Enter your network's subnet
»
Subnet Mask:
mask value here, usually 255.255.255.0
Gateway IP Address:
»
stration of your Livewire network, you'll need a
network gateway. If you have one installed, enter
its IP Address value here.
»
Engine IP Address:
controls a unique Studio Engine. Enter the IP of
the controlled Engine here.
1st NTP Server IP Address:
»
NTP (Network Time Protocol) timekeeping to
synchronize time-of-day clocks across your fa-
cility. If you have an NTP server, enter its IP Ad-
dress here.
2nd NTP Server IP Address:
»
software supports redundant NTP servers. Enter
the IP Address of your backup server here.
Web Page User Password:
»
protect your Element's webserver connection by
entering a numeric password here.
Note: If you set a password for HTTP access,
you will not see your password displayed in this
field upon re-entering the IP Address book. This
is a security feature intended to prevent "over-
the-shoulder" password theft.
•
Rotating the
knob choosees between the fol-
Action
lowing options:
stores the changes you've made to the IP
Save
»
Address Book.
reverses any changes you've made if you
»
Undo
haven't yet saved them.
immediately reboots the Element.
Reboot
»
•
Press the
knob to leave the IP Address Book.
Exit
Note: After making changes to any Element IP
address settings, you must reboot the console.
Use the "REBOOT" soft key to begin an immediate
reboot sequence.
Remember, you can even reboot Element while
on-the-air, since the audio mixing is not done in
the console but in the Studio Engine; your audio
will continue to play without interruption.
To enable remote admin-
Each Axia control surface
Element supports
Element v2.x
You can password-
©2008 Axia Audio — Rev. 3.0
Clock Configuration
Locate the Timer section of the Monitor Module;
press and hold the key marked
Clock & Timer Options screen (Figure 1-13).
Figure 1-13: Clock & Timer Options menu screen.
•
Rotate the
Select/Set
the list of available options. To select an option to
modify, push this knob. Rotate the knob to change an
option's value, and push the knob when you're done
to move to other fields. Available options include:
»
Set Time Of Day Clock:
NTP (Network Time Protocol) server configured
as part of your Livewire IP-Audio network, use
this option to set the correct time for Element's
on-screen clock.
»
Set Calendar Date:
Element's on-screen calendar.
»
If you have an NTP server tied to
NTP On/Off:
your IP-Audio network, set this option
do not, or if your NTP server is supplying incor-
rect time data, turn this option
with Element's internal clock.
»
12/24-Hour Format:
to enter the
Options
SoftKnob to scroll through
If you do not have an
Choose this option to set
If you
On.
to keep time
Off
This option switches the
