Any other Source Type will be fed to the
Codec.
recorder's right channel.
»
Summed-Mono to Left
This option allows you to
PGM-4/
is a special pre-on/off,
Phone
sums the left and right
or
